Designing Replication and Disaster Recovery

1
Chapter 11

• Designing Replication and Disaster Recovery

2
Learning Objectives

• Explain how Active Directory replication works,
  including the use of the Knowledge Consistency
  Checker
• Design the Active Directory replication topology
  for an organization
• Design Dfs for folder and file replication
• Plan disaster recovery methods, including backing
  up and restoring Active Directory and other
  critical system data

3
Using Active Directory Replication

• Replication
• The process of creating a copy of specific Active
  Directory data (data store) on domain controllers
• Each copy is regularly synchronized to ensure
  that it is identical to every other copy on
  domain controllers in the same domain

4
Using Active Directory Replication

• Vital elements in Active Directory that are
  replicated in the multimaster topology
• Domain partition namespace
• Schema namespace
• Configuration container namespace
• Global catalog
• DNS namespace (when DNS is integrated with Active
  Directory)

5
Domain Partition Namespace Replication
6
(No Transcript)
7
(No Transcript)
8
The Replication Process

• Tracking Active Directory changes
• Track every change in sequence
• Place a timestamp on each change
• Providing fault tolerance
• Packaging changes to match the site topology

9
Knowledge Consistency Checker (KCC)

• Purpose to guarantee that Active Directory
  replication takes place
• Establishes network connections between DCs
• Ensures that replication services take place
• Obtains site and site link information from the
  configuration container
• Assesses locations of DCs, site link costs, and
  the replication strategy of server administrators
• Determines replication partners

10
How the KCC WorksWithin a Site

• Establishes connections between domain
  controllers and polls those connections every 15
  minutes to determine if
• The connection needs to be reestablished
• A new DC needs to be added for replication
• A DC has been removed from the network
• Ensures efficient replication and establishes the
  replication ring by using information about sites
  and site links that it obtains from the
  configuration container

11
How the KCC WorksWithin a Site
12
How the KCC WorksWithin a Site
13
How the KCC WorksWithin a Site

• Information about all of the replicating DCs in a
  site, including global catalog servers, is
  contained in an Active Directory child object
  under a site called NTDS Site Settings
• Child objects in the Servers folder are the DCs
  in the site each DC has a child object called
  NTDS Settings

14
NTDS Site Settings Container
15
Replication Partners
16
How the KCC WorksWithin a Site

• Remote procedure call (RPC) protocol
• Transport protocol used by the replication
  process within a site
• Carried over another transport protocol, TCP/IP
• Enables one computer to run a program process or
  procedure called a remote procedure call on
  another computer

17
How the KCC WorksOver Site Links

• Establishes one bridgehead server at each site
• Each bridgehead server replicates Active
  Directory to other DCs on the same site using
  ring-based replication topology
• You can establish a cost with a site link and
  determine replication frequency

18
Setting Replication Frequency over a Site Link
19
How the KCC WorksOver Site Links

• Uses PRC protocol for replication between sites
• Carried over TCP/IP or SMTP
• Transitive replication
• Can go in any direction through a site link
  bridge

20
Using Site Link Bridges
21
Review of Replication Factors

• The KCC checks every 15 minutes for changes to
  site topology
• Intrasite replication occurs when a change is
  made to Active Directory
• Intersite replication occurs by default every 180
  minutes, 24 hours/day, 7 days/week, but the
  replication interval can be manually configured
  at other intervals
• Replication between two sites occurs only if a
  site link is configured between them

continued
22
Review of Replication Factors

• If two or more site links exist between the same
  site, configure each site link with a cost
  replication goes over the link with lowest cost
• Replication between sites is performed by one
  bridgehead server designated per site
• Configuring site link bridges enables two or more
  sites to replicate transitively (in multiple
  directions)

23
Guidelines for Designing a Replication Topology

• Small network
• Use two or more domains so replication can take
  place
• Dividing a single domain network
• Locate at least one domain controller and global
  catalog server at each site (provides offsite
  backup)
• Consider placing a DNS server that is integrated
  with Active Directory at each site

continued
24
Guidelines for Designing a Replication Topology

• Multiple domain network with 2 or more sites
• Locate two or more DCs in each domain, at least
  one DC in each site, and at least one global
  catalog server at each site
• Place a NDS server integrated with Active
  Directory in each domain and at each site
• Two or more site links between two adjoining
  sites
• Configure the cost of each site link so the KCC
  will direct replication traffic over the site
  link that has the lowest cost

continued
25
Guidelines for Designing a Replication Topology

• For each site link
• Configure replication frequency so that
  replication does not interfere with regular
  business use of the site link
• For small and medium-sized networks
• Configure site links that use the same protocol
  so that all site links are in the same site link
  bridge
• For some medium-sized and large networks
• Disable setting to link all site links into a
  single bride
• Configure individual site link bridges on basis
  of analysis of network traffic over site links

continued
26
Guidelines for Designing a Replication Topology

• Use TCP/IP as the main RPC host transport
  protocol
• For site links within and between domains,
  whenever possible
• Use SMTP as the main RPC host protocol
• When replicating between two different domains
  over an e-mail and Internet-based site link

27
Designing a Replication Topology Sample
28
Advantages of the Previous Design

• There is offsite replication of the domain
  partition, configuration container, schema, and
  global catalog, in case there is a disaster that
  damages servers in one of the buildings
• Replication over the site link it compressed to
  reduce traffic
• Replication traffic over the site link can be
  scheduled so that it does not interfere with
  regular business operations over the site link

29
Designing a Replication Topology Sample
30
Advantages of the Previous Design

• There is offsite replication at five different
  sites at each site, there is replication of the
  domain partition, configuration container,
  schema, and global catalog
• The bridge all sites links option ensures that
  replication occurs in any direction among site
• Assigning lowest cost to X.25 links ensures that
  replication goes over the links that have the
  least important network traffic

31
Designing a Replication Topology Sample
32
Advantages of the Previous Design

• Domain partition replication occurs across
  multiple servers within the same domain
• Offsite domain partition replication is set up
  for sites in the same domain that are in
  different physical locations
• Global catalog server replication occurs between
  all domains, providing offsite replication of
  global catalog server information

33
Using Dfs for File Replication and Disaster
Recovery

• Distributed File System (Dfs)
• Protects critical user files enables you to
• Simplify access to shared folders on a network
• Replicate shared folder information to multiple
  DCs on a network
• Load balance access to shared folders
• Provides a way to automatically replicate vital
  information in shared folders
• Enables fault tolerance
• Can be a source of disaster recovery

34
Dfs Models

• Standalone
• Domain-based

35
Standalone Dfs Model

• No Active Directory implementation to help manage
  shared folders
• Only a single or flat-level share
• Main Dfs shared folder does not contain a
  hierarchy of other shared folders
• Does not have Dfs folders that are linked to
  other computers through a Dfs container that has
  a main root and a deep, multilevel hierarchical
  structure
• Does not implement fault tolerance and load
  balancing for shared folders

36
Domain-based Dfs Model

• Takes full advantage of Active Directory
• Available only to servers and workstations that
  are members of a domain
• Enables a deep root-based hierarchical
  arrangement of shared folders that is published
  in Active Directory
• Shared folders are replicated for fault tolerance
  and load balancing

37
Dfs Topology

• The hierarchical structure of Dfs in the
  domain-based model
• Three elements
• Dfs root
• Dfs link
• Servers on which the Dfs shared folders are
  replicated as replica sets

38
Dfs Topology
39
Creating a Dfs Implementation Plan

• When Active Directory is installed, plan to use
  the domain-based model it provides the most
  options and enables you to mange resulting
  network traffic
• Place Dfs shared folders on disks that are
  formatted using NTFS ensures strong security
  options

continued
40
Creating a Dfs Implementation Plan

• Use more than one Dfs root to reflect the
  particular needs of an organization

continued
41
Creating a Dfs Implementation Plan

• Use upper-level subfolders under a root to
  reflect other elements of an organization (Figure
  11-15)
• Determine the impact that Dfs will have on
  network traffic use domain-based model with load
  balancing to help equally disperse network traffic

continued
42
Creating a Dfs Implementation Plan
43
Creating a Dfs Implementation Plan

• When designing a domain-based model, create the
  first Dfs root and links to that root before
  creating additional Dfs roots
• In the domain-based model, develop a
  synchronization schedule that will take into
  account the existing network traffic along
  different routs (segments) on which
  synchronization will occur
• Review all Dfs shared folders on a regular basis
  purge folders no longer in use

44
Setting Up Dfs

• Dfs is configured using either
• The Distributed File System tool in the
  Administrative Tools menu, or
• The Distributed file system MMC snap-in

45
Planning Disaster Recovery

• In addition to carefully planning Active
  Directory replication and Dfs
• Develop a backup strategy and perform regular
  backups
• Back up system state data and system protected
  files
• Create boot disks
• Create and regularly update emergency repair disks

46
Developing a Backup Strategy
47
Developing a Backup Strategy

• Backup media rotation plan should include
• At least two complete sets of media
• A media rotation method
• Offsite storage of backup media

48
Disaster Recovery for System State Data

• Critical elements are backed up as a group
  because many are interrelated
• System and boot files
• Active Directory
• SYSVOL folder
• Registry
• COM Class Registration information
• DNS zones
• Certificate information
• Server cluster data

49
Disaster Recovery for System Protected Files

• System protected files are vital for booting a
  server
• Ntldr
• Bootsect.dos
• Boot.ini
• Ntdetect.com
• Ntbootdd.sys
• Ntoskrnl.exe
• Hal.dll

50
Disaster Recovery for System Protected Files
51
Creating Boot Disks

• Vital if you cannot boot from a hard drive or a
  CD-ROM drive
• Needed to boot the computer and use the emergency
  repair disk

52
Creating and Using an Emergency Repair Disk

• Enables you to fix several kinds of problems
• Create a new ERD each time you
• Install software
• Make a server configuration change
• Install a new adapter
• Add a NIC
• Restructure a partition
• Upgrade the operating system

53
Starting the ERD
54
Chapter Summary

• How Active Directory replication works and how to
  design your network to take full advantage of
  replication
• How Dfs can be used to replicate information that
  is not in Active Directory, for faster access and
  fault tolerance
• How to back up and restore critical system data
  for extra disaster recovery insurance
