Using CDO And ADSI For Contact Management

1
Using CDO And ADSI For Contact Management
Robert BrownProgram ManagerExchange Server
Product UnitMicrosoft Corporation
2
(No Transcript)
3
Agenda

• Demo - virtual community web site
• Schema for contact management
• The CDO Person Object
• Interacting with the Web Store
• Interacting with the directory
• Using ADSI to work with people and groups
• CDO for Exchange Management

4
Demonstration

• Sample Application

5
Person Schema

• Exchange 5.5 and CDO 1.21
• CDO 1.2 does not have a contact object
• Outlook has a contact object but you cant use it
  on the server
• Store had no knowledge of structured data
• Developers had to invent schema, or figure out
  the Outlook schema
• No interop with other popular person schemas like
  LDAP and VCard

6
Person Schema

• Exchange 2000
• Knows about and exposes structured data
• Ships with a comprehensive and extensible set of
  schema
• Including urncontent-classesperson
• Based on LDAP
• Normalized across VCARD, Outlook Express, and
  Outlook Contacts
• Person schema also has built-in behaviors

7
Schema Inheritance

• Subclass Exchange 2000 schema to fit your
  business needs

urncontect-classesobject
(base object)
urncontent-classesitem
(basic document properties)
urncontent-classesperson
(person-specific properties)
my-customer
my-competitor
(specific to your customers)
(specific to your competitors)
8
DemonstrationExchange 2000s Person schema

• urncontent-classesperson has a comprehensive
  set of properties
• The person schema is described using XML
• Schema is directly leveraged by in Web Forms
• Binding in native HTML no programming required!

9
Programming With The Person Schema

• HTTP-DAV
• OLE DB
• ADO
• CDO.Person

10
ADO - Code Sample
sDom mydom.myOU.myorg.com sMB /mbx/
useralias /contacts sURL file//./BackOffic
eStorage/ myDom sMB set rs
server.createobject("adodb.recordset") rs.Open
"select ""DAVhref"", ""urnschemascontactsfilea
s" from SCOPE('shallow traversal of " sURL
"")", "ProviderExoledb.DataSource.1 Data
Source sURL While Not rs.EOF
response.write _ rs.Fields("urnschema
scontactsfileas").Value rs.MoveNext Wend
sDom mydom.myOU.myorg.com sMB /mbx/
useralias /contacts sURL file//./BackOffic
eStorage/ myDom sMB
set rs server.createobject("adodb.recordset")
rs.Open "select ""DAVhref"", ""urnschemascontac
tsfileas" from SCOPE('shallow traversal of
" sURL "")", "ProviderExoledb.DataSourc
e.1 Data Source sURL
While Not rs.EOF response.write _
rs.Fields("urnschemascontactsfileas").Value
rs.MoveNext Wend
11
CDO Person Object Model

• CDO.Person
• CDO for Exchange Management
• Extends CDO by adding two interfaces to
  CDO.Person
• IMailRecipient
• IMailBoxStore

12
CDO.Person

• Models a Person in the contact database and in
  the Directory
• Provides simple access to name, addresses,
  telephone numbers and email addresses properties
• All other properties available through the fields
  collection
• Supports VCard import and export

13
CDO.Person Interfaces

• IPerson
• IDataSource
• IMailbox
• IMailboxStore
• IMailRecipient

14
IPerson Properties

• Name
• First, Middle, Last, Title, Initials, Suffix,
  Prefix
• Address Properties
• Separate sets of properties for Home, Work and
  Mailing addresses
• Street, city, state, country, post code, postal
  address, P.O. Box

15
More IPerson Properties

• E-mail addresses
• Telephone numbers
• Home and work phone,home and work fax, mobile
  phone
• Fields Collection

16
IMailBox Properties

• URLs to exchange folders
• Inbox
• Outbox
• Contacts
• Calendar
• Etc.

17
IMailBox Code Sample
Set pers server.CreateObject("CDO.Person") Set
f server.CreateObject("CDO.Folder") set rs
server.CreateObject("ADODB.Recordset")
Set pers server.CreateObject("CDO.Person") Set
f server.CreateObject("CDO.Folder") set rs
server.CreateObject("ADODB.Recordset") pers.DataS
ource.Open "mailto" uid "_at_"
dnsdomain f.DataSource.Open pers.GetInterface("IM
ailbox").Inbox rs.Open "select from
SCOPE('shallow traversal of """ m.Inbox
"""')", _ f.DataSource.ActiveConnection Whi
le Not rs.EOF response.write
rs.Fields("DAVdisplayname").Value
rs.MoveNext Wend
pers.DataSource.Open "mailto" uid "_at_"
dnsdomain
f.DataSource.Open pers.GetInterface("IMailbox").In
box
rs.Open "select from SCOPE('shallow traversal
of """ m.Inbox """')", _
f.DataSource.ActiveConnection
While Not rs.EOF response.write
rs.Fields("DAVdisplayname").Value
rs.MoveNext Wend
18
Directory Integration

• Contacts can exist in
• Active Directory
• Exchange 2000 Web Store (public or private)
• Use CDO.Person to create contacts anywhere
• Use CDO Contacts to bind to a Contact in the
  Directory and then save it to a contacts database

19
Directory Integration Code Sample
Copy pers1 from the DS into pers2s contacts
folder
Set pers1 server.CreateObject("CDO.Person") Set
pers2 server.CreateObject("CDO.Person") pers1.D
ataSource.Open "mailto" uid1 "_at_"
domain pers2.DataSource.Open "mailto" uid2
"_at_" domain pers1.DataSource.SaveToContainer _
pers2.GetInterface("IMailbox").Conta
cts
Set pers1 server.CreateObject("CDO.Person") Set
pers2 server.CreateObject("CDO.Person")
pers1.DataSource.Open "mailto" uid1 "_at_"
domain pers2.DataSource.Open "mailto" uid2
"_at_" domain
pers1.DataSource.SaveToContainer _
pers2.GetInterface("IMailbox").Contacts
20
ADSI IADs interface

• Implemented by every base object
• Properties
• Name, ADsPath, class, schema, parent
• Methods
• Get, put, getinfo, setinfo
• Using only the IADs interface you can learn all
  about an object and get or set all of its
  properties
• Use GetObject(ADSPath)

21
ADSIReading And writing properties

• Simple caching system
• IADsGetInfo()
• Reloads the cache with values from the
  underlying Web Store
• Changes made in the cache are lost
• IADsSetInfo()
• Writes cached changesto the underlying Web Store

22
DemonstrationADSI and CDO.Person in the directory

• Use CDO.Person to interact with the Directory
• Use CDO.Person to save contacts from the DS to
  the Web Store

23
CDO For Exchange Management

• CDOEXM (a.k.a. EMO) extends CDO and ADSI by
  adding management interfaces
• Exchange 2000 release supports recipient and
  folder management
• Exchange 2000 includes the following management
  interfaces
• IMailRecipient
• IMailBoxStore

24
CDO EXMObject model

• CDOEXM extends CDO
• Extends Person by adding IMailRecipient and
  IMailboxStore interfaces
• Extends Folder by adding IMailRecipient
  interface
• CDOEXM extends ADSI
• Extends User with IMailRecipient and
  ImailboxStore interfaces
• Extends Group and Contact with IMailRecipient
  interface

25
CDOEXM IMailRecipient

• Provides access to the properties of a
  mail-enabled recipient in the DS
• Promotes management properties
• Proxy addresses
• Send/deliver limits
• Forwarding properties
• Restricted address properties
• Common management methods
• Mail enable, mail disable

26
CDOEXMIMailboxStore

• Provides access to the properties of a user with
  an Exchange mailbox
• Promotes management properties
• Store quotas
• Garbage collection parameters
• Mailbox location
• Delegates
• Common management methods
• Create, delete and move mailbox

27
CDOEXM - Code SampleMailbox- enabling a user
Dim objUser As IADsUser Dim objMailbox As
CDOEXM.IMailboxStore Set objUser
GetObject("LDAP//exsrv1/CNuser1, OUMarketing
,DCmicrosoft,DCcom") objUser.CreateMailbox
"LDAP//exsrv1/CNPrivate MDB, CNSG1,CNInform
ationStore,CNEXMBSVR, CNServers,CNAG1, C
NAdministrative Groups,CNOrg, CNMicrosoft
Exchange,CNServices, CNConfiguration,DCmicro
soft,DCcom" objUser.SetInfo
Dim objUser As IADsUser Dim objMailbox As
CDOEXM.IMailboxStore
Set objUser GetObject("LDAP//exsrv1/CNuser1,
OUMarketing,DCmicrosoft,DCcom")
objUser.CreateMailbox "LDAP//exsrv1/CNPrivate
MDB, CNSG1,CNInformationStore,CNEXMBSVR,
CNServers,CNAG1, CNAdministrative
Groups,CNOrg, CNMicrosoft Exchange,CNService
s, CNConfiguration,DCmicrosoft,DCcom"
objUser.SetInfo
28
CDOEXM ADSI vs. CDO integration

• ADSI provided for compatibility with existing DS
  scripts and applications
• Use ADSI if you need to manage groups / Exchange
  distribution lists
• CDO method preferred for collaborative
  applications and scripts
• Use CDO if you need to manage Exchange public
  folders

29
CDOEXM DemoCreating a user

• Adding subscribers to our Web site

30
Call To Action

• Leverage the person schema
• Manage contacts in the Web Store
• use OLE DB/ADO and CDO.Person
• Access persons in the DS
• Use CDO.Person, ADSI, OLE DB/ADO
• Use CDO.Person for in-memory behaviors

• Leverage the person schema

• Manage contacts in the Web Store
• Use OLE DB/ADO and CDO.Person

• Access persons in the DS
• Use CDO.Person, ADSI, OLE DB/ADO

• Use CDO.Person for in-memory behaviors
