IO Introduction: Storage Devices

1
I/O Introduction Storage Devices RAID
2
I/O Systems
interrupts
Processor
Cache
Memory - I/O Bus
Main Memory
I/O Controller
I/O Controller
I/O Controller
Graphics
Disk
Disk
Network
3
A Computer System with One Bus Backplane Bus
Backplane Bus
Processor
Memory
I/O Devices

• A single bus (the backplane bus) is used for
• Processor to memory communication
• Communication between I/O devices and memory
• Advantages Simple and low cost
• Disadvantages slow and the bus can become a
  major bottleneck
• Example IBM PC - AT

4
A Two-Bus System
Processor Memory Bus
Processor
Memory
Bus Adaptor
Bus Adaptor
Bus Adaptor
I/O Bus
I/O Bus
I/O Bus

• I/O buses tap into the processor-memory bus via
  bus adaptors
• Processor-memory bus mainly for processor-memory
  traffic
• I/O buses provide expansion slots for I/O
  devices
• Apple Macintosh-II
• NuBus Processor, memory, and a few selected I/O
  devices
• SCCI Bus the rest of the I/O devices

5
A Three-Bus System
Processor Memory Bus
Processor
Memory
Bus Adaptor
I/O Bus
Backplane Bus
I/O Bus

• A small number of backplane buses tap into the
  processor-memory bus
• Processor-memory bus is used for processor memory
  traffic
• I/O buses are connected to the backplane bus
• Advantage loading on the processor bus is
  greatly reduced

6
Disk History
Data density Mbit/sq. in.
Capacity of Unit Shown Megabytes
1973 1. 7 Mbit/sq. in 140 MBytes
1979 7. 7 Mbit/sq. in 2,300 MBytes
source New York Times, 2/23/98, page C3,
Makers of disk drives crowd even more data into
even smaller spaces
7
Disk History
1989 63 Mbit/sq. in 60,000 MBytes
1997 1450 Mbit/sq. in 2300 MBytes
1997 3090 Mbit/sq. in 8100 MBytes
source New York Times, 2/23/98, page C3,
Makers of disk drives crowd even mroe data into
even smaller spaces
8
1 inch disk drive!

• 2000 IBM MicroDrive
• 1.7 x 1.4 x 0.2
• 1 GB, 3600 RPM, 5 MB/s, 15 ms seek
• Digital camera, PalmPC?
• 2006 MicroDrive?
• 9 GB, 50 MB/s!
• Assuming it finds a niche in a successful
  product
• Assuming past trends continue

9
Use Arrays of Small Disks?

• Katz and Patterson asked in 1987
• Can smaller disks be used to close gap in
  performance between disks and CPUs?

Conventional 4 disk designs
10
5.25
3.5
14
High End
Low End
Disk Array 1 disk design
3.5
10
Array Reliability

• Reliability of N disks Reliability of 1 Disk
  N
• 50,000 Hours 70 disks 700 hours
• Disk system MTTF Drops from 6 years to 1
  month!
• Arrays (without redundancy) too unreliable to
  be useful!

Hot spares support reconstruction in parallel
with access very high media availability can be
achieved
11
Redundant Arrays of (Inexpensive) Disks

• Files are "striped" across multiple disks
• Redundancy yields high data availability
• Availability service still provided to user,
  even if some components failed
• Disks will still fail
• Contents reconstructed from data redundantly
  stored in the array
• ? Capacity penalty to store redundant info
• ? Bandwidth penalty to update redundant info

12
Redundant Arrays of Inexpensive DisksRAID 1
Disk Mirroring/Shadowing
recovery group

•  Each disk is fully duplicated onto its mirror
• Very high availability can be achieved
• Bandwidth sacrifice on write
• Logical write two physical writes
• Reads may be optimized
• Most expensive solution 100 capacity overhead
• (RAID 2 not interesting, so skip)

13
Redundant Array of Inexpensive Disks RAID 3
Parity Disk
P contains sum of other disks per stripe mod 2
(parity) If disk fails, subtract P from sum of
other disks to find missing information
14
RAID 3

• Sum computed across recovery group to protect
  against hard disk failures, stored in P disk
• Logically, a single high capacity, high transfer
  rate disk good for large transfers
• Wider arrays reduce capacity costs, but decreases
  availability
• 33 capacity cost for parity in this configuration

15
Inspiration for RAID 5

• Small writes (write to one disk)
• Option 1 read other data disks, create new sum
  and write to Parity Disk
• Option 2 since P has old sum, compare old data
  to new data, add the difference to P
• Small writes are limited by Parity Disk Write to
  D0, D5 both also write to P disk

16
Redundant Arrays of Inexpensive Disks RAID 5
High I/O Rate Interleaved Parity
Increasing Logical Disk Addresses
D0
D1
D2
D3
P
Independent writes possible because
of interleaved parity
D4
D5
D6
P
D7
D8
D9
P
D10
D11
D12
P
D13
D14
D15
Example write to D0, D5 uses disks 0, 1, 3, 4
P
D16
D17
D18
D19
D20
D21
D22
D23
P
. . .
. . .
. . .
. . .
. . .
Disk Columns
17
Problems of Disk Arrays Small Writes
RAID-5 Small Write Algorithm
1 Logical Write 2 Physical Reads 2 Physical
Writes
D0
D1
D2
D3
D0'
P
old data
new data
old parity
(1. Read)
(2. Read)
XOR


XOR
(3. Write)
(4. Write)
D0'
D1
D2
D3
P'
18
System Availability Orthogonal RAIDs
Array Controller
String Controller
. . .
String Controller
. . .
String Controller
. . .
String Controller
. . .
String Controller
. . .
String Controller
. . .
Data Recovery Group unit of data redundancy
Redundant Support Components fans, power
supplies, controller, cables
End to End Data Integrity internal parity
protected data paths
19
System-Level Availability
host
host
Fully dual redundant
I/O Controller
I/O Controller
Array Controller
Array Controller
. . .
. . .
. . .
Goal No Single Points of Failure
. . .
. . .
. . .
with duplicated paths, higher performance can
be obtained when there are no failures
Recovery Group
20
Summary RAID Techniques Goal was performance,
popularity due to reliability of storage
1 0 0 1 0 0 1 1
1 0 0 1 0 0 1 1
Disk Mirroring, Shadowing (RAID 1)
Each disk is fully duplicated onto its "shadow"
Logical write two physical writes 100
capacity overhead
1 0 0 1 0 0 1 1
0 0 1 1 0 0 1 0
1 1 0 0 1 1 0 1
1 0 0 1 0 0 1 1
Parity Data Bandwidth Array (RAID 3)
Parity computed horizontally Logically a single
high data bw disk
High I/O Rate Parity Array (RAID 5)
Interleaved parity blocks Independent reads and
writes Logical write 2 reads 2 writes
