Lecture Problem 17

1
Lecture Problem 17

• Michael Dayringer

2
Problem Statement

• 17a. Identify the following plane

3
Answer

• The intercepts are x2, y2, z1
• This yields the plane (1 1 2)

4
Problem Statement

• 17b. Calculate the planar packing density (in
  atoms/nm2) of this plane in chromium.
• Properties in Table 3.1, pg. 35 of Callister
• Chromium is BCC with R 0.1249 nm

5
Approach

• 1. Find a tessellating plane section
• 2. Count atoms in the section
• 3. Find area of the section
• 4. Calculate PPD

6
Answer

• Our plane section contains 4 atoms
• Plane section is a rhombus
• Area 0.407 nm2
• Planar Packing Density 9.82 atoms/nm2
