Introduction: Lasers

1
Courtesy Electron Physics Group, NIST
6
Atoms and Light
Introduction Lasers 6.1/ Characteristics of
Atoms 6.2/ Characteristics of Light 6.3/
Absorption and Emission Spectra 6.4/ Properties
of Electrons 6.5/ Quantization and Quantum
Numbers 6.6/ Shapes of Atomic Orbitals 6.7/
Sunlight and the Earth
2
6.1 Characteristics of Atoms
1 mole sample of Li
Atoms possess mass Atoms contain positive
nuclei Atoms contain electrons Atoms occupy
volume
Courtesy John Olmsted
3
6.1 Characteristics of Atoms
Fig 6-1
Atoms possess mass Atoms contain positive
nuclei Atoms contain electrons Atoms occupy
volume
Atoms have various properties Atoms attract one
another Atoms combine with one another
4
6.2 Characteristics of Light
Fig 6-2

• Light has Wave Aspects
• Frequency, ?
• Wavelength, l
• Amplitude

5
6.2 Characteristics of Light
Fig 6-3

• Light has Wave Aspects
• Frequency, ?
• Wavelength, l
• Amplitude
• Intensity

l? c 2.9979 x 108 m/s (6-1)
6
6.2 Characteristics of Light
Fig 6-4
7
6.2 Characteristics of Light

• Light is bent when it interacts with a medium.
• Each wavelength interacting with a medium will
  bend to a different degree.
• If the white light is all the wavelengths of
  visible light, then a rainbow (all the visible
  colors) will be emitted from the prism.

Fig 6-5
Courtesy Bausch Lomb
8
What we perceive as white light is actually a
mixture of ls of visible light.
9
Bulk Interactions
wave properties
Atomic/Molecular
particle properties
10
6.2 Characteristics of Light
The Photoelectric Effect

• Below a characteristic threshold, ?o, no e-s are
  observed.
• 2. Above ?o, KEmax of ejected e- increases
  linearly with ? of light.
• 3. Above ?o, higher light intensity increases
  of ejected e- (not their KE)
• 4. All metals exhibit same pattern, each having a
  different ?o.

Fig 6-6
Fig 6-7
11
6.2 Characteristics of Light

• The Photoelectric Effect
• Below a characteristic threshold, ?o, no e-s are
  observed.
• 2. Above ?o, KEmax of ejected e- increases
  linearly with ? of light.
• 3. Above ?o, higher light intensity increases
  of ejected e- (not their KE)
• 4. All metals exhibit same pattern, each having a
  different ?o.

Conclusions

• Light comes in packets called photons.
• Each photon has an energy proportional to its
  frequency
• (6-2)

Ephoton h? photon

• Plancks constant, h 6.62606876 x 10-34 J/s

12
6.2 Characteristics of Light
Fig 6-8
Ekinetic(electron)h?photon-h?0
(6-3)

• Below a characteristic threshold, ?o, no
  e-s are observed.
• h?photon
• Above ?o, KEmax of ejected e- increases linearly
  with ? of light.
• h?photon h?0
• Above ?o,higher light intensity increases of
  ejected e- (not their KE)
• Higher intensity means more photons

13
6.2 Characteristics of Light
Fig. 6-9

• Light Has Particle Aspects
• Photons have discrete energy described by E h?
• Light and Atoms
• Excited state a higher energy state
• Ground state lowest energy state
• Energy level diagram diagrams depicting atomic
  energy transformations

(6-4)
?Eatom ?h?photon
14
Emission and Absorption
15
(No Transcript)
16
(No Transcript)
17
Atomic spectra

• specific energies correspond to specific orbitals
• can be used to identify an atom
• emission occurs when an electron relaxes to a
  lower orbit
• energy must match the transition

photon energy
18
(No Transcript)
19
6.3 Absorption Emission Spectra

• Emission Spectra

Fig 6-11
20
6.3 Absorption Emission Spectra

• Absorption Spectra

Fig 6-10
21
(No Transcript)
22
6.3 Absorption Emission Spectra

• Quantized Energy

Fig 6-13
23
6.3 Absorption Emission Spectra

• Energy Level Diagrams
• Hydrogen

Fig 6-14
24
6.3 Absorption Emission Spectra

• Energy Level Diagrams
• Mercury

Fig 6-15
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
Bulk Interactions
wave properties
Atomic/Molecular
particle properties
29
Types of energy transfer
30
1885-1962 Neils BohrPost-Doc of Rutherford

• Why are the negative electrons
  not pulled toward the positive nucleus?
• Electrons are in motion around the nucleus
• string - rock
• Electrons exist in defined orbits
• These orbits are quantized

e
e
31
Bohr ModelEnergy Level ModelCloud Model
32
Bohr Model

• Defined the quantized energy states of atoms
• Could predict the spectrum of hydrogen
• Could not be extended to other atoms
• fell apart when more than one electron present
• Could not explain WHY energy was quantized
• Could not calculate the intensities

33
1923 Prince Louis de Broglie

• Light behaves as particles (photoelectric effect)
  and waves (diffraction)
• Proposed
• Matter also has particle and wave properties
• Matter is quantized due to wave nature
• Energy associated with a particle follows a
  similar equation as a photon

34
(No Transcript)
35
(No Transcript)
36
de Broglies Model

• Each orbital is (must be) a whole number times
  the wavelength of the electron
• Destructive interference demands this
• Concept of electrons having a wave nature was
  profound
• His description was to simplistic

37
1924 Erwin Schrödinger

• Agreed with de Broglies concept
• Over New Years wrote the wave eqn. for matter
• Solution to Schrödinger eqn. is a function
• The function2 is the probability of finding an
  electron in a small volume

38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
1925 Werner Heisenberg"Heisenberg MAY have
slept here."

• We see by the interaction of light with an object

• The wavelength must be at least as large as the
  size of the object
• How do we see an electron? IT IS TOO SMALL
• small wavelengths high energy

The smaller m, is the greater the uncertainty
45
6.4 Properties of Electrons
Heisenbergs Uncertainty Principle
The position of an electron cannot be precisely
defined. The more accurately we know position of
a particle, the more uncertain we are about its
motion, and visa versa Uncertainty is a feature
of all objects, but becomes noticeable only for
very small objects.
Fig 6-16
46
