CIP4 Tools for JDF and JMF

1
JDF Toolkits for JDF and JMF
2
JDF Library and API

• Read, write, work with JDF and JMF files
• Additional high-level routines
• spawn / merge
• Validate / Repair
• Convert Versions
• MIME handling
• Networking

3
JDF Library and API

• JDFLibC C
• Windows VisualC 8 (main), VC7 / VC8
• Mac OS X Xcode 2.4.1, CodeWarrior
• Linux makefiles (last update 2002 (!))
• JDFLibJ Java
• compiled with Java 1.5 (Java 1.6 incoming)
• used extensively by CIP4s JDF tools
• C Translation being evaluated

4
CIP4 JDF Editor

• Visual editor for JDF and JMF files
• Views input/output, process, localized
  capabilities, comments
• Validates
• Capabilities (used for certification)
• XML Schema
• Sends JDF / JMF
• Binaries for Mac and Windows

5
CIP4 JDF Editor
6
CIP4 JDF Utilities

• CheckJDF
• Check validity of JDF files (online and on the
  command line)
• FixJDF
• Update a JDF file to another version
• Both are integrated into the Editor

7
CIP4 JDF Utilities
8
Elk

• application framework providing services needed
  by a JDF device
• Send and receive JMF
• Send and receive JDF
• Job queue
• Execute JDF nodes
• Reference implementation elk-press

9
Alces

• Tool for testing JDF software
• JDF Controller / Manager

10
Bambi

• simple Elk based on Tomcat
• Queue Handling
• Device Simulation
• Message Subscription handling
• Push and Pull workflows
• Simulators can pull jobsfor load balancing

11
Bambi Properties

• JMF Queue
• HTTP
• Hot Folder
• MIME
• JMF Signal Handling
• Device Simulation
• Manual
• Scripted Phases
• Device Proxy
• JDF Visualization

12
Bambi
13
Legal

• Code is open source
• Free for non-commercial use
• Free for in-house use
• Usage in commercial products that are for sale ?
  only for Full and Partner members

14
Links

• Downloads
• http//www.cip4.org/open_source/index.html
• Public Wiki
• http//www.cip4.org/publicwiki
• Subversion
• http//cip4srv2.igd.fhg.de/svnroot/
• Bugtracker Jira
• http//www.cip4.org/jira/secure/Dashboard.jspa
