Tennessee Base Mapping Program

1
Tennessee Base Mapping Program

• Mark A. Tuttle,Department of Finance and
  AdministrationOffice for Information Resources

2
TN Base Mapping Program

• Overview
• Status
• Activities
• Next steps

3
TN Base Mapping Program Basic Products

• Ortho Imagery
• Cadastral (Parcel)
• Limited Planimetric Data
• Street Centerlines
• Edge of Pavements
• Ridge Lines
• Hydrography
• Scales are 1100 and 1400

4
TN Base Mapping Program Value Added Products

• High Accuracy DTMs
• Contours
• Building Footprints
• Rooftop Elevations
• Building Points
• Rail Centerlines

5
TN Base Mapping Program Scope

• Continuous coverage for the entire state
• Over 24,000 100 sheets
• Over 11,000 400 sheets
• Over 3.6 million parcels

6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
Project History
1996/1997 2 county Pilot Program conducted by
the Comptroller of the Treasury Maintain Parcel
maps for 80 of 95 counties Maintain Assessment
Database for 90 of 95 counties 1998 Pilot
Program extended to 3 additional
counties Program coordination transferred to
Office for Information Resources
12
TN Base Mapping Program Collaboration

• Funding Model
• Benefits of collaboration
• Cost Share between State, County, Municipal, and
  Federal governments
• Local Shares 25 per county
• State/Federal 75 (the rest!)

13
TN Base Mapping Program Collaboration

• Reduced costs for collection, update, and
  maintenance at startup
• Reducing redundancy of collection
• Higher accuracy data for all users
• Increased ability to integrate data
• Horizontal Integration EPA and USGS
• Vertical Integration Local govt / Census

14
TN Base Mapping Program Collaboration
Anderson County Total Cost 473,500 Local
Share118,400
Local Share 118,400 County 38,700 E911
Board 21,400 City of Oak Ridge
12,500 Oak Ridge Utility Dist 12,500 Powell
Clinch Utility Dist 26,100 City of Clinton
4,700 City of Norris 600 City of
Oliver Springs 1,000 City of Lake City
800
15
TN Base Mapping Program Administration

• Responsibility of Office for Information
  Resources
• Contract holder for production
• Contract execution with local partners
• Fiscal accounting accountability
• Partnership with the Division of Property
  Assessment, Comptroller of the Treasury
• Specifications, implementation, scheduling

16
TN Base Mapping ProgramFunding

• 1999 Legislative Session 5 Million requested
  rcvd. 2.5 M 2.5 M
• 2000 Legislative Session 5 Million requested
  rcvd. 2.5 M 2.5 M
• 2001 Legislative Session 5 Million requested
  rcvd. 2.5 M
• 2002 Legislative Session 5 Million requested
  rcvd. 2.5 M
• Total to date 15 M
• 2003 Legislative Session 2.275 Million

17
TN Base Mapping Program Status
Pilot Counties 1997, 1998
18
TN Base Mapping Program Status
Year 1 Counties 2000
19
TN Base Mapping Program Status
Year 2 Counties 2001
20
TN Base Mapping Program Status
Year 3 Counties - 2002
21
TN Base Mapping Program Status
Year 4 Counties 2003
22
TN Base Mapping Program Status
Cumulative thru January 2004
23
TN Base Mapping Program - Next Steps

• Street centerlines - Intelligent layer
• Current spatially accurate
• No attribute data (dumb data !!)
• How to make it useable
• TN Department of Safety - THP dispatch system
• State E911 Board
• TN Base Mapping Program

24
TN Base Mapping Program - Next Steps

• State ECB Board (E911 Board)
• Assist and coordinate Emergency Response systems
  in a wireless world
• FCC mandate for cellular carriers to provide
  dispatchers with geographic location
• Requires uniform, consistent mapping across
  jurisdiction boundaries

25
TN Base Mapping Program - Next Steps

• State ECB Board (E911 Board)
• FCC mandate for cellular carriers to provide
  dispatchers with geographic location

• Original Implementation Date 12/31/01
• Extended to 12/31/03 (FCC Waivers)
• Currently rolling out/testing

• TNBMP Completion
• Originally 5 years, starting in Feb. 2000
• Extended to 8 years or more

26
TN Base Mapping Program - Next Steps

• State ECB Board (E911 Board)
• Assist and coordinate Emergency Response systems
  in a wireless world
• FCC mandate for cellular carriers to provide
  dispatchers with geographic location
• Requires uniform, consistent mapping across
  jurisdiction boundaries

27
TN Base Mapping Program - Next Steps

• Intelligent street centerlines ISSUES
• Source of geography (TN BMP)
• Source of intelligence attributes
• Public source vs. Proprietary source
• Some combination of Public/Private
• Conflation (transferring the Intelligence to the
  Geography)

28

29

30

31
TN Base Mapping Program - Next Steps

• Intelligent street centerlines ISSUES
• Maintenance and update
• Who has authority to
• Add a street ?
• Assign an address ?
• Notify secondary and tertiary parties ?
• How are updates disseminated to required parties?

32
TN Base Mapping Program - Next Steps

• State ECB Board Wireless Phase II Mapping
  Minimum 911 Software Data Requirements
  February 1, 2002
• Software functionality, must display and use
  TNBMP data
• Minimum layers defined
• Cost recovery requirements
• Suggested deployment (GDT data via the community
  update program, then TNBMP)

33
TN Base Mapping Program - Next Steps

• State ECB Board Wireless Phase II Mapping
  Minimum 911 Software Data Requirements
  February 1, 2002
• Minimum Layers defined
• Street centerlines with complete address
  attributes
• Point landmarks churches, schools, hospitals,
  cemeteries, government bldgs.
• Area landmarks parks, airports, military bases
• Fire Hydrants and Stations
• Water features
• Administrative boundaries city, county, state
• ESN boundaries
• Digital Ortho photos

34
TN Base Mapping Program - Next Steps

• TNBMP/ECB Partnership ISSUES
• Timing (long term TNBMP project versus immediate
  need of the ECB)
• Data integrity (or lack thereof for the TNBMP)
• Spatial consistency (across jurisdictional
  boundaries)
• Maintenance/Updates (ie Custodial
  Responsibilities)

35
TN Base Mapping Program - Next Steps

• TNBMP/ECB Partnership
• Formalized by vote of the ECB January 15, 2003
• OIR/GIS Services to facilitate and manage the
  task of creating uniform, consistent Street
  Centerlines, concurrent with TNBMP Production
  efforts
• Phase 1 acquire statewide license (State,
  County, Municipal agencies) to GDTs Dynamap,
  covering the entire State, plus one county buffer
  outside the State
• OIR/GIS Services to disseminate to local
  districts
• Phase 2 transfer intelligence to TNBMP
  centerlines, for counties complete, then
  concurrently with future production
• OIR/GIS Services to disseminate to local
  districts either centerlines, or the entire
  TNBMP data set, should there be full local
  participation

36
TN Base Mapping Program - Next Steps

• How ..
• Access and disseminate
• To agencies
• To public
• For free (?)
• For fee (?) (premium services)

lt 3.5 terabyte data set gt
37
TN Base Mapping Program - Next Steps
38
TN Base Mapping Program - Next Steps

39
Thank You!!

• Contact Information
• Mark Tuttle, Director, GIS Services312 8th
  Avenue North16th Floor, WRS Tennessee
  TowerNashville, TN 37243-0288
• E-mail mark.tuttle_at_state.tn.us
• Phone [phone]

See us on the WEB too http//gis.state.tn.us
