Problem Solving

1
Problem Solving

• May 4, 2005
• Brandon Beltz

2
Lecture Outline

• Defining problem solving
• goals, problem space, operators
• Solving novel problems
• Types of operators
• brute force, hill climbing, working backward,
  means-end analysis
• Memory and problem solving
• Background knowledge, analogy, functional
  fixedness
• The role of expertise
• Differences between experts and novices
• Becoming an expert
• What can nonexperts tell us about problem
  solving?

3
Problem Solving Overview

• In decision making we select one choice from
  multiple choices.
• We must implement that choice through action.
• Sometimes the actions to take are not obvious,
  which can be a problem.
• Hence we encounter problem solving.

4
Problem Solving Overview

• Problem When a person wants something but
  doesnt immediately know what actions he/she can
  take to get that something.

5
Studying Problem Solving

• Most interesting problems take minutes or more
  to solve.
• Thus, speed (RTs) and accuracy are not usually
  helpful for studying problem solving.
• Verbal protocols more common
• An audio transcription and analysis of subjects
  verbalizations as they solve problems.

6
Defining the problem

• Goal End solution to the problem.
• Well-defined problems explicitly specify the
  goal.
• Examples?
• Ill-defined problems only vaguely specify the
  goal.
• Examples?

7
Defining the problem

• Problem Space Includes the initial state,
  intermediate states, and goal states of the
  problem.
• Also includes the problem solvers knowledge at
  each of these steps.

8
Defining the problem

• Operators The set of legal actions that can be
  performed during problem solving.

9
Defining the problem
Initial State
Goal/ end state
Goal/ end state
10
Studying Problem Solving The Tower of Hanoi

• Tower of Hanoi puzzle
• Well defined problem within cognitive science.

Image http//www.viterbo.edu/personalpages/faculty
/DWillman/
11
Studying Problem Solving The Tower of Hanoi
Puzzle

• Goal Move all three rings from the left peg to
  the right peg
• Operators (rules)
• You can only move one ring at a time
• You cannot put a larger ring on top of a smaller
  ring

12
Problem Space Tower of Hanoi
Initial State
Operators
Image http//www.viterbo.edu/personalpages/faculty
/DWillman/
13
How do people solve novel problems?

• The key is the selection of operators.
• i.e. What actions do we choose?
• Different types of operator selection
• Brute force search
• Hill climbing
• Working backwards
• Means end analysis

14
Brute Force Search

• Exhaustive (serial or parallel) search through
  the problem space.
• Search through all subgoals and operators to find
  the best path to the goal.
• Contrast with
• satisficing
• A form of optimizing?

15
Brute Force Search

• Advantage relatively easy to apply
• e.g. crossword puzzle, garden tool _ake
• Disadvantage combinatorial explosion
• The number of states in the problem space
  increase dramatically with moderate increases in
  attributes of the problem.
• e.g. Chess

16
Operations in Chess

• Chess attributes
• 2 players
• 64 spaces
• 32 pieces
• Each piece has several moves available each turn
• Number of moves per game

17
Operations in Chess

• In the beginning there are a lot of potential
  moves.
• Over time, the number of possible moves goes down
  as pieces are removed from the board.
• There are approximately 1018 potential moves
  during an entire game.
• The problem space is immense- combinatorial
  explosion!

If you thought about each move for 1 second, it
would take 30,000,000,000 years!
18
Operations in Chess

• Computer players / artificial intelligence
• Modern computers have the ability to conduct
  brute force searches.
• Human players
• Must rely on strategies and heuristics.

19
Hill Climbing Heuristic

• Search for an operator that will take you to a
  state in the problem space that appears to be
  closer to the goal than you are now
• Missionaries and cannibals problem

20
Missionaries and Cannibals Problem

• 3 missionaries (M) and 3 cannibals (C)
• All 6 must cross the river in the boat.
• Max 2 people can ride in the boat at a time
• Cannibals can never outnumber missionaries on
  either side of the river.

21
Missionaries and Cannibals Solution
1. 2. 3. 4.
5. 6. 7. 8.
9. 10. 11. 12.
22
Missionaries and Cannibals Solution

• According to the hillclimbing heuristic, people
  should have extreme difficulty performing step 7
• It involves a step backward downhill!

5. 6. 7. 8.
23
Working backward heuristic

• Begin at the goal state of the problem and try to
  work back to the starting state.
• Useful when the goal state is known but the
  initial state is not known.
• e.g. What would I need to do to become mayor?

24
Types of operators

• Hill climbing and working backward have a limited
  range of application as most problems require
  moving backward and forward.

25
Means-End Analysis

• A formalized problem-solving heuristic that uses
  a set of rules about when to work forward or
  backward.
• Also indicates when and how to set subgoals.

26
Means-End Analysis

• Sequence of steps
• Compare the current state with the goal state. If
  no difference, problem solved
• If there is a difference, set a subgoal to solve
  that difference. With more than one difference,
  solve the largest difference
• Select an operator that will solve the difference
  identified in Step 2
• If the operator can be applied, do it. If not,
  set a new subgoal to reach a state to allow the
  application of the subgoal
• Return to Step 1 with the new goal set in Step 4

27
Means-End Analysis

• Think about writing a paper for class
• What is the difference between my current state
  (no paper written) and the goal state (paper
  written)?
• I need a paper topic!
• Set a goal to reduce the difference
• What operator reduces the difference?
• A sheet of paper containing my brainstorming
  ideas
• Apply the operator if I can, if not set a
  subgoal.
• I need a piece of paper to write down my ideas!
• What is the difference between my current state
  (need piece of paper to write down ideas) and the
  goal state (paper written)?
• Repeat until goal is accomplished

28
Types of operators

• Means-End analysis has been successfully
  implemented on computer with the General Problem
  Solver program.
• However, there are a variety of ways to select
  operators to accomplish goals.
• Different problem types are more conducive for
  different methods of selecting operators.

29
The Role of Expertise

• Differences between experts and novices
• Becoming an expert
• What can nonexperts tell us about problem
  solving?

30
Differences between experts and novices

• Experts have more knowledge about the domain
• Demonstrated in chess with memory tasks
• Information is organized differently
• In physics problems, novices organized by surface
  features. Experts by underlying physics
  principles
• Experts might be better at selecting operators
• Originally thought to be the case
• Evidence does not support it now many examples
  in the chess expertise literature

31
Expertise in Chess

• Chess has objective chess rating system (ELO
  rating) that ranks players by wins, losses,
  quality of opponents, etc.
• Grandmaster 2500
• Master 2200-2499
• Expert 2000-2199
• Class A 1800-1999
• Class B 1600-1799
• The rating system allows one to distinguish
  between chess players expertise.

32
Expertise in Chess (Gobet and Simon, 1996)

• Study examining highest ranking chess players
  performance over time
• Garry Kasparov
• Highest ranked player in chess history.
• Grandmaster 2750 rating at the time of the study

Image courtesy of http//en.wikipedia.org/
33
Expertise in Chess (Gobet and Simon, 1996)

• On several different occasions Kasparov played
  simultaneous chess matches (from 1985-1992)
• He usually played six opponents at a time.
• His opponents were rated as chess masters (2400
  rating)

Image courtesy http//www.clubedexadrez.com.br/
Basically, the best player in the world played
simultaneously against the best players of
different countries!
34
Expertise in Chess (Gobet and Simon, 1996)

• Method of play
• One round lasted 3 minutes
• Kasparov had to make one move in six different
  games (6 moves total). 30 seconds per move
• 6 opponents only had to move once in their
  respective games. 3 minutes per move.
• Rounds continued until winner (Kasparov or
  opponent) was decided in each game.

35
Logic of Study Chess(Gobet and Simon, 1996)

• Hypothesis A
• Chess experts can either use extensive look ahead
  strategy and calculate the best move
• Prediction A
• Kasparovs rating will decrease significantly due
  to reduced time to look-ahead and plan.
• Hypothesis B
• Experts rely mostly on memory and past experience
  to recognize the state of the game and choose the
  best move.
• Prediction B
• Kasparovs rating will not be decreased as much
  from the reduced time because he quickly
  recognizes the best move from his extensive chess
  knowledge.

36
Results(Gobet and Simon, 1996)

• Kasparovs rating was reduced slightly to 2650
  during the simultaneous games.
• However, he still won the majority of his games
  and his chess skill was still comparable to the
  best chess grandmasters!
• What do these results tell you about expertise?

37
Becoming an Expert

• Practice
• Inherent Talent

38
Becoming an Expert Practice

• Ericssons (1993) definition distinguishes
  practice from play and performance.
• Subject must be motivated
• Task must be at the appropriate level
• There must be immediate corrective feedback
• Repetition of the same or similar tasks

39
Becoming an Expert Practice

• Evidence comes from a variety of sources not
  typically problem solving domains.
• Ten-Year Rule The phenomenon that experts in
  almost all fields are seldom able to compete at
  the very highest levels with less than a decade
  of intense practice.

40
Effects of Practice
(Ericsson et al., 1996)
41
Becoming an Expert Talent

• Inherent talent
• Some suggest that talents like perfect pitch in
  music can be acquired with practice.
• (Takeuchi Hulse, 1993)
• However, studies with twins suggest that genetic
  component is greater.
• That is identical twins were closer in the degree
  of pitch talent than fraternal twins.
• (Drayna, et al., 2001)

42
Becoming an Expert Summary

• Practice and talent interact
• Developmental stages in achieving expertise.

43
Developmental stages in achieving expertise
(Bloom, 1985)

• Examined common conditions surrounding
  development of experts in various domains
  (sports, music, etc).
• Parents expose child to domain under playful
  conditions child shows promise.
• Parents arrange for instruction from expert who
  works well with children. Practice emphasized!
• Parents show a great deal of enthusiasm and
  provide teachers of increasing expertise as the
  child ages.
• Parents make decision to commit teenager to
  activity full time in order to get the best
  instruction.
• Usually teenager leaves home (college,
  professional academy, etc.)

44
What can nonexperts tell us about problem solving?

• Working Memory Capacity
• High correlations found between working memory
  capacity and problem solving.
• In means-end analysis, one must remember several
  things at a time.
• What steps have I done, what step do I do next,
  how do I do the next step, etc.
• Verbal influences on working memory and problem
  solving
• Instructions which reduce working memory load aid
  problem solving and vice versa.
• (Gilhooly, et al., 1993 Barrouillet, 1996)

45
What can nonexperts tell us about problem solving?

• Setting Subgoals
• Using subgoals can break peoples attempts to use
  memorized solutions steps.
• e.g. functional fixedness
• Comparing Problems
• Transfer to new problems can be effective if
  subjects see the deep structure of a problem.
• e.g. analogies
• However, this is difficult to teach as subjects
  tend not to transfer unless they see an explicit
  reason to do so.

46
End
