Zio TR70 LCD Wall Module

1
Zio TR70 LCD Wall Module

• Customer Training

2
Zio TR70 LCD Wall Module Feature Brief

• Used with the enhanced Spyder Controller with
  Sylk
• Two-wire polarity-insensitive bus interface
• Very large backlit display
• Pull down and view almost any point in the Spyder
  controller
• Customizable home screens
• Balance systems from the wall module
• Use Spyder tool to customize your configurations
  and home screen
• Multiple override options
• Easy to use, borrows from Honeywell homes
  thermostat design
• Only two models do it all (one offers humidity)

3
Zio TR70 Customizable Home Screens

• Customizable Home screen
• Home screen choices are created in the S-Bus Wall
  Module function block in the newest Spyder tool
  and downloaded to the TR70. Multiple home
  screens can be downloaded with one set as
  default.
• From the Home screen, the Tenant can change the
  setpoint, fan speed and/or initiate override, if
  configured. They can also view or view/change
  other parameters using the View More key if
  desired. View More parameters are configurable.
• Some sample home screens shown below

Mix and match options for the home screen as
desired
4
Zio TR70 Contractor Mode

• A contractor mode can be accessed.
• Enter and exit the contractor mode by pressing
  Up, Down, and Middle softkey.
• In the contractor mode, you can choose the home
  screen, select parameter access to tenant (Yes or
  No as desired), and view/change parameters.
• Parameters may include virtually any point in the
  controller. Scheduling is not accessible.
• Some sample parameter screens below.

Use the tool to set up how you want the parameter
displayed
5
Wiring and Address Dial of Zio
Sylk Bus Address Dial Leave setting at
1 (Currently the bus can accept only 1 device at
a time)
Four Terminals 1 and 2 for network jack
(optional) 3 and 4 for Sylk Bus (to controller
S-bus terminals)
6
Configuration of Zio

• All configuration of the Zio Wall Modules is done
  through the S-bus Wall Module Configuration tool
• This tool is embedded in the Sylk Enhanced Spyder
  Tool, Version 2.0.0 as of the date of product
  release in Oct 2008.
• Download the latest version at the Honeywell
  Buildings Forum.

Download here
7
Drag S-Bus WM block onto wire sheet
8
Wizard General Settings Tab
9
Wizard Categories and Parameters Tab
10
Wizard Categories and Parameters Tab
11
Wizard Categories and Parameters Tab
12
Wizard Memory Usage
13
Wizard Memory Usage Window
14
Wizard Home Screen Options
15
Wizard Occupancy and Override
16
Wizard Occupancy Time Interval
17
Wizard Fan Command
18
Wizard System Status and Command
19
Wizard System Status and Command
20
Wizard Preview
21
Wizard Preview
22
SBus WM Block imbedded in Venom VAV App
23
TR70 Wall Model
