Norovirus: Nature

1
Norovirus Natures Perfect Pukeogenic Pathogen

• Todd F. Hatchette MD FRCPC
• Director, Virology and Immunology
• QEII HSC
• November 27, 2008

2
Overview

• Case
• Outline features of Norovirus
• Epidemiology
• Transmission
• Clinical features
• Infection control concerns

3
Case

• Thursday 1230 AM index case awoken from sleep
  with projectile vomiting
• Distressed
• Multiple vomiting episodes overnight
• Relocated to more comfortable location
• By 800AM was fatigued but otherwise well

• Friday 1700 hrs
• Patient 2 feels light headed and fatigued
• Nausea and vomiting begin at 1745
• Associated with
• profuse watery diarrhea
• Fever
• Chills
• Vomiting resolves by 0300hrs
• Diarrhea resolves next day

4
(No Transcript)
5
Caliciviridae

• Members of the Caliciviridae
• (Calyx Latin for cup or chalice).
• sense, single-stranded RNA genome.
• EM structured.
• Size 26-40 nm

• Had been referred to by names are derived from
  the geographic area they are discovered
• Small round-structured virus (SRSV)
• Now classified into genogroups

6
Caliciviridae

• New classification four genera
• Norovirus Found in human, cows and pigs
• Most common cause of human illness
• Includes the Norwalk-like agent
• Sapovirus Found in Humans and pigs
• Saporo-like agents
• Vesivirus
• Animal viruses feline
• Lagovirus
• Mainly in rabbits/hares. Rarely has been
  isolated in humans

7
The Many Faces of Norovirus
(Zeng et al., 2006 Virology 346312-323)
8
Caliciviridae

• Genetic variation occurs by recombination

• Occurs at the junction of the NS cassette and
  capsid regions

• May permit virus to escape host immunity

9
Norovirus - Epidemiology

• Most common cause of sporadic gastroenteritis
• 23 million infections each year in the US
• Causes up to 50 of all food borne outbreaks
• Accounts for 54 of Gastro in Hospitals in UK
• Cost 184 million (US) between 2002-2003
• Common cause of travelers diarrhea
• Since 2002 PHAC has had approximately 300-400
  outbreaks each year
• High attack rate

10
History

• Zahorsky 1929 describes winter vomiting disease
• Outbreaks of non-bacterial gastro (NBG)
• Gordon et al 1940s
• Collected stool samples from institutional
  outbreak of NBG filtrate fed to volunteers
• Showed it could be serially passed in humans
• Could not isolate pathogen in eggs

11
History

• Norwalk Ohio, 1968
• Outbreak of winter vomiting disease in an
  elementary school
• 50 of students and teachers were infected
• Etiology could not be identified but stools saved
  and filtrates used in subsequent human
  experimentation
• Kapikian et al., 1972
• Able to visualize SRGV in EM from volunteers
  infected with filtrate from Norwalk outbreak

12
Winter Vomiting disease
Lopman et al., 2003 BMC Public Health
13
Why could it be seasonal?

• Possibly related to virus stability
• Social behaviors that increase the likelihood of
  person-to-person transmission
• Winter pressures on healthcare

14
Not Just a Winter Disease
Frankhauser et al., 2002 JID 1861-7)
15
Not Just a Winter Disease
Frankhauser et al., 2002 JID 1861-7)
16
Norovirusclinical presentation

• Incubation 12-48hrs
• Onset abrupt or gradual
• adults commonly presents as explosive projectile
  vomiting, diarrhoea or both but either can occur
  alone
• myalgias, malaise and occasionally headaches
• low grade fever in 50
• Illness lasts 12-60 hrs

17
Clinical Presentation

• Retrospective sturdy looking at large food borne
  outbreak in children and staff at 30 day care
  centers in Sweden (Gotz et al., 2001 CID
  33622-628)
• Diarrhea more common in adults
• Vomiting is more common in children
• Prospective community cohort study in the
  Netherlands (Rockx et al., 2002 CID 35246-253)

18
Rockx et al., 2002
19
Duration of Shedding
Correlates with age but not duration or severity
of symptoms
Rockx et al., 2002
20
Duration of Shedding

• 71 cases of gastroenteritis, 71 children were
  positive for NV by RT-PCR (Murata et al. 2007 Ped
  Infect Dis J 2646-49)

• Healthy Pediatric patients can shed for up to 47
  days

21
Shedding and Immunosuppresion

• Up to a year in pediatric cancer patients (Ludwig
  et al., 2008 J Med Virol. 801461-1467)

(Siebenga et al., 2008 JID 994-1001)
22
Norovirus Clinical Presentation

• Clinical criteria for recognizing Norovirus
  outbreaks (Kaplan et al., 1982 Turcios, et al.
  2006)
• (99 specific/68 sensitive)
• Short incubation period (24-48 hours)
• Short symptomatic illness (12-60 hrs)
• High frequency of vomiting (gt 50)
• Absence of bacterial pathogens
• Symptoms vary patient to patient

23
Norovirus Transmission

• Transmission
• Fecal Oral
• Direct contact
• Contaminated fingers/hands
• Aerosol

24
Norovirus - Transmission

• Transmission associated with
• Contaminated food
• 9.2/13.8 million cases of food related illness in
  US secondary to calicivirus
• Any food not served hot (56oC for 30 min before
  preparation) can be a source of infection.
• Person to person contact
• Oysters
• NV can bind to the carbohydrates in the gut of
  shellfish
• Sick crew members contaminated the oyster field
• Contaminated water
• Genome has been identified in bottled water
• Mode of transmission sometimes not clear

25
Outbreaks of Gastroenteritis Reported to CDC Jan
1996Nov 2000N348
Mode of transmission
Settings
MMWR 2001 50 RR-9
26
Food as a source

• Calicivirus stable on food for up to 1 week
  (Mattison et al., 2007 J Food Pro 170500-503)

Room temp
4oC
27
Why are they so Infectious? Characteristics that
facilitate their spread during epidemics

• Low infectious dose
• Prolonged asymptomatic shedding
• Environmental stability
• Survives lt10ppm Chlorine, freezing and heating to
  60 oC
• Strain diversity
• Multiple antigenic and genetic types
• Incomplete immunity

MMWR 2001 50 RR-9
28
How Infectious is it?

• Human challenge studies are limited because the
  starting dose is unknown
• Try to quantify by EM but many particles are in
  aggregates
• Estimated that 49 of people exposed to a single
  virus particle will get infected. (Teunis et al.,
  2008 J Med Virol 1468-1476)

29

• The higher the dose the more likely people
  developed illness

(Teunis et al., 2008 J Med Virol 1468-1476)
30
Norovirus Persistence on Surfaces
(Clay et al., 2006 AJIC 3441-43)
31
Norovirus and the cruise ship industry - the
ship of stools
The Carnival of crap

• 2002 21 outbreaks of acute gastroenteritis on
  17 cruise ships reported to CDC
• 9 were laboratory confirmed cases of Norovirus
• 9 unknown
• 26 land-based outbreaks reported during the same
  time

32
Norovirus and the cruise ship industry

• 3/5 outbreaks described in the MMWR (200251(49)
  1112-1115) had repeated outbreaks on subsequent
  cruises after disinfections in accordance with
  CDC recommendations
• Required aggressive cleaning and sanitizing
  before outbreaks stopped

33
Caliciviridae diagnosis

• Diagnosis
• Culture not successful
• EM
• laborious and relatively insensitive (requiring
  106 to 107 particles/g or ml of feces).
• RT-PCR
• Which gene to target?
• Testing 5 specimens appears to be ideal (Fisman
  et al, 2008)

Recent 3D culture has some success (Straube et
al., 2007 EID 13396-403)
34
Norovirus pathogenesis

• Pathogenesis is not clear
• Lesions in the small bowel
• Broadening and blunting of intestinal villa
• Transient malabsorption of sugars and fats
• Decreased activity in brush border enzymes

(Hutson et al., 2004 Trends in Microbiol.
12279-287)
35
Norovirus

• Long term immunity is not consistent and usually
  short lived
• Immunity appears to be genotype specific
• Paradoxical association with antibody level
• Suggests genetic factors

36
Norovirus and Human Resistance
Lindesmith et al., 2003 Nat Med 9548-553
37
Tan and Jiang, 2007
38
Norovirus and Mortality

• Illness is generally self limiting
• Elderly can succumb to complications of
  dehydration
• Recent US estimates
• 310/23 million die each year
• 553/1.4 million cases of Salmonella die each year
• Others estimate lower (0-3.7 deaths/year)

39
Norovirus and Mortality

• Case fatality in UK - 7.5/10000 cases
• Recent modeling data suggests that from 2001-2006
  there were 228 deaths from norovirus related
  infections in England and Wales

• Represents 20 of deaths from infectious diseases
  in gt65 yrs

(Harris et al., 2008 EID 141546-1552)
40
Prevention

• Good hand hygiene
• Alcohol based hand washes? - controversial
• Good food hygiene
• Discard stool vomit and clean with a bleach
  solution
• H2O2 products can also be used
• Patients to remain off work for 72 hrs after
  symptoms resolve

41
Are Noroviruses Emerging(Widdowson et al.,
2005 EID 11735-737)

• gt2500 foodborne outbreaks of norovirus 1995-1997
• lt1 attributed to norovirus
• 68 were unknown etiology
• Today
• Responsible for up to 50 of food borne outbreaks
  in US
• Detected in 35 of persons with sporadic
  gastroenteritis

42
The other Pandemic

• Genogroup II.4
• First identified in mid 1990s
• Responsible for significant outbreaks in Nursing
  homes in US and acute care facilities in Europe
• Continues to evolve

Laboratory Reports of Norovirus-Positive
Specimens in England and Wales, 1991 to 2006
Lopman et al., 2008 PLoS Med 187-189
43
How did to arise?

• Could new variants arise in chronically infected
  patients?

Siebenga et al., JID 2008 198994-1001
44
Siebenga et al., JID 2008 198994-1001
45
Norovirus the Gastric Flu

• Evidence for genetic drift - the surface exposed
  carbohydrate binding domain is under heavy
  immunologic pressure
• Examined 176 full length GII.4 sequences from
  1987-2005
• Found 5 major clusters

Lindesmith et al., 2008 PLoS Med 5269-289
46
Norovirus the Gastric Flu
Den Haag (2006)
Sakai (2004-2006)
Hunter (2004-2006)
Lindesmith et al., 2008 PLoS Med 5269-289
Farmington Hills (2002-2004)
Grimsby cluster (1995-2002)
Camberwell (1987-1995)
47
Norovirus the Gastric Flu

• Genetic drift of H3 Influenza A from 1983-1994

Bush et al., 1999 Science 2861921-1925
48
Norovirus the Gastric Flu

• Evidence of positive selection in AA in the P2
  protein (surface exposed region) but no single
  pattern was discernable
• VLPs containing representative samples had
  different binding affinities with different
  antigens

49
Evidence for Zoontic transmission

• Noroviruses known to infect pigs, cattle, mice
• Cattle and pigs can be infected experimentally
  with human strains
• Human norovirus GII.4 was detected in fecal
  samples from cattle and swine and from retail
  meat samples (along with animal samples)
  (Mattison et al., 2007 EID 131184-1188)
• Genetic diversity can occur through recombination

50
Natures Perfect Pukeogenic Pathogen

• The ultimate goal of a virus is not to kill its
  host but to find a new host to infect so that it
  can replicate its genetic material. What better
  way to do this than to induce explosive diarrhea
  and vomiting.
