Presentation Platform Engineering

1
Yahoo! Experiences with Accessibility, DHTML,
and Ajax in Rich Internet Applications CSUN,
March 23rd, 2006 Victor Tsaran Accessibility
Project Manager, Yahoo! Inc. Nate Koechley
Senior Engineer Design Liaison, Yahoo! Inc.
2
Agenda

• Changing Landscape
• Definitions
• Four Approaches
• Standards-based development
• Redundant interfaces
• Fortified, thorough interfaces
• Accessible DHTML
• Looking Ahead

3
About Us

• Victor Tsaran
• Accessibility Project Manager
• Nate Koechley
• Senior Frontend Engineer
• Technical Architect and Design Liaison
• Presentation Platform Team

4
Whats Happening?
5
Browser vs. Desktop
6
Web 1.0 vs. Web 2.0
7
Yahoos Alan Cooper Model
8
Definitions
9
DefinitionsDHTML

• DHTML is
• markup and style made interactive and dynamic
  through script
• Generally, DHTML is JavaScript modifying CSS,
  HTML and the DOM
• DHTML is not
• a specific technology
• inherently inaccessible
• new

10
DefinitionsAJAX / Ajax

• Asynchronous JavaScript and XML
• the ability to talk to the server without tearing
  down the existing page
• the ability to update part of the page
• Ajax is not
• a specific technology
• inherently inaccessible
• new
• No server requests its not Ajax
• AJAX is a subset of Ajax

11
DefinitionsRich Internet Applications (RIAs)

• Rich Internet Applications are
• web apps with features and functionality of
  traditional desktop applications
• usable from any internet terminal no
  installation required
• can be created in various languages Flash,
  JavaScript, Java
• todays talk is focused on JavaScript RIAs

12
DefinitionsAccessibility

• Accessibility is
• A general term used to describe the degree to
  which a system is usable by as many people as
  possible without modification (cite wikipedia)
• Often, our focus is on enabling screen-readers
  specifically
• However, the resulting work in generally more
  far-reaching

13
What about Desktop Accessibility?
14
Accessibility on the Desktop

• Through various APIs
• Microsofts Active Accessibility (MSAA)
• Suns Java Access Bridge
• Accessibility Toolkit for Linux (ATK)
• Software communicates to the operating system,
  which communicates with assistive technology.
• Highly effective, resulting in nearly omnipresent
  accessibility.

15
But what about web accessibility?
16
Accessibility on the Web (1)

• Some information is provided to the desktop API
• The Document Object Model (DOM) provides static
  information via semantic elements and attributes
• But

17
Accessibility on the Web (2)

• but the depth of necessary information is
  missing
• Role, state, actions, caret, selection, children,
  relations, changes
• And so are inputs and outputs
• keyboard, focus, blur, change, updates.

18
So how can we move forward?
19
Four Techniques Use em All

1. Standards-based development
2. Redundant interfaces
3. Fortified, thorough interfaces
4. Accessible DHTML

20
Approach 1Standards-based development

• Overview and Definition
• Subsequent layers enhance meaningful and
  structured markup
• Progressive and unobtrusive enhancement
• Make each layer a strong foundation
• Dont corrupt neighboring layers

21
Approach 1Standards-based development

• Examples
• Tab box is really anchored links and lists well
  marked up content, available to all
• Unobtrusive JavaScript doesnt Hijax links when
  it shouldnt
• Stretching semantics to provide clues
• Microformats enrich date, and provide predictable
  hooks for add-ons

22
Approach 1Standards-based development

• Example Tab-Panel box complete

23
Approach 1Standards-based development

• Example Tab-Panel box no CSS

24
Approach 1Standards-based development

• Example Tab-Panel box no JavaScript

25
Approach 1Standards-based development

• Benefits
• Should be doing this regardless
• Truly available to all
• The foundation of better things
• Works with the grain of web technologies
• A step toward a semantic web
• Here to stay, more than 10 years

26
Approach 1Standards-based development

• Drawbacks
• Doesnt solve every problem
• Perceived overhead
• Unobtrusive JavaScript and Hijax are still less
  familiar techniques
• Be careful not to step on event handlers
• Only trap clicks when appropriate
• Server must reply to both partial and complete
  requests from the client

27
Approach 2Redundant interfaces

• Overview and Definition
• Multiple means of input
• GUI input vs. alphanumeric input
• Direct movement of objects vs. form-based
  movement
• Multiple means of manipulation
• Keyboard vs. Mouse
• Esc vs. Cancel
• Drag-drop vs. form-based

28
Approach 2Redundant interfaces

• Example, 1D Slider Input
• Simple support for vertical and horizontal
  sliders as a direct-manipulation alternative to
  input boxes
• Enhances the basic input box, but need not
  replace it.

29
Approach 2Redundant interfaces

• Example, 2D Slider Input

30
Approach 2Redundant interfaces

• Example Calendar Date Selector

31
Approach 2Redundant interfaces

• Benefits
• Better for everybody
• Keyboard is important for ALL users
• Provide multiple familiar task paths
• Transfer the complete set of expectations from
  the desktop to the browser
• Works today

32
Approach 2Redundant interfaces

• Drawbacks
• Cannot fully communicate with the desktops
  accessibility APIs
• Dual experiences challenge goal of parity
• Requires development of two experiences

33
Approach 3Fortified, thorough interfaces

• Overview and Definition
• Now is the time to lay a new foundation
• Libraries and platforms must support all comers
• Not just the mouse, not just the keyboard
• Not just one key, but all keys
• Must offer a faithful and complete experience

34
Approach 3Fortified, thorough interfaces

• Examples Menu fortified with keyboard

35
Approach 3Fortified, thorough interfaces

• Example Slider fortified with keyboard

36
Approach 3Fortified, thorough interfaces

• Benefits
• More options for everybody
• Supports many working styles
• Establish the new platform
• My prediction new platform will last much longer
  than the 10 years of the previous platform

37
Approach 3Fortified, thorough interfaces

• Drawbacks
• Isnt easy
• Clients dont always notice
• Requires personal integrity and commitment
• Seems more complete and heavy

38
Approach 4Accessible DHTML

• Overview and Definition
• IBM technology, now in W3C and open
• http//www.w3.org/WAI/PF/adaptable/HTML4/embedding
  -20060318.html
• Allows embedded role and state metadata in HTML
  documents
• Uses namespace extensions to XHTML 2, but
• Techniques allow most functionality in HTML 4
  documents, as of today
• Communicate directly with the desktop API

39
Approach 4Accessible DHTML

• Examples XHTML 2

lthtml xmlnswairole"/w3.org/2005/01/wai-rdf/GUIRo
leTaxonomy" xmlnswaistate/w3.org/2005/07/aaa"
gt ltspan id"slider" class"myslider"role"wairol
eslider"waistatevaluemin"0"waistatevaluemax
"50"waistatevaluenow"33"gt lt/spangt
40
Approach 4Accessible DHTML

• Examples HTML 4

ltscript type"text/javascript" src"enable.js"gtlt/s
criptgt ltspan id"slider" class"myslider
myselector2 slider valuemin-0 valuemax-50
valuenow-33" tabindex"0" gtlt/spangt
41
Approach 4Accessible DHTML

• Benefits
• Utilizes powerful and well-understood desktop API
• Map controls, events, roles and states directly
  to powerful and well-understood desktop
  accessibility APIs
• Enriches markup in standard way

42
Approach 4Accessible DHTML

• Drawbacks
• Requires recent-version of assistive technology
  software (e.g., screen reader)
• Only works in Mozillas Firefox 1.5 today
• Not in Microsofts IE 7, or others
• XHTML required for full power
• HTML does not allow multiple states, for example
• Emerging technology

43
More Information

• Nate Koechley
• natek_at_yahoo-inc.com
• http//nate.koechley.com/blog
• Victor Tsaran
• vtsaran_at_yahoo-inc.com
• Yahoo! Developer Network and Y! UI Blog
• http//developer.yahoo.net
• http//developer.yahoo.net/yui
• http//developer.yahoo.net/ypatterns
• http//groups.yahoo.com/group/ydn-javascript
• http//www.yuiblog.com

44
END OF TALK

• NOTE Remaining slides are candidates for
  inclusion, but will likely be dropped from the
  presentation.

45
Looking ahead

• What is at risk if we dont standardize on an
  accessible platform?

46
Open Questions

• Is there always an alternative to a mouse-based
  experience? (for example, with the mouse I can
  reorder the toolbars in MSWord. Im not sure if
  this is possible without a mouse, or even
  necessary.)
• Partial-page updates remain difficult to
  communicate to the screen readers DOM buffer.

47
Slider
48
Calendar
ltscriptgt var myCal function init()
myCal new ygCalendar(myCal,myCalContainer)
myCal.render() lt/scriptgt ltdiv
idmyCalContainergtlt/divgt
49
AutoComplete
50
TreeView
