Title: PROCESS IMPROVEMENT


1
PART II
  • PROCESS IMPROVEMENT

2
Chapter 5 Software Process Improvement
Modelszahran
  • Objective
  • To introduces the quality gurus
  • To introduces the concepts of SPI
  • To understand the use of sw process models and
    standards

3
Chapter 5 Software Process Improvement Models
  • Introduction
  • Learning from quality gurus
  • SPI Models
  • Standards and Models for SPI
  • Use of SW Process Models and Standards
  • Summary

4
Introduction
  • SPI should be a lifetime habit of SW
    organizations
  • Once an organization goes through a complete
    cycle of SPI, it should begin the next one and
    repeat this continuously
  • To make continuous SPI a reality in an
    organization, the process culture needs to be
    institutionalized in that organization

5
Introduction
  • To achieve the status of continuous SPI, process
    awareness, attitudes and behaviors need to be
    ingrained in the organization culture.
  • Quality mgt concepts and trends are the roots of
    the sw process maturity and improvement models

6
Learning from the Quality Gurus
  • Quality gurus

Jurans four steps
Shewharts improvement cycle
Crosbys quality maturity grid
Demings way out of the crisis
7
Quality gurus
  • Shewharts improvement cycle(1930s)
  • Walter shewhart proposed a Plan-Do-Check-Act
    cycle for quality improvement
  • 1.Plan
  • Define the problem
  • State improvement objectives
  • 2.Do
  • Identify possible problem causes
  • Establish baselines
  • Test changes

8
Quality gurus
  • 3.Check
  • Collect data
  • Evaluate data
  • 4.Act
  • Implement system change
  • Determine effectiveness

9
Quality gurus
  • Jurans four steps
  • Joseph juran suggests a systematic approach to
    control and improve quality
  • Emphasizes the mgt of quality at all phases in
    the product lifecycle

10
Quality gurus
Quality improvement
11
Quality gurus
  • Demings way out of the crisis
  • Edward demings focus is on the the need for
    mgts long-term commitment to new learning and
    new philosophy in order to achieve transformation
  • Suggested fourteen-point plan for achieving the
    transformation towards continuous improvement
    (distribute in class)

12
Quality gurus
  • Crosbys quality maturity grid
  • Phil Crosby stresses the importance of
    involvement and motivation for everyone in the
    organization
  • Suggested a Quality Mgt Maturity grid that
    specifies 5 stages of maturity and their
    measurement categories (distribute in class)

13
SPI Models
  • Many people contributed to the development of the
    sw process maturity movement but, most of the
    credit goes to one individual Watts Humphrey
  • Humphreys early work suggested 6 steps for
    organizations to improve their sw capabilities

14
SPI Models
  • 1. Understand the current status of their
    development process or processes
  • 2. Develop a vision of the desired process
  • 3. Establish a list of required process
    improvement actions in order of priority
  • 4. Produce a plan to accomplish these actions
  • 5. Commit the resources to execute the plan
  • 6. Restart at step 1

15
SPI Models
  • 5 maturity levels proposed by Humphrey
  • Level 1. Initial
  • Level 2. Repeatable
  • Level 3. Defined
  • Level 4. Managed
  • Level 5. optimizing

16
SPI Models
  • The original sw process maturity model has been
    developed and refined to become the Capability
    Maturity Model (CMM) ? developed by the Software
    Engineering Institute (SEI)
  • CMM ? the most popular model for SPI (discuss in
    next chapter )

17
Staged Vs Continuous Architecture for SPI Models
  • Staged models
  • Comprises a number of maturity levels
  • Each process area being fixed to a particular
    level
  • The key process areas themselves are staged
  • Each key process area is the foundation for the
    next process areas and
  • Each level represents the foundation for the next
    maturity model
  • The result of an assessment againts such models
    usually can be expressed as calibration of the
    organizations maturity
  • well-known example ? CMM

18
Staged Vs Continuous Architecture for SPI Models
  • Continuous Models
  • Individual processes progress continually along
    the maturity scale independently of each other
  • Example in a project, the Project mgt process
    could be at high maturity level, while the
    configuration mgt process could be at lower
    maturity level
  • The result of an assessment against such models
    usually takes the form of a profile for the
    assessed processes
  • Example ? ISO/IEC 15504 model

19
Staged Vs Continuous Architecture for SPI Models
  • Continuous architecture
  • General focus
  • Building process capability for each process
  • Model focus
  • A reference model for rating individual processes
    (process capability)
  • Staged architectures
  • General focus
  • Building organizational capability
  • Model focus
  • Focus on the few issues that need attention to
    progress organizational capability

20
Staged Vs Continuous Architecture for SPI Models
  • Staged architectures
  • Nature of the model
  • Describes a roadmap for process improvement
  • Describes organizational capability
  • Continuous architecture
  • Nature of the model
  • Describes the terrain of process mgt
  • Describes the evolution of individual processes

21
Standards and Models for SPI
  • There are a number of SPI moels and emerging stds
    developed by international organizations,
    industry consortia, large sw purchasers and sw
    developers
  • So far, the most popular model for SPI is the CMM
  • The international std ISO/IEC 15504 was developed
    by the International Stds Organization (ISO) for
    SPI under the acronym SPICE

22
Standards and Models for SPI
23
Use of SW process models and standards
  • SPI roadmaps can be the basis for sw process
    assessments, sw process audits, capability
    evaluations and certification of sw
    subcontractors as well as self-improvement
    programmes
  • Organizations without in-house sw development
    capability can use the stds and models as a basis
    for developing subcontractor evaluation and
    selection criteria for qualifying their sw
    subcontractors

24
Use of SW process models and standards
  • Organizations which do have in-house sw
    development capability can use the stds and
    models to design their own sw processes, and to
    develop a self-assessment method. This can be
    used for assessing the organizations sw
    processes and developing a programme for SPI

25
Use of SW process models and standards
  • Prime contractors who lead a consortium for
    responding to, a specific contract can use the
    stds and models to develop subcontractor
    evaluation and selection criteria for qualifying
    their sw subcontractors. They can also use them
    to assess their own sw processes and develop
    plans for SPI

26
Use of SW process models and standards
  • Subcontractors and suppliers who develop
    packages, subsystems or components of a system as
    part of a consortium have similar uses to
    customer organizations which have in-house
    development

27
Summary
  • Quality mgt concepts and trends are the roots of
    the sw process maturity and improvement models
  • The concepts of quality preached by the quality
    gurus Deming, Juran and Crosby have influenced
    the SW process improvement approaches
  • Watts Humphrey pioneered the adaptation of the
    general quality approaches for software
    engineering
  • Humphreys efforts led to the development of the
    SEIs CMM
