The Haskell Refactorer, HaRe, and its API

1
The Haskell Refactorer, HaRe, and its API

• Huiqing Li
• Claus Reinke
• Simon Thompson
• Computing Lab, University of Kent
• www.cs.kent.ac.uk/projects/refactor-fp/

2
Outline

• Refactoring
• HaRe The Haskell Refactorer
• HaRe Demo
• The HaRe API
• API Demo
• Conclusion and Future Work

3
Refactoring

• What? Changing the structure of existing code
  without changing its meaning.
• Source-to-source
• Functionality-preserving
• Diffuse and bureaucratic
• Bi-directional
• Where and why? Development, maintenance,
• To make the code easier to understand and modify
• To improve code reuse, quality and productivity
• Essential part of the programming process.

4
HaRe The Haskell Refactorer

• A tool for refactoring Haskell 98 programs.
• Full Haskell 98 coverage.
• Driving concerns usability and extensibility.
• Implemented in Haskell, using Programaticas
  frontends and Strafunskis generic traversals.
• Integrated with the two program editors (X)Emacs
  and Vim.
• Preserves both comments and layout style of the
  source.

5
Refactorings Implemented in HaRe

• Structural Refactorings
• Generalise a definition
• e.g.

module Test1 where
module Test1 where g x x (g (x 1))
g m x x ((g m) (x
m)) module Test2 where ?
module Test2 where import Test1
import Test1 h y g y
h
y g 1 y
6
Refactorings Implemented in HaRe

• Structural Refactorings (cont.)
• Rename an identifier
• Promote/demote a definition to widen/narrow its
  scope
• Delete an unused function
• Duplicate a definition
• Unfold a definition
• Introduce a definition to name an identified
  expression
• Add an argument to a function
• Remove an unused argument from a function

7
Refactorings Implemented in HaRe

• Module Refactorings
• Move a definition from one module to another
  module
• e.g.

module Test1(g) where module
Test1 where g x x (g (x 1))

module Test2 where ?
module Test2 where import Test1
import Test1 h y g y
g x x ( g
( x 1))
h y g y
8
Refactorings Implemented in HaRe

• Module Refactorings (cont.)
• Clean the imports
• Make the used entities explicitly imported
• Add an item to the export list
• Remove an item from the export list

9
Refactorings Implemented in HaRe

• Data-oriented Refactorings
• From concrete to abstract data-type (ADT), which
  is a composite refactoring built from a sequence
  of primitive refactorings.
• Add field labels
• Add discriminators
• Add constructors
• Remove (nested) pattern
• Create ADT interface.

10
HaRe Demo
Demonstration of HaRe, hosted in Emacs
11
From concrete data type to ADT
module Tree where data Tree a Leaf a
Node a (Tree a) (Tree a) flatten Tree a -gt
a flatten (Leaf x ) x flatten (Node x l r
) x (flatten l flatten r)
12
From concrete data type to ADT
module Tree where data Tree a Leaf leaf1
a Node node1 a, node2 Tree a,
node3 Tree a flatten Tree a -gt
a flatten (Leaf x ) x flatten (Node x l r
) x (flatten l flatten r)
13
From concrete data type to ADT
module Tree where data Tree a Leaf leaf1
a Node node1 a, node2 Tree a,
node3 Tree a isLeaf (Tree a) -gt
Bool isLeaf (Leaf _) True isLeaf _ False
isNode (Tree a) -gt Bool isNode (Node _ _ _)
True isNode _ False flatten Tree a -gt
a flatten (Leaf x ) x flatten (Node x l r )
x (flatten l flatten r)
14
From concrete data type to ADT
module Tree where data Tree a Leaf leaf1
a Node node1 a, node2 Tree a,
node3 Tree a mkLeaf a -gt Tree a mkLeaf
Leaf mkNode a -gt (Tree a) -gt (Tree a) -gt Tree
a mkNode Node isLeaf (Tree a) -gt
Bool isLeaf (Leaf _) True isLeaf _ False
isNode (Tree a) -gt Bool isNode (Node _ _ _)
True isNode _ False flatten Tree a -gt
a flatten (Leaf x ) x flatten (Node x l r )
x (flatten l flatten r)
15
From concrete data type to ADT
module Tree where data Tree a Leaf leaf1
a Node node1 a, node2 Tree a,
node3 Tree a mkLeaf a -gt Tree a mkLeaf
Leaf mkNode a -gt (Tree a) -gt (Tree a) -gt
Tree a mkNode Node isLeaf (Tree a) -gt
Bool isLeaf (Leaf _) True isLeaf _ False
isNode (Tree a) -gt Bool isNode (Node _ _ _)
True isNode _ False flatten Tree a -gt
a flatten p isLeaf p (leaf1
p) flatten p isNode p (node1 p)
(flatten (node2 p) flatten (node3 p))
16
From concrete data type to ADT
module Tree (Tree,flatten,isLeaf,isNode,leaf1,mkLe
af,mkNode,node1,node2,node3) where data Tree
a Leaf leaf1 a Node node1 a,
node2 Tree a, node3 Tree a mkLeaf a -gt
Tree a mkLeaf Leaf mkNode a -gt (Tree a) -gt
(Tree a) -gt Tree a mkNode Node isLeaf
(Tree a) -gt Bool isLeaf (Leaf _) True isLeaf _
False isNode (Tree a) -gt Bool isNode (Node
_ _ _) True isNode _ False flatten Tree
a -gt a flatten p isLeaf p (leaf1
p) flatten p isNode p (node1 p)
(flatten (node2 p) flatten (node3 p))
17
Generalise a definition
--- Test1.hs module Test1(g) where -- a
generator g x x (g (x 1)) -- Test2.hs
module Test2 where import Test1 h y g y
18
Generalise a definition
--- Test1.hs module Test1(g) where -- a
generator g m x x ((g m) (x m)) -- Test2.hs
module Test2 where import Test1 h y g 1 y
19
Move a definition to another module
--- Test1.hs module Test1() where -- Test2.hs
module Test2 where import Test1 -- a
generator g m x x ((g m) (x m)) h y g 1 y
20
Clean imports
--- Test1.hs module Test1() where -- Test2.hs
module Test2 where -- a generator g m x x
((g m) (x m)) h y g 1 y
21
The HaRe API

• A collection of functions for program analysis
  and transformation extracted from the HaRe.
• Hidden layout and comment preservation in program
  transformation functions.
• Programaticas abstract syntax for Haskell 98
• Strafunskis library for AST traversals
• HaRes API
• make implementing primitive refactorings or
  general program transformations much easier.

22
The HaRe API

• Program analysis API
• Variable analysis
• Property checking
• Module interface (import and exports) analysis
• Module and files
• Program transformation API
• Add/remove/update/swap program entities (e.g.
  declarations, expressions, parameters,
  identifiers, etc.)
• Others
• Parsing/writing
• Name generators, from textual to AST syntax
  phrase,

23
API Demo

• Example refactoring Swap the first two arguments
  of a function, say foo. This affects
• The formal parameters of foo.
• The arguments at the use-sites of foo throughout
  the program (could be a multi-module program).
• The type signature.

24
API Demo
-- swap the first two arguments of a
function swapArgs fileName row col do (inscps,
exps, mod, ts)lt-parseSourceFile fileName
-- from text to program
let pnt locToPNT
fileName row col mod
if isFunPNT pnt mod
then -- deal with the current module
do rlt-applyRefac (doSwap pnt) (Just
(mod, ts)) fileName if
isExported pnt exps then
-- deal with the client modules.
do rs lt- applyRefacToClientMo
ds (doSwap pnt) fileName
writeRefactoredFiles False (rrs)
else
writeRefactoredFiles False r else
error "\nInvalid cursor position!"

-- more code to follow
25
API Demo
--- Inside a module doSwap pnt applyTP
(full_buTP (idTP adhocTP inMatch

adhocTP inExp
adhocTP
inDecl)) where inMatch ((HsMatch loc
fun pats rhs ds)HsMatchP) fun pnt
case pats of (p1p2ps) -gt
do pats'lt-swap p1 p2 pats
return (HsMatch loc fun pats' rhs
ds) _ -gt error
"Insufficient arguments to swap." inMatch m
return m inExp exp_at_((Exp (HsApp (Exp
(HsApp e e1)) e2))HsExpP) expToPNT e
pnt swap e1 e2 exp inExp e
return e


26
API Demo
inDecl (decl_at_(Dec (HsTypeSig loc is c
tp))HsDeclP) isTypeSigOf pnt decl
if length is 1 then do let ts
tyFunToList tp swap
(ts!!0) (ts!!1) ts -- assume no
type synonym is used. else error "This
type signature defines the type of more than one
identifiers." inDecl d return d tyFunToList
(Typ (HsTyFun t1 t2)) t1(tyFunToList t2)
tyFunToList t t
27
API Demo
Demonstration of the swap refactoring
28
Swap arguments
-- Test3.hs module Test3 where sumLength
String -gt Int-gt Int sumLength x y length x
length y -- Test4.hs module Test4 where
import Test3 test3 sumLength "abc" 1,2,3
29
Swap arguments
-- Test3.hs module Test3 where sumLength
Int -gt String-gt Int sumLength y x length x
length y -- Test4.hs module Test4 where
import Test3 test3 sumLength 1,2,3 "abc
30
Conclusion and Future Work

• The API is relatively low-level, but essential
  for implementing program transformations.
• Program appearance preservation hidden in the
  API.
• Together with Strafunski, the API allows to write
  concise source-to-source program transformations
  and their side-conditions.
• A framework for exploring your program
  transformation ideas.
• In the future
• Complete and improve the current API.
• Look for some higher-level API.

31
www.cs.kent.ac.uk/projects/refactor-fp/
