Security in application integration

1
Security in application integration

• Kari Nordström

2
Topics

• Objectives
• Application integration
• Enterprise Application Integration EAI
• Business-to-Business integration B2Bi
• Information security
• Basic concepts ideas
• Network security
• Segmented networks
• Security of application integration systems
• Results

3
Background and objectives of the thesis

• Find out the current level of security in the
  application integration systems of a certain
  company
• Conduct security reviews with a panel of experts
• Make suggestions on improving the security level
  based on findings
• Implement improvements if possible
• Supervisor Docent Timo O. Korhonen

4
Application Integration

• Integrating various applications enables
  information sharing between applications and
  organisations, not between people
  (System-to-System connections)
• Internal and external integration
• EAI B2Bi
• Traditionally integration has dealt with sharing
  business data and documents
• B2Bi is usually used for exchanging business
  documents
• EAI integrates applications to work together,
  data can be gathered from various sources
  (applications) before processing

5
Application integration platforms in the company
6
Enterprise Application Integration (1/2)

• Integration within a single enterprise
• A centralised integration solution
• Error handling, monitoring, cost savings over time

7
Enterprise Application Integration (2/2)

• Integrating diverse applications requires
  transformations between formats
• Processing and / or enrichment of data is also
  required in some integrations (defined in the
  workflow)

8
Business-to-business integration

• Integration between separate enterprises (partner
  integration)
• Business data, demand / supply planning
• B2Bi relies on standards, otherwise it would be
  very cumbersome to connect to other companies,
  each using their own data formats and processes
• Two B2Bi platforms used in the company
• EDI, Electronic Data Interchange
• RosettaNet

9
Electronic Data Interchange (1/3)

• EDI is the granddaddy of all B2Bi systems
• Designed to automate exchanging business
  documents ? a quicker and cheaper way
• Dates back all the way to the 1960s, in active
  use since the 1980s
• Two main standards in use
• EDIFACT (EDI For Administration, Commerce and
  Transport)
• ANSI X12

10
VAN-based EDI (2/3)

• VAN (Value Added Network) operators used to relay
  messages
• An electronic post office

11
Internet EDI (3/3)

• EDI-INT has been thought up to eliminate VAN
  costs to companies
• Standards used
• AS1 (SMTP)
• AS2 (HTTP)
• AS3 (FTP)
• The basic idea sending EDI messages directly to
  trading partners over the Internet

12
RosettaNet (1/2)

• XML-based integration standard
• Developed and maintained by the RosettaNet
  Consortium, a non-profit organisation of more
  than 500 corporations
• Integrations are based on Partner Interface
  Processes (PIP), which define how data is
  processed and the sequence of transactions
  between trading partners
• RosettaNet Implementation Framework (RNIF)
  describes the basic architecture (RNIF 1.1 2.0)
• Document Type Definition (DTD) describes the
  format of messages and data

13
RosettaNet (2/2)

• RosettaNet aims in integrating the whole supply
  chain, not just passing business documents
• Marketed as more flexible and easier to implement
  than EDI
• Using VANs actually makes EDI more simple than
  RosettaNet where companies need to implement all
  connections themselves

14
Information security

• Traditional way to model information security CIA

15
General security concepts

• Authentication
• Making sure the user is who she claims to be
• Authorisation
• Giving an authenticated user the right to do
  something
• Accounting
• All operations performed by users are logged

• Non-repudiation
• If a user performs a task, she cant later deny
  having done so, the system also cant later deny
  the users action
• Antivirus protection
• Protecting computers and network elements against
  malicious software
• Cryptography
• Scrambling information in a way that only the
  correct recipient can decipher it

16
Network security

• Host security vs. network security
• Systems are protected on the network level by
  controlling network traffic
• More cost-effective than host security
• Typical misconception network security
  firewalls
• Firewalls are a central part of network security,
  but there are numerous other things to consider
  (understanding the network architecture is key)

17
A few key security strategies

• Use multiple, diverse layers of security
• Give the lowest possible rights to users
• Deny everything thats not explicitly allowed
• Use choke points to monitor traffic
• KISS Keep It Simple, Stupid
• Make users aware of security issues!
• The human factor is often the weakest link in
  security

18
Network segmentation

• A new network architecture in the company that
  divides an internal network into smaller parts
  called cells
• Naturally also affects AI systems
• In practice more firewalls

19
Security requirements for application integration
systems

• An AI system is central and crucial in any
  network that has one
• Connected to many other systems ? attacker could
  gain access to virtually the whole network if
  e.g. the EAI system is hacked
• Availability requirements are very high
• Many other systems are dependant on integration
  systems

20
Results of the security reviews

• Risk level is high for all three systems
• Security implementations do not match the current
  requirements
• Requirements have changed significantly from the
  1990s
• RosettaNet was found more secure than EAI and EDI
• Age, standardisation, segmented network
• EDIs problem is the number of unknown factors
• VAN operator responsible for most of the
  implementation
• EAIs biggest problem is the lack of security
  standards

21
EAI security improvements

• User management (no super-users) ? access control
• Certain authentication issues have been addressed
• A component was not authenticating connections
  properly
• Client software used (fewer vulnerabilities)
• The migration to new architecture will bring
  major advancements in the security of the system
• Border security
• Hosts have been hardened

22
B2Bi security improvements

• Its hard to fundamentally change security
  implementations in standardised systems
• User management has been improved vastly in EDI
• EDI will also be migrated into new architecture
  (RosettaNet has already been migrated)
• RNIF specifies many security features, such as
  various forms of encryption, digital certificates
  and checksums
• They just werent always used in the company ?
  new policy

23
Any questions or comments?

• If not, thank you!
