Powertrain Matching

1
Powertrain Matching

• John Bucknell
• DaimlerChrysler
• Powertrain Systems Engineering
• September 30, 2006

2
What is Powertrain Matching?

• Selecting the right engine and gearing for a
  given application
• Not just performance, but giving the driver the
  expected response to pedal inputs
• In automotive applications delves deeper into
  transmission shift schedules as fuel economy is
  heavily impacted

3
A little side storytoget you in the right
mindset which illustrates the difference
between motorheads and everyone else
4
The Story of Powerand the Power Paradigm(the
early life of Electronic Throttle Control at
Chrysler)
5
The Beginning
Pedal
Driver

• Driver pushes on Pedal to move vehicle
• Pedal formerly known as Gas Pedal, and before
  that, Accelerator Pedal

6
Driver Intent Relates to Pedal Position
Speed up a lot
Speed up a little
Driver Intent
Maintain speed
Foot off Pedal
Floored
Slow down
Pedal Position
7
Driver Intent

• Driver Intent is essentially acceleration rate (
  or -)
• Since pedal position is related to driver intent,
  pedal position is related to desired vehicle
  acceleration.

8
Acceleration Relates to Pedal Position
Vehicle Acceleration
Foot off Pedal
Floored
Pedal Position
9
Vehicle Acceleration

• Newtons First Law
• Fma
• Vehicle mass is constant (ignoring fuel usage,
  washer solvent spray, and any fluid leaks)
• So, Force is proportional to acceleration

10
Force Relates to Pedal Position
Force Applied to Vehicle
Foot off Pedal
Floored
Pedal Position
11
Where Does the Force Come From?

• Engine produces some torque, at a speed
• Transmission
• Ignoring Losses, of Course

12
Where Does the Force Come From?

• Axle
• Ignoring Losses, of Course

13
Where Does the Force Come From?

• Tire
• Ignoring Losses, of Course
• Interesting, but not the end of the Story.

14
Where Does the Force Come From?

• Note

15
Where Does the Force Come From?

• Power- the rate at which work is done
• Power is Force times Velocity (linear)
• Power is Torque times Rotational Speed (rotary)

16
Where Does the Force Come From?

• Engine produces power

17
Where Does the Force Come From?

• Transmission
• Ignoring Losses, of Course

18
Where Does the Force Come From?

• Axle
• Ignoring Losses, of Course

19
Where Does the Force Come From?

• Tire
• Ignoring Losses, of Course

20
Where Does the Force Come From?

• Power is conserved
• POWER IS ABSOLUTE
• Torque is relative (depends on gear ratio)
• Ignoring Losses, of Course

21
Where Does the Force Come From?

• The force comes from engine power
• At a given vehicle velocity, force, and therefore
  acceleration, depends on power produced by the
  engine

22
Force Relates to Pedal Position
Force Applied to Vehicle
Foot off Pedal
Floored
Pedal Position
23
Engine Power Relates to Pedal Position
Engine Power
Foot off Pedal
Floored
Pedal Position
24
Engine Power Relates to Pedal Position
Acceleration
Constant Speed
Deceleration
25
Implications of the Power Paradigm

• Powertrain Control
• Vehicle Performance
• Engine Performance Optimization Criteria

26
Powertrain Control

• Should provide the power level demanded by the
  driver as efficiently as possible
• Efficiency could be based on
• minimum fuel consumption
• minimum emissions
• best NVH
• some combination of these or other considerations
• Should use the best combination of

• engine speed (gear ratio)
• throttle position (ETC)
• spark advance
• fuel flow rate
• EGR rate

• cylinder deactivation
• variable valve timing
• active manifold
• external charge motion devices

27
Powertrain Control Example

• Example minimize fuel consumption at a driver
  commanded power level
• pedal position indicates driver wants 100 hp
  delivered (based on power required vs. pedal
  position and vehicle speed)
• need to find engine speed and MAP (throttle
  position) for best fuel consumption
• assume Electronic Throttle Control

28
Specific Fuel Consumption vs. Speed MAP
29
Engine Power vs. Speed MAP
30
Specific Fuel Consumption vs. Speed MAP
31
Engine Power vs. Speed MAP
32
BSFC vs. Speed MAP with Constant Power Lines
33
Powertrain Control Example

• Any combination of MAP and rpm along the 100 hp
  line will satisfy the drivers power requirement
• Low rpm and high MAP gives best BSFC
• Ideally, efficient CVT sets engine speed (1900
  rpm, set MAP to 90 kPa)
• Conventional transmissions with discreet gear
  ratios must pick gear ratio for combination of
  rpm and MAP for lowest BSFC at a vehicle speed

34
Vehicle Performance

• Best possible vehicle acceleration if engine runs
  at peak power (not at peak torque)
• requires efficient CVT to change transmission
  ratio vs. vehicle speed to maintain peak power
  engine speed
• Transmission that allows the engine to provide
  the highest average power over an acceleration
  event will give best vehicle acceleration
• more transmission gears improves vehicle
  acceleration by keeping engine speed in range
  that makes more power

35
Simulated Vehicle Performance with Different
Transmissions
36
Engine Performance Optimization Criteria

• Typically engine program goals are a peak torque
  value and a peak power value
• Assuming different sets of engine hardware could
  meet the program goals, only one set of hardware
  will perform the best in a vehicle
• The best performing vehicle will have the highest
  average power delivered to the wheels during an
  acceleration event, which is dependent on
  transmission capability

37
Engine Optimization Example Which Engine
Performs Better in a Vehicle?
38
Engine Optimization Example Which Engine
Performs Better in a Vehicle?
39
Engine Optimization Example

• Engine A Engine B both meet program objectives
• Which one is better?
• It depends on the transmission
• Engine B will perform better if transmission
  keeps engine speed above 3200 rpm during an
  acceleration event
• This is true for any of the typical vehicle
  performance metrics
• 5 sec. Distance
• 0-60 time
• 1/4 mile time

40
Summary

• The Story of Power
• Pedal Position relates to driver demanded power
  output
• The Power Paradigm
• Power is Absolute
• Powertrain (engine/transmission) matching is
  crucial to maximize vehicle performance

41
(No Transcript)
42
Closing Remarks

• Powertrain Matching makes best use of your engine
  potential
• Torque Power shaping can give optimal
  performance for a given set of gearing
• Optimal gearing can make your car faster for no
  changes in engine performance

43
Q A
