Purpose of this presentation

• This presentation is designed to be presented to
  customers. You do not need to have an NDA.
• It is acceptable to leave paper copies or provide
  this electronically.
• Disclaimer We will do our best to keep this
  presentation accurate. Please check the launch
  kit frequently to make sure you have the latest
  revision.

3
CN50 Handheld Mobile Computer

• Feature Rich and High Performance
• Small, Light Weight and Rugged Design
• Optimized for Mobile Applications
• Complements CN3/CN4 in Extending Intermec Reach

4
The CN50 Value Proposition

• The CN50 gives Mobile Workers, Business Managers,
  and IT Managers in Applications within Field
  Service, Postal/Courier, Transportation,
  Commercial Delivery, Public Safety, and Home
  Healthcare the ability to
• Hold and carry the industrys most advanced
  highest-performance 3.5G mobile computing device
  in a small, light weight, and rugged form factor
  - reducing operator fatigue and increasing user
  acceptance - with the longest battery life and
  highest-speed voice/data capabilities available.
• Deploy a single hardware solution on the wireless
  network that offers the lowest cost and best
  geographic coverage, and to re-provision the
  radio to a different carrier network as business
  needs or coverage options evolve - simplifying
  application development and verification
  complexity, lowering deployment costs, and
  dramatically lowering overall cost-of-ownership.
• Complete more tasks faster on a single,
  high-performance multifunctional device
  eliminating the need to purchase, manage, and
  maintain different devices while increasing
  worker productivity and efficiency, reducing
  operational costs, and improving service quality,
  accuracy, responsiveness.
• Expand service offerings through leverage of more
  data-intensive enterprise applications -
  including implementation of always-on vehicle or
  pedestrian-based services with real-time
  location, directional movement, or navigation
  information and applications requiring secure
  data transfer of detailed technical diagrams,
  documents, and electronic payment information or
  large file attachments such as, higher-resolution
  images for proof-of-condition and geo-stamping
  for proof-of-location.

5
Who benefits from the CN50

• Mobile workers that are highly mobile, where
  activity is dominated by hold and carry and
  direct customer interaction
• Desire a light weight, streamlined, yet highly
  capable solution
• Business managers that want to improve and expand
  their service offering to increase profitability
• Need tools to increase mobile worker
  productivity, efficiency and capability
• IT managers that need to control costs and
  maintain flexibility in their mobile IT solutions

• Need IT solutions that enables them to grow and
  adjust as business conditions change
• Need tools that integrate easily with existing
  systems and reduce time to deploy and maintain

6
How CN50 Meets Your Needs

• Compact, light weight
• Rugged
• Powerful navigation tools. WWAN radio provides
  real-time, always connected, voice and data.
• Intuitive and easy to use is combined with high
  speed computing and communications
• Converged data capture, navigation, communication
  and computing
• Industry standard and industry leading tools for
  development, deployment, and management of your
  mobile business solutions

• On the go all day
• Wet, dirty, rough environments
• Strive for on-time service delivery
• Improve productivity and efficiency
• Streamline the tools needed to get the job done
• Strive to increase service levels while reducing
  cost to operate the mobile solution

7
CN50 Product Description and Attributes
Smallest size, lightest weight, rugged WWAN
mobile computer from Intermec
Flexible Network 3.5G radio UMTS or CDMA
802.11b/g WLAN Bluetooth Integrated GPS
Intermec 2D Area Imager 3 MP Autofocus Color
Camera
Enhanced Mobile Document Imaging
Digital Compass and Accelerometer
All new Multi-Processor Architecture Windows
Mobile 6.1
Numeric or QWERTY Keypad Options
128 MB RAM 512 MB Flash up to 32 GB microSD
Expansion
Standard Extended Battery Packs
8
CN50 Physical Specifications

• 25 Smaller and lighter than other full-featured
  devices
• Size 15.2 mm x 7.5 mm x 2.5 mm (6 in x 3 in x 1
  in)
• Weight 310 340 gm (10-11 oz)
• More rugged and improved industrial design
  compared with other light weights
• 1.5 m (5 ft) drop, 26 times per MIL-STD 810F
• IP54 Dust Water Sealing
• -10 to 50C (14 - 122 F) Operating Temp
• No external antenna
• Designed for usability and all day comfort
• Tethered Stylus
• Hand strap, Soft Grip Area
• Scan Button Ridge

Standard
Extended
For hold and carry applications, the small size
and light weight of the CN50 increases user
acceptance, reduces fatigue, and eliminates the
burden of carrying a bulky and heavy mobile
computer. The Rugged design increases reliability
over commercial grade SmartPhones or lower grade
mobile computers
9
High Speed WWAN Radio

• Compared to EDGE and HSDPA, the CN50 can
• Download up to 30x faster than EDGE and 2x
  faster than HSDPA
• Upload up to 16x faster than EDGE and 5x faster
  than HSDPA
• Compared to CDMA Rev 0, the CN50 can
• Download up to 30 faster
• Upload up to 10x faster
• Faster data transfers increase productivity,
  improve customer service, and enable new services
  that arent practical at slower speeds. High
  speed uplink enables applications such as
  document imaging to transfer files faster. By
  supporting 1700 MHz, the CN50 is the only rugged
  mobile computer to work on the two leading UMTS
  networks in the US (T-Mobile and ATT)

10
WWAN Flexible Network Radio

• A single hardware platform that can be
  re-programmed for any CDMA or UMTS network in
  North America
• Support only a single hardware platform but
  deploy on the best available network
• Economically re-provision devices if they need to
  change network providers
• Negotiate with data carrier without feeling
  locked in by their mobile hardware

The CN50 with Flexible Network Radio allows IT
departments to manage their WAN enabled mobile
solutions with simplicity, flexibility and cost
saving that has never been previously available.
11
High Quality Cell Phone

• Ergonomic design and full feature set allows the
  CN50 integrated phone to easily replace your
  existing cell phone
• Well designed speaker and microphone provides
  highest quality voice communications

The high quality voice capabilities of the CN50
eliminates the need for dedicated cell phone,
reducing the tools needed by a mobile worker and
simplifying IT task to deploy and manage multiple
hardware devices.
12
Imager and Color Camera

• CN50 comes standard with both an imager
• and color camera
• 1 Megapixel imager
• High Speed scanning for 1D and 2D barcodes
• Supports new Intermec Enhanced Mobile Document
  Imaging
• Dedicated DSP provides responsive barcode
  performance
• Industry leading 3.1 Megapixel Color camera
• Autofocus Flash
• Provides high quality image capture and easy
  integration of picture data within the Line of
  Business application

By combining both a camera and a scanner, theres
no need to carry a separate digital camera,
reducing the burden on the mobile worker. The
integrated camera streamlines the process of
getting image data integrated into the mobile
application. IT department has less tools to
deploy and maintain.
13
Intermec Enhanced Mobile Document
ImagingOptional software application available
for CN50

• Features
• Capture full-page document images
• Point Capture user experience
• Image enhancement that cant be provided by
  cameras
• Compression, perspective correction, contrast
  enhancement
• Compatible with major document management
  systems.
• Supports common document indexing schemes (doc ,
  PRO , invoice , date/time stamp, etc.)
• Creates images in file size and native formats
  that are accepted by document management
  companies.
• Works indoor, outdoor, and with cab lighting
  conditions

With eMDI, the CN50 improves cash flow by
simplifying workflow and reducing the time
between delivery of shipments and invoicing the
customer. The easy point and capture operation
improves image quality by eliminating the
variability between users.
14
Digital Compass and GPS

• Enhances the functionality of GPS
• Applications can display a map or instructions
  based on the direction you are facing
• Provides a real-time indication of direction and
  does not require movement to determine which way
  you are heading
• Can be used with or without GPS software
• Combined with the integrated camera, this allows
  the user to easily document time, location, and
  directional heading of picture images
• The digital compass of the CN50 improves
  turn-by-turn directions to increase driver and
  pedestrian efficiency by reducing the errors and
  overcoming a key limitation of existing GPS
  solutions . This improves worker productivity and
  helps save time and fuel.

15
Accelerometer

• Built in Sensors allows the CN50 to monitor
  direction and acceleration
• Device always knows which way is up and sensors
  provide complex data to monitor movement of the
  device
• This capability allows Smart applications such as
• Turn the device sideways, and the display on the
  screen will rotate
• Lay the unit face down and the backlight can dim
  to save power
• Install a background application that can monitor
  mobile work movements and behavior
• Orientation and motion sensors can simplify work
  processes and improve user acceptance. By
  monitoring device movements, business managers
  can monitor worker activities and to eliminate
  unnecessary motion and improve workflow
  efficiency.

16
WLAN, BT, and Integrated GPS

• WLAN
• WiFi certified 802.11 b/g, WPA, WPA2
• Microsoft Zero Config provides simple and secure
  connection management
• Bluetooth
• V2.0, Class 2, EDR
• Supports printers, scanners, BT Audio Devices
• Integrated 12 channel receiver
• Stand Alone or A-GPS
• Can use ephemeris data for faster TTFF
• Accuracy within 3 meters (10 ft)

With integrated WWAN, WiFi, Bluetooth, and GPS,
the CN50 provides flexible wireless options for
voice and data connectivity, allows the mobile
computer to be used with a variety of Bluetooth
peripherals, and integrates easily with 3rd party
navigation software. All this in a single device
lowers overall costs and simplifies deployment
and management of multiple devices.
17
CN50 Simplify and Lower the Cost of the Mobile
IT Solution

• Development
• Industry standard Windows Mobile 6.1 makes it
  easy to develop and port existing mobile
  applications. This save time and money
• Intermec Developers Resource Kits allow
  programmers to quickly port applications that
  were developed for existing Intermec platforms
• Deployment
• Scan to Connect Use simple and fast barcode
  scanning to configure your CN50 and connect to
  your enterprise wireless network
• Easy Set Simple tool to configure scanner
  settings
• AutoDeploy / SmartSystems Fast and reliable,
  this saves time and guarantees the installation
  is done correctly. New Scan to Load uses a simple
  barcode scan to automatically load and install
  applications from your secure network.
• Management
• Compatible with most 3rd party remote device
  management solutions, the CN50 can easily be
  updated or completely reprogrammed with minimal
  or no interaction from the mobile user
• Windows Mobile Image Update and SmartSystems
  allows manual or automatic software updates
  without requiring proprietary device management
  software

18
Accessories

• Desktop AC charger w/USB
• Vehicle Holder
• Vehicle Power Adapter
• Quad Battery Charger
• Multi-Dock with or without Ethernet
• Belt Holster

19
Configurations and Accessories
20
CN50 WAN Configurations and Availability

• 3G / 3.5G
• US List 2500 w/battery
• UMTS, Limited Quantities for ATT or Non-WAN
  usage July 1
• UMTS, Full Shipments for ATT Sept 09
• CDMA, Full Shipments for Verizon Oct 09
• CDMA, Full Shipments for Sprint / Bell Mobility
  2010

21
Thank You!
22
Backup Slides
23
CN50 Intermec Value Add SoftwareThese are the
Intermec SW tools planned for CN50 initial
launch, we will be adding more over time. Please
check with you Intermec rep.
SmartSystems See following slide
24
CN50 - Smart Systems Support

• SmartSystems Reference Client
• Remote Settings Management
• Data Collection, Bluetooth, 802.11 Microsoft Zero
  Config, SmartSystems Settings
• Scan-to-Connect/Scan-to-Load
• HTTP or FTP loading of applications
• SmartSystems Bundle Provisioning (3.50 Feature of
  SmartSystems Foundation Console)
• Application Deployment
• Silent Image Update Capability
• Licensed on Device Separately
• 3rd Party Device Management Extensions
• SmartSystems Foundation Console
• Not Included
• No Intermec Settings Manual UI, however all
  settings are fully programmable

25
CN50 UMTS Country Availability(This list is
constantly being updated. Check with sales rep)

• First PQA Work Week 31 (44 Countries)
• 30 EU Countries Austria, Belgium, Bulgaria,
  Cyprus, Czech Republic, Denmark, Estonia,
  Finland, France, Germany, Greece, Hungary,
  Iceland, Ireland, Latvia, Liechtenstein,
  Lithuania, Luxembourg, Malta, Netherlands,
  Poland, Portugal, Romania, Slovakia, Slovenia,
  Spain, Sweden, Switzerland, UK, Turkey
• 4 MEA Countries Egypt, India, Morocco, Saudi
  Arabia
• 4 APAC Countries Singapore, Hong Kong, Thailand,
  Vietnam, Australia, New Zealand
• 4 Central/South American Countries Venezuela,
  Costa Rica, Chile, Belize
• Russia, Ukraine
• Second PQA Work Week 38 (12 Countries)
• 2 North American Countries US (ATT), Mexico
• 7 Central/South American Countries Columbia,
  Argentina, El Salvador, Guatemala, Honduras,
  Nicaragua, Panama
• 1 MEA Country Israel
• 2 APAC Countries Indonesia, Taiwan
• Remaining Carriers Countries (11
  Countries/Carriers). We will work with the local
  contacts (below) to finalize schedule
• Norway (Telnor) - Herlufsen,
• Italy (TIM) Costi, Brazil
• Canada (Rogers / Telus) McGuire / Guadagnolo
• Telus is switching their network to UMTS. UMTS
  deployment and certification plan is yet to be
  defined.
• South Africa (Vodacom) and UAE Summers / Cox
• Philippines (Smart) and Malaysia (Maxis) Tay /
  Hng / Ng

26
What is Enhanced Mobile Document Imaging (eMDI)?

• eMDI enables the ability to capture full size
  documents in the field
• 81/2x11 or A4
• Primary components CN50 with EA21 scan engine,
  decode software, license
• Represented as a separate offering with its own
  launch kit on GSS
• Product Profile, FAQ, White Paper, Video
• Users Manual, Intermec U Training Module
• Primary markets and applications
• TNL (LTL, courier express package, postal carrier
  last mile delivery)
• Field Service (secondary)

27
eMDI Delivers Real Value

• Improves cash flow for LTL carriers by reducing
  the time between delivery of shipments and
  invoicing the shipper
• eMDI enables processing after each stop versus
  the end of the day or after leaving with a drop
  off service
• Trip envelopes have to be processed before
  customers can be billed.
• Point Capture user experience reduces
  variability in image quality between individual
  users
• Laser framer (no more estimating with a view
  finder)
• Image enhancement that cant be provided by using
  camera only
• Keystone correction (perspective), brightness,
  flattening, contrast
• Works in indoor, outdoor and cab lighting
  conditions
• Easy integration with existing mobile
  applications and popular document management
  systems
• Compatible with major document management
  systems.
• Supports common document indexing schemes (doc ,
  PRO , invoice , date/time stamp, etc.)
• Creates images in native formats that are
  accepted by document management companies.
• Use eMDI software out of the box.
• Integrates directly with existing mobile
  applications.
• APIs available to customize user experience.

28
eMDI - Deployment, Pricing and Part Number

• eMDI application is free
• Shipped on CN50 computers
• The application is also a sales tool, no demo app
• Use without license produces images with a
  watermark
• List Price 160 (based on 1 year ROI with
  respect to drop off service)
• M discount code (25)
• Listed in Price Guide under CN4 software sections
• License name is mobile_doc_imaging.d
• Unique startup icon

29
eMDI Point Capture User Experience

• Easy-to-Use point capture user experience
  reduces variability in image quality between
  individual users
• Laser framer (no fiddling with viewfinder)
• Image correction
• Keystone correction, brightening, flattening,
  contrast
• Up to 10 degrees of rotation, up to 35 degrees
  off of vertical
• Image capture from 1 foot above document
• Works in outdoor, indoor and cab lighting
  conditions
• Constraints
• Full size documents should have good print
  contrast and captured only to Jpeg grayscale
  images with good lighting environments
• Half size documents can be captured to TIFF
  monochrome images if they have good print
  contrast with good lighting.
• This version does not support OCR or decoding
  embedded barcodes

Results using a camera
Results using Intermec MDI
eMDI Laser Framer
30
Support ServicesChoosing the Best Repair Value

• Medallion Complete Contract Service Repairs
• Peace of Mind' through comprehensive service for
  Intermec rugged mobile computers, which provides
  insurance against unbudgeted and rising repair
  costs.
• Committed turnaround times
• Locked in, long-term value-based pricing3 5
  year contract terms aligns with depreciation
  and/or leasing schedules
• Covers defects, failures, normal wear tear
  damage, and preventative maintenance during
  repair
• NO additional charges for repair of physical
  damage
• Telephone based Technical Support
• Standard Warranty-related Repairs
• Standard Warranty coverage only applies to
  defects in material or workmanship
• Best effort, on average 15-day depot repair time

Please see Medallion Complete Terms
Conditions.
Medallion Complete Silver Contract Packages
2-day depot repair timeBronze Contract
Packages 5-day depot repair time Silver
Replacement Contract Packages Overnight
depot replacement from customer-owned spares
pool
31
Professional ServicesConsistency for Faster ROI

• Most experienced, trusted provider in technology
  deployment planning through systems Go-Live
• Offering a complete suite of Professional
  Services to support your rugged mobile computers
• ReadiCareSM Activation and Provisioning Services
  (available in North America only)
• WWAN Carrier Provisioning Activation
• Software Configuration
• Tagging
• Operational Testing
• Packing, Storage Staging
• Project Management
• Vehicle Installation for forklifts, trucks
  other vehicles
• Application Documentation
• Software Project Management, Development
  Support
• RFID Consulting Implementation

Some services may not be available in your
location. Please check with your local service
representative for availability.
32
Education ServicesCustom Training for End User
Solutions

• Flex with the Changes Training Ensures
  Successful Rollouts
• Training Deliverables
• Pre-rollout Promotion
• Curriculum Development
• Sourcing Training of Instructors
• On-site Training Delivery
• Train-the-Trainer Programs
• Project Management
• Help Desk Support
• Facility and Logistics Planning

Some services may not be available in your
location. Please check with your local service
representative for availability.
