ICT Intraoperative Corneal Topography for
image registration purposes S.Schründer
2
Model eye
6mm optical zone
8mm corneal radius
6mm pupil, 4mm below apex
5mm to rotation axis
12mm radius bulbus
3
Tilted eye
4
Motivation
Treatment
Diagnosis
5
Solution
Registration in 3d space
6
Requirement
3d objects
7
(No Transcript)
8
(No Transcript)
9
Height map pre ablation
Difference to 8.4mm sphere Range 100µm
10
Height map post ablation
Difference to 8.7mm sphere Range 100µm
11
Fine registration Iterative Closest Point
Find corresponding 3d points (via Hough
tables) Minimize their distance

• Distance Minimization
• Levenberg-Marquardt
• for fast convergence
• Simmulated annealing
• to overcome local minima

12
Registration points area
Detected flap edge
13
Difference map after registration
7.5mm circle Range 105µm
14
Line scans
Dimensions in mm
15
3d Flap thickness
9.5mm circle Range 290µm
16
Line scans
Dimensions in mm
17
Next steps
Rigid incorporation into a laser system
Extended clinical trials
Stand alone device
18
Centered cornea
19
0.5mm lateral shift
20
Corresponding tilt
0.22mm decentration
21
Linear function
8mm corneal radius, 4mm apex/pupil, 13mm
apex/rotation axis
22
Coworkers at BioShape
Andreas Dankert Hendrik Fuchs Saso Spasovski
23
Thank you. bioshape.com
