437th Operations Group Web Application
Development Team Capstone Corporation Charleston
AFB, SC
FASTT WAS DEVELOPED BY DEREK.MENDEZ AND
JOHN.BAUSCHATZ DSN 673-6478
2
(No Transcript)
3
https Guards mission data and personnel data
NTFS domain authenticated identity throughout
4
Calendar Data published by Current Ops
(externally) is shared at the data layer. When
events are added, changed, or deleted by the
Current Ops Bookie, the status is automatically
displayed on the calendar. Squadrons do not have
to re-define scheduled flying events (from
Current Ops) or scheduled training events (from
Wing Training).
5
Calendar display option Filter Allows user to
select the content to be displayed on the
calendar
6
Calendar display option Unit Allows user to
select the unit events to be displayed on the
calendar Mission units are assigned by
Current Ops (externally) Locally defined events
are assigned to the creators unit For Sale
events have not been assigned to a squadron
by Current Ops
7
Calendar display option Unit Allows user to
select the unit events to be displayed on the
calendar
8
Calendar display option Customize Second
monitor (crew information) can be automatically
refreshed with each selected item Calendar
breaks can be based on Local or Zulu
9
Tricks of the trade Contextual Menu System
Administrators have an additional menu item that
allows for quick switching between Production and
Development environments
10
Start date for calendar Back one week
Back on month Forward one week Forward
one month
Number of weeks displayed Decrease by one
week Increase by one week
Context Reminder 14AS Current displayed
Squadron Date shows Event Start Date by
Local or Zulu
11
New mission items added to calendar Notional
missions Crew anticipation Jump Orders
Group Events (cc, ergo, picnic, etc)
Access any scheduled event by tracking number
12
External Link to Music Another agency maintains
the mission scheduling application, Music. There
is a shared security between the web servers.
This means users do not have to log in to the
target system after clicking on the
link. Calendar dates are links to the LIVE,
published AOD in Music.
13
Color Coded Calendar Blue Firm
Crew Black Beyond 48 hours Green SRT within
48 Yellow SRT within 36 Red SRT within
26 Gray-Red Canceled w/Crew Gray-Black Canceled
no crew
14
Change notification If the mission start time is
still future, and the change from Current Ops
generated a numbered change then the event is
highlighted
15
Tricks of the Trade Web page log-in sessions
time-out after predetermined time periods. To
keep-alive this session, so the user does not
have to log back into the application, a small
file is included with the page content. This
included page auto-refreshes every five minutes,
restarting the session expiration clock. Users
are not aware of any activity on the page.
16
Sequence of Events Start Time/Date and Stop
Time/Date are external data fields. All others
are derived from a matrix based on Crew Type
field. AirLand vs Airdrop and Local vs Overseas
determine offsets. All times managed in Zulu,
displayed in Zulu and Local
17
Sequence of Events Options User selectable Pre
Crew Rest, Post Crew Rest, and SRT based on
mission needs
18
Sequence of Events AOD information pulled
live from MUSIC.
19
Sequence of Events Air Refuel button is
displayed if there is AR information. Link
opens live MUSIC data Since AR data is not
always applicable, this popup prevents consuming
page real estate when it is not needed
20
Sequence of Events Change acknowledgement.
ORANGE items are changes/addons. They are
acknowledged
21
Sequence of Events Once the order has been
completed, it can be accessed conveniently from
the SOE area. This has made it easier on users
still using a single monitor.
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
Sequence of Events Based on Crew
Type Calculated from Start Date/Time and Stop
Date/Time
Airland Local PreCR -12 Alert -225
Show -165 FSRT StopDate/Time
PostCR StopDate/Time
Airland Mission PreCR -24 Alert -225
345 Show -165 245 FSRT 14 / 21
PostCR 48
AirDrop Local PreCR -12 Alert -255
415 Show -195 315 FSRT StopDate/Time
PostCR 0
AirDrop Mission PreCR -24 Alert -255
415 Show -195 315 FSRT 14 / 21
PostCR 48
26
Two screen application Windows can be SYNCd to
bring up crew for each selected calendar event
27
Crew Status Alert/Notional/Notified Above/Below
the line Audit trail (aircrew changes) Scheduler
comment area
28
AF 4327A crewmember data Crew remarks codes Crew
Codes (Column F) are updated FUNDED controls
above/below line
29
AF 4327A additional data Four pages of order
data Uncompleted steps highlighted Data driven
defaults Squadron unique values
30
Additional crew members added Guest/FCC/RAV/PUR/CT
CS FCCs added by MXG Guests shared between
squadrons Crew Qual checked against ARMS
31
Crew Display Filters Squadron/Type/CrewQual Crew
Qual data driven based on Event Type White
background displays event timeframe
32
Available Crew Status (Rainbow) Times filtered to
the minute Displays whole-day event color Event
Type driven crew qual i.e. Air Drop 3rd digit
numeric Rainbow event links to calendar
33
UNAvailable Crew Status (Rainbow) Times filtered
to the minute Displays whole-day event color
34
PDF document generated on request DRAFT appears
until FINAL checked Crew Qual changes
indicated Masked/Full SSN option Option to print
back
35
Optional NATO order
36
Setup sheet Includes scheduler remarks Alert/Fly
Hour/Security Clearance info
37
FASTT
