FLASH Future March 21, 2005

1
FLASH FutureMarch 21, 2005

• Anshu Dubey

2
FLASH3 Motivation

• The FLASH Center wont be around forever
• Put FLASH in a position to be a community
  developed and supported code
• First opportunity to focus on design rather than
  capabilities

3
FLASH 3 Goals

• To create robust, reliable, efficient and
  expandable code, that stands the test of time and
  users
• Build upon lessons learned in FLASH 2
• Simplify the architecture
• Decentralize data management
• Define rules for inheritance and data movement
• Eliminate assumptions
• Incorporate newer software engineering practices
• Design by contract / Unit test
• Exploit technologies
• Tools
• Create a community code
• Easy to add new functionality
• Policy for external contributions

4
The Design

• Great effort to get the design right
• Individual proposals
• Discussed, iterated upon
• Detailed specifications worked out
• Prototyped and tested
• Keeping track of design documents
• Digital photographs of the board
• CVS repository of the design specification
  proposals and documents
• The documents in the repository should eventually
  become basis for developers guide.
• Some parts still dynamic.

5
Design Trade-offs

• Determine the scope
• How deep should the changes be
• Infrastructure
• Algorithms
• Design and Implementation Methodology
• Transition of modules/units from FLASH2 to FLASH3
• Reconcile the divergence

6
The Implementation Plan

• Initially concentrate on the Framework
• Carried out independently of FLASH2
• No disruption for people using FLASH2 for science
  runs
• Move a minimal set of units from FLASH2 to FLASH3
• Dependencies dictate the set
• Those units frozen in FLASH2
• If unavoidable, changes in those units must be
  carefully synchronized
• Evaluate the algorithms in the unit and redesign
  as needed
• Repeat until all units done

7
Unit Testing

• Goal have each module be testable as
  independently as possible from the rest of the
  code
• Tests should be very simple, light on memory.
• Should eventually hook up with the FLASH test
  suite
• What are obstacles?
• Most modules have some knowledge of other units
• Most modules need some form of Grid

8
Architecture Lessons from FLASH 2
Example Decentralize data management
FLASH2
source
source
FLASH3
dbase
mesh
Grid
amr
amr
UG
UG
UG
AG
PM data .
UG data
UG func
PM func.
PM func.
UG data
UG func
PM data .
9
Eliminate duplicate code
IO
IO
checkpoint.F90 Calls generic methods open_file() w
rite_data()
Common
UG
AMR
hdf5
netcdf
hdf5
netcdf
hdf5
netcdf
Hdf5_open()
ncmpi_open()
checkpoint()
checkpoint()
checkpoint()
checkpoint()
Lots of duplicate code!
10
Infrastructure Mesh Packages in Flash
Paramesh

• FLASH original design was Paramesh specific
• Block Structured
• Fixed sized blocks
• Specified at compile time
• Every section of the code assumed knowledge of
  block size
• Removing fixed block size requirement opens the
  door for other mesh packages like a uniform grid,
  squishy grid and patched base grid

Relaxing the fixed block size restraint in Flash
makes the code more flexible and robust, however
it requires the code to be modified at the
deepest levels
11
New Capabilities
Patch Based Mesh (planned)
Uniform Grid

• one block per proc
• No AMR related overhead

• Adaptive mesh with variable block size
• Allows mesh to zoom in on specific areas
  without having to refine surrounding areas

12
New Capabilities - Squishy Grid (Planned)
Squishy Grid

• Non-uniform, non-adaptive grid
• No overhead from AMR
• Useful in cases where high levels of resolution
  are needed in fixed areas of the domain

or
13
FLASH 3 Architecture
Four Cornerstones
Setup tool assemble simulation
Config files Tell setup how to Assemble simulation
Unit Architecture API Inheritance Data management
Driver Organize interactions Between units
14
FLASH3 Units
Infrastructure
I/O
Runtime inputs
Grid
monitoring
Physics
Profiling
Hydro
MHD
Driver
Burn
Gravity
Runtime viz
Simulation
15
Unit Architecture
Grid
Data Module

• Top level
• API
• Unit Test

block data time step etc
Wrapper
Driver
Kernel
16
Unit Hierarchy
API/ Stubs
Common API Impl
API impl
API impl
API impl
Wrapper
Wrapper
Wrapper
kernel
kernel
kernel
17
Building an Application
Runtime Inputs
Driver
Grid
mesh
Simulation/ setup
I/O
Physics
Profiler
18
FLASH3 Framework

• How do you get the Framework out of FLASH 3?
• Include the source tree up to the top level of
  each Unit.
• Stub implementations
• Config files
• Include setups/default
• Include the setup tool
• Include the Driver
• Unit tests could be included, but have no meaning
  with stubs

19
Move a Unit

• Create a Unit_data Fortran module to store data
  needed from other units in the code.
• Create storage in Unit_data for all variables
  that kernel gets through either runtimeparameter
  or dbase calls.
• Eliminate the first call constructs, move them
  to the Unit_init.
• Unit_init fills up Unit_data.
• Use wraper functions to fill up the remaining
  variables in Unit_data.

20
Moving a Module Example PPM Hydro

• PPM Hydro
• And its dependencies (for example Eos)
• Reasons
• Central Module
• Majority of applications need it
• Exercises the FLASH3 design
• FLASH3 cannot be meaningfully tested without it
• Challenges
• Legacy, with many assumptions
• Has too much knowledge of the mesh
• Very difficult to encapsulate
• Eos even more challenging

21
FLASH 3 Status

• The framework works, and can be separated out
• The following units are implemented
• Grid can switch between PM2, PM3 and UG
• PM2 and UG work in parallel
• Driver, RuntimeInputs, Profiler
• Hydro, Gamma Eos, Materials
• Dummy MPI
• IO
• Simple application work
• Compiles and runs on multiple platforms
• Test suite is up and running
• Will be released to users within the center soon.
• A Beta version might be released by the end of
  the year.

22
Impact on user

• We hope it wont be painful
• Lots of Kernels will be the same as in FLASH2
• A user, who has modified source files in setup
• should be able to read Unit API documentation to
  clearly determine how to make the code compatible
  with FLASH3 or
• Look at the new source file implementation for
  how to start on converting to FLASH3
• If youre in the process of developing a deep
  functional module for FLASH2 that you want to
  contribute, talk to us now

23
Tools

• The Diagnostic Tools
• Memory diagnostic tool
• Profiling tools
• Runtime viz
• Post Processing Tools
• Fidlr
• FLASH view
• Documentation Tools
• Benchmark management tool
• Robodoc for web interfaced documentation

24
Tools Snapshots
25
The Future

• The next few steps
• Benchmark and profile the performance
• Move efficient units in FLASH 2 to FLASH 3
• Evaluate algorithms in units that are not
• With some help select the appropriate ones
• Implement them
• The still open major design issues
• Gravity
• Particles
• Look at load balancing with non-uniform work per
  block

26
Load Balancing
Work in blocks

• Load balanced in number of blocks
• Work concentrated in few blocks
• CPU snapshot shows one processor idle for the
  most part
• Work weighted load balancing needed.

Distribution of blocks
27
which brings us to

• Discussion and Questions
