Intelligent Power Switches I'P'S'

1
Intelligent Power Switches (I.P.S.)
2
I.P.S. Features
Short circuit and Over current Protection
Under-voltage and Over-voltage Protection
ESD Protected
I.P.S.
IEC 61131-2 Compliant
Loss of ground Protection
Open Load detection
Fast Demagnetization
Over-temperature Protection
3
I.P.S. APPLICATION FIELDS

• - Programmable Logic Controller
• - Peripheral I/O
• - Textile Machines
• - Alarm and Security Systems
• - Vending Machines
• - Car systems
• - Robotic
• - Industrial Automation

4

• WHAT IS AN INTELLIGENT POWER SWITCH?

12V lt Industrial Supply Rail lt 35V

• Fully Protected Power Switch
• Designed for Harsh Environment
• Capability to drive any kind of Load
• Exhaustive Diagnostics

Supervisory Functions
Logic Diagnostic
References Supply
Input
Protected Driver
Input Stage
Out
5
CURRENT LIMITATION

• Output current internally limited
• Products like VN808, VN330SP, L6375 etc.
• Current limitation externally programmable
• L6377 0.1A lt Isc lt 1A
• L6370 0.3A lt Isc lt 3A
• Non dissipative short circuit protection
• L6376 Ton and Toff external independently
  programmable
• L6370/7 Ton ext. progr. Toff 64Ton

•



6
OPEN LOAD DETECTION

• The diagnostics is active when the load is
  disconnected

7
DIAGNOSTICS
DC Supply bus
to mP
Diag
GND

• Open Drain Diagnostic for Wired OR
• More diagnostic outputs and one opto-coupler can
  be used to signal the device(s) status

Diag
GND

•



8
HIGH NOISE IMMUNITY INPUT STAGE

• High noise immunity 200mV hysteresis
• High impedance
• Multi-Standard Link
• Operative range
• 0 to 40V for L6376
• -7 to 15V for L6370/7/5

•



9
EMC Compliance

• IEC 61000-4-4 Burst test Level 4 (4kV)
  Input/Output ports Power supply lines
• IEC 61000-4-5 Surge test Level 3 (2kV)
• Output ports Power supply lines by
• IEC 6000-4-6 Conducted disturbances Level 3 (10V)
  Input/Output ports Power supply lines by

Transil diode
Capacitor 10nF on output channel
10
I.P.S. versus Relays Benefits
1. Compactness, Space Saving 2. No Contacts
Wear-out !!?? 3. Protections and Diagnostics On
Chip 4. Very High Reliability !!!!??? 5.
Competitive Prices !
Relay
I.P.S.
11
Intelligent Power Switches family portrait
ViPower
VN808/CM/SR
VN330SP
Quad HSD 200m? PSO10
Octal HSD 160m? PSO36
VN340SP
VNQ860
VN540
Quad HSD 270m? SO28/PSO36
Single HSD 2A Full Diagnostic PSO20
Single HSD 60m? PSO10/PWATT
VN751
L6370
MultiPowerBCD
Single HSD 0.5A SO20/DIP8
Single HSD 50m? PPAK/SO8
L6376
L6375
Single HSD 0.5A SO14/DIP8
L6377
Quad HSD 0.5A DIP20/P-SO20
TDE1897
TDE1898
Single HSD 0.5A Full Diag. SO20/DIP8
Bipolar
Single HSD 0.5A Full Diag. DIP8/SO14
TDE1798
TDE1737
TDE1767
Single LSD 0.5A SO14/DIP8
TDE1747
TDE1708
HSD/LSD 0.3/0.5A for proximity sensors SO8/QFN4X4
TDE1707
In development
12
VIPower Technology I.P.S. spectrum
13
VIPower Technology I.P.S. Features protections
14
VIPower M0 technology
15
VN808 150mW Octal HSD
16
VN808 150mW Octal HSD
17
VN808CM Low Threshold Octal H.S.D
18
VN808CM Low Threshold Octal H.S.D
19
VN808 Application Circuit
Filter for bus inductance effect., make supply
voltage stable and avoid undervoltage shut down
Protection for IEC 61000-4-5 Surge test suggested
1,5KE39xx
Optional protection for Vcc disconnection.
EMC Filter
.
.
.
.
.
.
.
.
.
Vcc24V - 28,2V IEC1132
22µF
100nF
.
Vin1
Load 1
Imax 80µA
Load 2
10nF
Vin2
Vcc/2 compatible inputs
Load 3
Protection against IEC 61000-4-6 Current
injection Test
Vin3
VN808
Vin8
Status
Load 8
Status output current from 2 to 4 mA
10W protection against Vcc disconnection
on Inductive loads
RGND
PROTECTIONS INCLUDED IN THE DEVICE IEC
61000-4-2 ESD Test better than 2000V Human body
model IEC 61000-4-4 Burst Test
20
Thermal Behavior
All channels short circuit

• Thermal tests
• All channel short circuit, fswitching 0.5 Hz,
  Vcc28V, during 72 hours and temperature ambient
  25C.
• All channel short circuit, fswitching 0.5 Hz,
  Vcc28V, during 8 hours and temperature ambient
  85C.
• All channel short circuit, fswitching 0.5 Hz,
  Vcc28V, during 8 hours and temperature ambient
  -25C.
