Bias Correction Methods Adjusting Moments

1
Bias Correction Methods Adjusting Moments

• Bo Cui, Zoltan Toth Yuejian Zhu, Dingchen
  Hou, and Richard Wobus
• Environmental Modeling Center, NCEP/NWS
• SAIC at Environmental Modeling Center, NCEP/NWS

2
Acknowledgements
Zoltan Toth Yuejian Zhu Dingchen Hou
Richard Wobus
3
Outline

• Tasks Goals
• Bias-Correction Algorithm Adjusting Moments
• Experimental Design
• Ensemble Forecast Verification
• Future Plans

4
Ensemble Postprocessing

• NWP models, ensemble formation are imperfect
• Deficiencies due to various problems in NWP
  models
• Systematic errors in analysis induced by
  observations and model related
• Ensemble formation
• Not appropriate initial spread
• Lack of representation of model related
  uncertainty
• Limited ensemble size
• Known model/ensemble problems addressed at their
  sources, no perfect solution exists
• Systematic errors remain and cause biases in
• 1st , 2nd moments of ensemble distribution

5
Tasks Goals

• Tasks
• Develop and implement a statistical
  post-processing scheme to reduce the biases in
  ensemble forecasts (height, temperature and other
  variables)
• Correct both the 1st and 2nd moments of the
  ensemble
• Goals
• Biased-corrected forecasts will have reduced or
  no bias with respect to the verifying analysis
  fields, given on the model grid

6
Moment Adjustment

• Bias Assessment

FIRST MOMENT B DIFFERENCE BETWEEN Ensemble
mean forecast and Verifying analysis
SECOND MOMENT R RATIO BETWEEN RMS Error of
Ensemble mean and Ensemble Spread

• Bias Correction

1st moment Ensemble mean B
2nd moment Ensemble mean B
(Ensemble Forecast Ensemble Mean) R
7
Implementation Facts

• Bias assessment carried out separately at each
• forecast lead time
• individual grid point
• ensemble mean, GFS and ensemble control forecasts

• Bias correction tests - applied on
• all ensemble member forecasts
• for 00Z initial cycle only
• 2.5x2.5 lat/lon resolution
• 500 mb height, 850 mb temperature

8
Alternatives or Refinements of Bias-Correction
Algorithm

• Adaptive methods
• Consider most recent past data with decaying
  averaging
• Use data from surrounding grid-points (with a
  Gaussian weighting function)
• Use large (climatological) sample data if
  available and forecast system is stable
• Adjust temporal/spatial sampling domain to
  optimize performance
• Construct cumulative frequency distribution to
  match that of observed, QPF calibration (Yuejian
  Zhu)
• Regime dependent method (Jun Du)
• use correlation coefficients between circulation
  field today vs. that in recent past to determine
  weights given to data in estimating bias

9
Experimental Design
Implementation of decaying averaging for 1st
moment bias
T0-46 day
T0-16 day
T0 day
decaying averaging mean error (1-w) prior
t.m.e w (f a)
a) Prior estimate to startup procedure choose T0
as current date (00Z), calculate the time mean
errors between T-46 and T-16 day. b) Update the
prior estimate of the average state is multiplied
by a factor 1-w (lt1). Then, most recent
verification error (f - a) is added to the
decaying average for each lead time with a weight
of w. c) Cycling repeat step (b) every
day. Three experiments with w of 1, 2 and 10

10
Experimental Design
Centered running mean error test for 1st moment
bias
T0-15 day
T0 day T015 day

• Define /- 15 day time average as bias. Use bias
  estimate
• (with dependent data) as optimal benchmark.
• Implementation
• Four experiments optimal test, three decaying
  averaging experiments (1, 2 and 10 weight)
• 8-month period for these experiments (Spring and
  Summer 2004 )

11
OPT
Temporal Cross Section 500 mb Height Time Mean
Error (40 N, 95 W, Jan. to Aug. 2004)
W1
May 22
Jun. 22
May 22
W2
W10
Jun. 22
Jun. 11
May 22
May 22
12
Temporal Cross Section 850 mb Temp. Time Mean
Error (40 N, 95 W, Jan. to Aug. 2004)
OPT
W1
May 1
Jun. 2
May 1
W2
W10
Jun. 2
May 1
May 1
May 10
13
Ensemble Forecasts Verification

• Verification of ensemble mean
• 500 mb height and 850 mb temperature
• Verification domains
• NH, SH and Tropics
• Verification data set
• GFS final analysis
• Verification scores ACpattern anomaly
  correlation coefficient RMSroot mean square
  error of ensemble mean ROC relative
  operating characteristics RPSSranked
  probability skill score

14
AC and RMS 500 mb Height, Summer 2004
AC
RMS
RMS error slightly reduced for first several days
3 bias-corrected ensembles with decaying average
AC scores slightly improved for week 1
15
ROC 500 mb Height, Summer 2004
NH
SH

• 2 weight experiment improves performance over
  NH, and slightly over SH up to week 2
• 10 weight experiments performance improved over
  Tropics

TR
16
ROC 500 mb Height, Spring 2004
NH
SH

• NH and SH ROC with some weight improved for
  most lead time
• Tropics ROC improved at all leads indicting
  bias much reduced for sub-regions. 10 weight
  experiment has a better performance

TR
17
RPSS 500 mb Height, Summer 2004
NH
SH

• 2 weight experiment improve performance over
  NH, and slightly over SH as well
• 10 weight experiment improves performance over
  Tropics, especially for week 2

TR
18
Preliminary Results

• In general, the time mean errors of 500 mb
  height increase with
• forecast lead time. The time mean errors
  growth of 500mb
• height with forecast lead time is nearly
  linear in some cases.
• What determines linearity?
• The time mean error difference between 1 and
  2 weight
• experiments is small. The 10 weight
  experiment has higher
• frequency details compared to the 1 and 2
  experiments (better for short range?).
• The centred running mean error test (OPT) shows
  potential for
• significant improvement in the forecast of
  both 500 mb height
• and 850 mb temperature in term of all
  verification scores,
• compared to the raw ensembles.

19
Preliminary Results

• For days 1 through 6, the AC scores for the raw
  ensemble and
• three bias corrected ensembles with decaying
  averaging are
• relatively close to each other on average.
  With some weights,
• AC and RMS performance can be improved.
• The 2 ensemble show large improvements of ROC,
  RPSS
• and BSS score over the North and South
  Hemisphere. The
• improvement of these scores in summer is more
  significant than
• in spring. On the other hand, the choice of
  10 weight works
• better for Tropics compared to 1 and 2. Use
  different
• weights for Tropics?
• The decaying averaging approach to improve the
  NCEPs
• global ensemble forecast system seems
  promising. Problems
• with estimating bias for longer lead time
  with short sample.

20
Future Plans

• Test 1st moment bias-correction algorithm on
  longer period (four seasons, 5 years) for tuning.

• Start research on the 2nd moment calibration.
• Test refinements of bias correction algorithm
  listed before.
• Run 4 cycles per day, adding 06Z 12Z and18Z
  forecasts, to provide more timely information and
  increase sample size. Use data with 1x1 lat/lon
  resolution.
• Add new ensemble forecast variables such as 2m
  temperature, U,V, cumulative frequency
  distribution for forecast QPF.
• Consider other methods and/or use of larger
  sample especially for longer lead times.

21
(No Transcript)
22
Refinements of Bias-Correction Algorithm

• Details
• Decaying averaging
• Use recent verification statistics in the
  calibration process, accumulated in a decaying
  averaging sense
• Achieved by using a recursive averaging procedure
  (Kalman Filtering)

6.6
3.3
1.6
Toth, Z., and Y. Zhu, 2001
23
Centered Running Mean Error Summer
2004 Latitudinal Cross Section (95 W)
Longitudinal Cross Section (40 N)
z500
z500
40N
95W
T850
T850
40N
95W
