International Space Station (ISS) and Space
Transportation System (STS) Overview
2
Overview

• Space Transportation System (STS)
• Solid Rocket Boosters and External Fuel Tank
• Orbiter
• International Space Station
• Module Overview

3
STS

• Solid Rocket Boosters (SRB) provide main initial
  thrust for lift-off.
• Detach at 45 km and parachute to the ground.
• External Tank (ET) provides fuel to Space
  Shuttle Main Engines (SSME) for continued ascent
  into Earth Orbit.
• Detach in LEO and burn up in Earth's Atmosphere

4
Shuttle Orbit

• What do you notice about this picture?

5
Shuttle Orbit

• Shuttle Altitude 250 400 km
• In LEO, Shuttle flies upside-down and
  backwards
• This provides MMOD, Radiation, and Thermal
  Protection
• It is also important for deorbiting

6
Space Shuttle Crew Compartment
7
Space Shuttle Cargo Bay
8
(No Transcript)
9
(No Transcript)
10
