WebEnabled Decision Support Systems

1
Web-Enabled Decision Support Systems

• Access Tables Building Data Foundation

Prof. Name
name_at_email.com Position
[phone] University Name
2
Overview

• 6.1 Introduction
• 6.2 Hands-On Tutorial Creating Access Tables in
  the Datasheet View
• 6.3 Hands-On Tutorial Creating Access Tables in
  the Design View
• 6.4 Field Data Types
• 6.5 Field Properties
• 6.6 The Lookup Wizard
• 6.7 Defining a Primary Key
• 6.8 Creating Access Tables by Using Import Wizard
• 6.9 Working with Table Properties
• 6.10 In-Class Assignment
• 6.11 Summary

3
Introduction

• Access stores and relates its data in tables
• Fundamental and foundational element of
  relational databases
• Datasheet View
• Two-dimensional grid
• Columns data fields
• Rows records

The Student Table of the University Database
4
Creating Access Tables

• Methods of creating Access tables
• Datasheet View
• Design View
• Table Wizard
• Import Wizard
• Link Table

New Table Dialog Box
5
Overview

• 6.1 Introduction
• 6.2 Hands-On Tutorial Creating Access Tables in
  the Datasheet View
• 6.3 Hands-On Tutorial Creating Access Tables in
  the Design View
• 6.4 Field Data Types
• 6.5 Field Properties
• 6.6 The Lookup Wizard
• 6.7 Defining a Primary Key
• 6.8 Creating Access Tables by Using Import Wizard
• 6.9 Working with Table Properties
• 6.10 In-Class Assignment
• 6.11 Summary

6
Hands-On TutorialCreating Tables in the
Datasheet View

• One of the simplest and quickest ways to build
  new tables in Access
• Manually enter data in the Datasheet View
• Limitations
• Primary key definition
• Data types and validation
• How-to Create Tables in the Datasheet View
• Open Access using the Start menu.
• Choose File New from the Main menu to open the
  New File Task Pane. Choose the Blank database
  option to create a new database file.
• Select the Table item in the Object Bar and
  choose the Create table by entering data option
  in the Database Window.

7
Hands-On Tutorial Creating Tables in the
Datasheet View (cont.)

• Enter the first record in the table as shown
  below. Double-click the column headings to rename
  them.
• Enter the remaining records in the subsequent
  rows of the grid.
• Save table as tblCollege by choosing File
  Save As from Main menu. Click No to ignore the
  warning regarding the lack of a primary key.

Creating the College Table in Datasheet View
8
Overview

• 6.1 Introduction
• 6.2 Hands-On Tutorial Creating Access Tables in
  the Datasheet View
• 6.3 Hands-On Tutorial Creating Access Tables in
  the Design View
• 6.4 Field Data Types
• 6.5 Field Properties
• 6.6 The Lookup Wizard
• 6.7 Defining a Primary Key
• 6.8 Creating Access Tables by Using Import Wizard
• 6.9 Working with Table Properties
• 6.10 In-Class Assignment
• 6.11 Summary

9
The Design View

• The Design View is a comprehensive, powerful, and
  flexible tool to create tables
• Design Grid (top half)
• Define fields, data types, and descriptions
• Field Properties (bottom half)
• Set validation and appearance preferences

The Department Table in Design View
10
Hands-On Tutorial Creating Tables in the Design
View

• How-to Create Tables in Design View
• Double-click the Create table in Design View
  option in the Database Window to open a new table
  in the Design View.
• Specify the fields of the department table on
  individual rows in the Design Grid.
• Select the DeptID row by clicking on the row
  selector. Right-click and choose the Primary Key
  option to assign DeptID as a primary key.
• Save the table as tblDepartment.

11
Overview

• 6.1 Introduction
• 6.2 Hands-On Tutorial Creating Access Tables in
  the Datasheet View
• 6.3 Hands-On Tutorial Creating Access Tables in
  the Design View
• 6.4 Field Data Types
• 6.5 Field Properties
• 6.6 The Lookup Wizard
• 6.7 Defining a Primary Key
• 6.8 Creating Access Tables by Using Import Wizard
• 6.9 Working with Table Properties
• 6.10 In-Class Assignment
• 6.11 Summary

12
Field Data Types

• Each column of a table is designed to contain a
  specific data type
• Access offers 10 different data types
• Text, Memo, Number, Date/Time, Currency,
  AutoNumber, Yes/No, OLE Object, Hyperlink, and
  Lookup
• Proper selection of data types at the design
  stage can greatly affect the performance and
  functionality of a database
• Considerations for selecting field data types
• Storage space
• Application requirements

13
Access 10 Data Types

• Text
• Default data type
• For alphanumeric data
• Not used in calculations
• Memo
• Large text data
• Up to 65,536 bytes (18 pages of text)
• Number
• For arithmetic operations
• Date/Time
• Dates, times, and combinations of the two
• Currency
• Money values

14
Access 10 Data Types (cont.)

• AutoNumber
• Automatically generates sequential numbers
• Mainly used for primary key fields
• Yes/No
• Boolean data
• Yes/No, True/False, and On/Off
• 1 bit per field
• OLE Object
• Object Linking and Embedding
• Complex data from other Windows-based
  applications
• Hyperlink
• Links in Uniform Resource Locator (URL) format
• Lookup
• Foreign keys

15
Overview

• 6.1 Introduction
• 6.2 Hands-On Tutorial Creating Access Tables in
  the Datasheet View
• 6.3 Hands-On Tutorial Creating Access Tables in
  the Design View
• 6.4 Field Data Types
• 6.5 Field Properties
• 6.6 The Lookup Wizard
• 6.7 Defining a Primary Key
• 6.8 Creating Access Tables by Using Import Wizard
• 6.9 Working with Table Properties
• 6.10 In-Class Assignment
• 6.11 Summary

16
Field Properties

• Every data field has its own properties that
  control
• Storage
• Formatting
• Validation
• Field Size
• Length of text and numeric data types
• Types
• Byte, integer, long integer, single, double,
  replicationID
• Format
• On-screen and printed data displays
• For all data types (excluding OLE Object)
• Particular options for Number, Date/Time, and
  Yes/No data types

17
Field Properties (cont.)

• Input Mask
• Restricts the input to a pre-defined format
• Available for Text, Number, Date/Time, and
  Currency data types
• Caption
• Allows inclusion of more descriptive or logical
  field names
• Required
• Indicates if the data must be entered for the
  column
• Validation Rule and Validation Text
• Limits what user can enter into the tables
• Indexed
• Indicates whether or not a field has been indexed

• Creates list of ordered field values for lookup

18
Using the Input Mask Wizard

• Goal
• Mask a phone number field in the format (xxx)
  xxx-xxxx
• How-to Use the Input Mask Property and Input
  Mask Wizard
• Open the tblDepartment table in the Design View,
  and click on the Phone field to view its field
  properties.
• Locate and click on the build button () to
  invoke the Input Mask Wizard.

Invoking the Input Mask Wizard from the Field
Properties
19
Using the Input Mask Wizard (cont.)

• Select the Phone Number option under Input Mask
  list. Click inside the Try It text box to test
  the format.

The Input Mask Wizard Selecting the Mask
20
Using the Input Mask Wizard (cont.)

• Accept the default values for the next two pages
  of the wizard and click the Finish button to
  close the wizard.

The Input Mask Wizard Selecting the
Placeholder Character
21
Hands-On Tutorial Using Validation

• Goal
• Validate the date entered by the user in the DOB
  (date of birth) field of the student table.
• How-to Use Required, Validation Rules and Text
  Properties
• Open the student table in the Design View. Click
  on the DOB field to reveal its properties in the
  Field Properties.
• Set the Required property to Yes.
• Set the Validation Rule and the Validation Text
  properties as shown
• Validation Rule gt Date()-(36516)
• Validation Text Student age must be at least
  16 or more!

22
Hands-On Tutorial Using Validation (cont.)

• Save the changes made to the table, and verify
  the Validation Rule and Validation Text
  properties by entering erroneous data in the
  student table.

Using Validation Rule and Validation Text
Properties
23
Expression Builder

• The Expression Builder dialog box uses existing
  object names and many built-in functions to build
  expressions
• Invoke by clicking the Build button found at the
  end of the Validation Rule property entry.

Expression Builder Dialog Box
24
New Validation Rules

• When saving a table with a new validation rule,
  Access asks if we would like to validate the
  existing data in the table
• If we answer No, only new data entered or
  existing data when updated will be checked
  against the validation rule

Prompt for Testing the Existing Data for the New
Validation Rule
25
Hands-On Tutorial Creating a Table Index

• How-to Create an Index on a Table Field
• Open the student table in the Design View and
  click on the Class field to view its field
  properties.
• Locate the Indexed property and change its value
  to Yes.

Setting-up an Indexed Property
26
The Indexes Dialog Box

• We can use the Indexes dialog box to view, add,
  or delete field indexes
• To invoke the Indexes dialog box, click the
  Indexes button on the Database toolbar.

The Indexes Dialog Box
27
Overview

• 6.1 Introduction
• 6.2 Hands-On Tutorial Creating Access Tables in
  the Datasheet View
• 6.3 Hands-On Tutorial Creating Access Tables in
  the Design View
• 6.4 Field Data Types
• 6.5 Field Properties
• 6.6 The Lookup Wizard
• 6.7 Defining a Primary Key
• 6.8 Creating Access Tables by Using Import Wizard
• 6.9 Working with Table Properties
• 6.10 In-Class Assignment
• 6.11 Summary

28
The Lookup Wizard

• The Lookup Wizard helps us to look-up field
  values from field values of the same or other
  table
• Useful tool for foreign key fields
• Helps avoid violations of referential integrity
  constraint
• Simplifies the data entry process
• Invoke via the 10th option in the data type
  drop-down list

Setting-up the Lookup Data Type
29
Hands-On Tutorial Using Lookup Wizard

• How-to Set-up Lookup for DeptID Table Field
• Open the student table in the Design View and
  click on the DeptID field. Choose the Lookup
  Wizard option from the drop-down list of data
  types.
• Keep the default option of looking up values from
  an existing table and click Next.

The Lookup Wizard Specifying the Lookup Source
30
Hands-On Tutorial Using Lookup Wizard (cont.)

• Select the department table and click Next.
• Select the DeptID and Name fields from the list
  of Available Fields to the list of Selected
  Fields.

The Lookup Wizard Selecting a Lookup Field
31
Hands-On Tutorial Using Lookup Wizard (cont.)

• Accept the default sorting selection on the next
  page and click Next.
• Accept the Hide key column check box selection
  and click Finish.

The Lookup Wizard Hiding the Key Column
32
Hands-On Tutorial Using Lookup Wizard (cont.)

• 7. Verify the Datasheet View with a lookup on
  the DeptID field.

Lookup for DeptID Field in the Datasheet View
33
Hands-On Tutorial Using Lookup Wizard (cont.)

• 8. Verify the Design View of the student table.

Lookup Tab in the Design View
34
The Lookup Tab

• Lookup Tab properties
• Display Control
• Dictates the type of control that must be used to
  display the lookup values
• Options Combo Box, List Box, and Text Box
• Row Source Type and Row Source
• Specifies the source type and actual source of
  the lookup field
• Bound Column
• Specifies the column that will provide the actual
  lookup values

35
Overview

• 6.1 Introduction
• 6.2 Hands-On Tutorial Creating Access Tables in
  the Datasheet View
• 6.3 Hands-On Tutorial Creating Access Tables in
  the Design View
• 6.4 Field Data Types
• 6.5 Field Properties
• 6.6 The Lookup Wizard
• 6.7 Defining a Primary Key
• 6.8 Creating Access Tables by Using Import Wizard
• 6.9 Working with Table Properties
• 6.10 In-Class Assignment
• 6.11 Summary

36
Primary Keys

• A primary key is the set of one or more fields
  that uniquely identifies a record
• Distinguishes one record from another
• Each table in a relational database must have a
  primary key
• Access displays a key symbol on the row
  selector for the primary key field(s)
• Access automatically creates an index, called the
  PrimaryKey index, on primary key fields

37
Assigning a Primary Key

• How-to Assign a Primary Key
• In the Design View, select the field(s) by
  clicking the row selector on the left-hand side
  of the Field Name column.
• Click the Primary Key button on the Database
  toolbar.

Defining a Primary Key in Design View
38
Overview

• 6.1 Introduction
• 6.2 Hands-On Tutorial Creating Access Tables in
  the Datasheet View
• 6.3 Hands-On Tutorial Creating Access Tables in
  the Design View
• 6.4 Field Data Types
• 6.5 Field Properties
• 6.6 The Lookup Wizard
• 6.7 Defining a Primary Key
• 6.8 Creating Access Tables by Using Import Wizard
• 6.9 Working with Table Properties
• 6.10 In-Class Assignment
• 6.11 Summary

39
The Import Wizard

• The Import Wizard option allows us to import
  large amounts of existing data from external
  files directly into Access tables
• Examples of external files
• Excel files
• Text files
• Used when manual entering of data is infeasible

40
Using the Import Wizard

• How-to Import Data Using the Import Wizard
• To invoke the Import Wizard, right-click anywhere
  in the Database Window and select the Import
  option from the short-cut menu.
• Select the CourseTable.xls Excel file provided
  on the book website www.dssbooks.com.
• Accept the default selection and click Next.
• Assign the first row in the Excel sheet as the
  column heading in the Access table.

41
Using the Import Wizard (cont.)

• Import the course data to a new table.

Creating Access Tables Using Import Wizard
42
Using the Import Wizard (cont.)

• The next page allows us to
• Modify field names
• Create indexes on fields
• Skip a column from importing

Selecting the Fields to Create in the Import
Wizard
43
Using the Import Wizard (cont.)

• Specify the primary key of the table.
• Name the new table.

Defining a Primary Key in the Import Wizard
44
Overview

• 6.1 Introduction
• 6.2 Hands-On Tutorial Creating Access Tables in
  the Datasheet View
• 6.3 Hands-On Tutorial Creating Access Tables in
  the Design View
• 6.4 Field Data Types
• 6.5 Field Properties
• 6.6 The Lookup Wizard
• 6.7 Defining a Primary Key
• 6.8 Creating Access Tables by Using Import Wizard
• 6.9 Working with Table Properties
• 6.10 In-Class Assignment
• 6.11 Summary

45
Working with Table Properties

• Like a table field, a table itself has its own
  properties
• Control the behavior and appearance of the table
• To view the table properties, open the table in
  the Design View and then click the Property
  button on the toolbar

The Table Properties Dialog Box for the Student
Table
46
Overview

• 6.1 Introduction
• 6.2 Hands-On Tutorial Creating Access Tables in
  the Datasheet View
• 6.3 Hands-On Tutorial Creating Access Tables in
  the Design View
• 6.4 Field Data Types
• 6.5 Field Properties
• 6.6 The Lookup Wizard
• 6.7 Defining a Primary Key
• 6.8 Creating Access Tables by Using Import Wizard
• 6.9 Working with Table Properties
• 6.10 In-Class Assignment
• 6.11 Summary

47
In-Class Assignment

• The marketing department of a firm wants to
  create a database with detailed information about
  its customers
• Create a table that includes the following
  personal information about each customer
• Address, phone number, and email
• Make the following modifications to the table
• Record identification number, full name, address,
  zip code, phone number, and fax number for each
  customer. Make each of these fields required
  fields. Assign an appropriate field as a primary
  key of the table.
• Use the Input Mask Wizard to appropriately mask
  the phone number and fax number fields.

48
In-Class Assignment (cont.)

• The department researchers are also interested in
  demographic characteristics of the customers
• They plan to scan the data in the database based
  on particular age ranges and gender
• Add additional fields for these characteristics.
  Set the default value of the field Gender to M.
  The values to be entered in the Age field should
  be between 1 and 100. Display an error message
  for inappropriate age values.
• Create indexes on the Age and Gender fields to
  facilitate an efficient search based on these
  fields.

49
Overview

• 6.1 Introduction
• 6.2 Hands-On Tutorial Creating Access Tables in
  the Datasheet View
• 6.3 Hands-On Tutorial Creating Access Tables in
  the Design View
• 6.4 Field Data Types
• 6.5 Field Properties
• 6.6 The Lookup Wizard
• 6.7 Defining a Primary Key
• 6.8 Creating Access Tables by Using Import Wizard
• 6.9 Working with Table Properties
• 6.10 In-Class Assignment
• 6.11 Summary

50
Summary

• Tables are fundamental elements of a relational
  database and act as data foundation objects.
• Tables can be built using following options
• Creating a table in Datasheet View.
• Creating a table in Design View.
• Creating a table by using Table Wizard.
• Creating a table by using Import Wizard.
• The field data type dictates what kind of data
  can reside in the field.

51
Summary (cont.)

• Field properties control the behavior of a field
  and its data.
• The following are a few important field
  properties
• Format controls how to display data.
• Input Mask controls how to input data.
• Validation Rule controls what data can be
  stored.
• Indexed allows setting an index on a field for
  searching.
• Lookup Wizard allows looking up values from
  other fields.
• Table properties control the behavior of a table.

• We can use the validation rules to control how
  data is entered or modified at the record level.

52
Additional Links

• Review more sample Access tables from database
  files on the book website http//www.dssbooks.com
  .
• Refer MS Access 2003 The Complete Reference by
  Virginia Andersen for more details on Access
  tables.
• Also refer Access 2003 Bible by Cary N. Prague,
  Michael R. Irwin, and Jennifer Reardon.
• Also see http//msdn.microsoft.com/ for useful
  tips on Access tables
