Goals and Objectives

1
Stress-Accent and Vowel Quality in The
Switchboard Corpus Steven Greenberg and Leah
Hitchcock International Computer Science
Institute 1947 Center Street, Berkeley, CA
94704 http//www.icsi.berkeley.edu/steveng
NIST Workshop on Large Vocabulary Continuous
Speech Recognition Maritime Institute of
Technology, May 4, 2001
2
Take Home Messages

• There is an intimate relationship between vocalic
  identity, nucleic duration and stress accent in
  spontaneous dialogue (at least in the
  Switchboard corpus)
• Stressed syllables tend to have significantly
  longer nuclei than their unstressed
  counterparts, consistent with the findings
  reported by Silipo and Greenberg in previous
  years meetings regarding the OGI Stories
  corpus (telephone monologues)
• Certain vocalic classes exhibit a far greater
  dynamic range in duration than others
• Diphthongs tend to be longer than monophthongs,
  BUT .
• The low monophthongs (ae, aa, ay, aw,
  ao) exhibit patterns of duration and dynamic
  range under stress (accent) similar to diphtongs
• The statistical patterns are consistent with the
  hypothesis that duration serves under many
  conditions as either a primary or secondary cue
  for vowel height (normally associated with the
  frequency of the first formant)

3
Take Home Messages

• Moreover, the stress-accent system in spontaneous
  (American) English appears to be closely
  associated with vocalic identity
• Low vowels are far more likely to be fully
  stressed than high vowels (with the mid vowels
  exhibiting an intermediate probability of being
  stressed)
• Thus, the identity of a vowel can not be
  considered independently of stress-accent
• The two parameters are likely to be flip sides of
  the same Koine
• Although English is not generally considered to
  be a vowel-quantity language (as is Finnish),
  given the close relationship between
  stress-accent and duration, and between
  duration and vowel quality, there is some sense
  in which English (and perhaps other
  stress-accent languages) manifest certain
  properties of a quantity system
• Thus, vowel duration may be an important factor
  in disambiguating spoken language and therefore
  should be of interest to the speech
  recognition community

4
What is (usually) Meant by Prosodic Stress?

• Prosody is supposed to pertain to extra-phonetic
  cues in the acoustic signal
• The pattern of variation over a sequence of
  SYLLABLES pertaining to syllabic DURATION,
  AMPLITUDE and PITCH (fo) variation over time
  (but the plot thickens, as we shall see)

5
Why is Prosodic Stress Important?

• It supposedly provides important information
  about
• Focus of the speakers attention and emphasis for
  the listener
• What is new and important information
• Emotional context of the utterance - surprise,
  sarcasm, shock, delight anger impatience, etc.
• Syntactic disambiguation, particularly at the
  clausal/sentential level e.g., interrogative,
  declarative forms
• Perceptual processing - parsing the utterance
  into chunks for reliable understanding
• Prosody provides a window onto the higher levels
  of language
• Can be useful for developing
  semantic-oriented models for speech
  understanding (Information spotting)
• Prosody affects pronunciation (and vice versa)
• Can be useful for modeling pronunciation
  variation in ASR
• Phonetic properties may be correlated with
  prosodic stress -
• THIS IS THE TOPIC FOR TODAYS PRESENTATION

6
The Nitty Gritty (a.k.a. the Corpus Material)

• SWITCHBOARD PHONETIC TRANSCRIPTION CORPUS (same
  as Phoneval-2000)
• Switchboard contains informal telephone dialogues

• 54 minutes of material that had previously been
  phonetically transcribed (by highly trained
  phonetics students from UC- Berkeley)
• 45.5 minutes of pure speech (filled pauses,
  junctures filtered out), consisting of
• 9,991 words, 13,446 syllables, 33,370 phonetic
  segments
• All of this material had been hand-segmented at
  either the phonetic- segment or syllabic level
  by the transcribers
• The syllabic-segmented material was subsequently
  segmented at the phonetic-segment level by a
  special-purpose neural network trained on
  72-minutes of hand-segmented Switchboard
  material. This automatic segmentation was
  manually verified

7
Evaluation Material Details

• AN EQUAL BALANCE OF MALE AND FEMALE SPEAKERS
• BROAD DISTRIBUTION OF UTTERANCE DURATIONS
• 2-4 sec - 40, 4-8 sec - 50, 8-17 sec - 10
  (mean 4.75 s)
• COVERAGE OF ALL (7) U.S. DIALECT REGIONS IN
  SWITCHBOARD
• A WIDE RANGE OF DISCUSSION TOPICS
• VARIABILITY IN DIFFICULTY (VERY EASY TO VERY
  HARD)

By Subjective Difficulty
By Dialect Region
Number of Utterances
Subjective Difficulty
Dialect Region
8
Manual Transcription of Stress Accent

• 2 UC-Berkeley Linguistics students each
  transcribed the full 45 minutes of material
  (i.e., there is 100 overlap between the 2)
• Three levels of stress-accent were marked for
  each syllabic nucleus
• Fully stressed (78 concordance between
  transcribers)
• Completely unstressed (85 interlabeler
  agreement)
• An intermediate level of accent (neither fully
  stressed, nor completely unstressed (ca. 60
  concordance)
• Hence, 95 concordance in terms of some level of
  stress
• The labels of the two transcribers were averaged
• In those instances where there was disagreement,
  the magnitude of disparity was almost always
  (ca. 90) one step. Usually, disagreement
  signaled a genuine ambiguity in stress accent
• The illustrations in this presentation are based
  solely on those data in which both transcribers
  concurred (i.e., fully stressed or completely
  unstressed)
• A table containing the complete set of data is in
  a paper submitted to Eurospeech (in the
  workshop notebook)

9
The Conventional Wisdom on Stress-Accent

• "Pitch is widely regarded, at least in English,
  as the most salient determinant of prominence. In
  other words, when a syllable or word is perceived
  as 'stressed' or 'emphasized,' it is pitch height
  or a change in pitch, more than length or
  loudness that is likely to be mainly responsible
  (see, for example, Fry 1958, Grimson 1980, pp.
  222-226, Lehiste 1976, Fudge, 1984, ch. 1)"
• Clark, J. and Yallop, C. (1990) An Introduction
  to Phonetics and Phonology. Oxford, Blackwell, p.
  280.
• "In fact, although it is clear that stressed
  syllables often have greater overall acoustic
  intensity than weakly stressed ones, loudness
  seems to be the least salient and least
  consistent of the three parameters of pitch,
  duration and loudness - at least for purposes
  such as signaling stress" (ibid, p. 282)
• Thus, acording to the general consensus the
  important parameters are (in order) - PITCH,
  DURATION, LOUDNESS
• (the latter most closely correlated with TOTAL
  ENERGY (i.e., duration x amplitude, cf. further
  on)

10
OGI Stories - Pitch Doesnt Cut the Mustard

• Although pitch range is the most important of the
  fo-related cues, it is not as good a predictor
  of stress as DURATION

11
Total Energy is the Best Predictor of Stress

• Duration x Amplitude is superior to all other
  combination pairs of acoustic parameters. Pitch
  appears redundant with duration.

12
A Brief Primer on Vocalic Acoustics

• Vowel quality is generally thought to be a
  function primarily of two articulatory properties
  - both related to the motion of the tongue
• The front-back plane is most closely associated
  with the second formant frequency (or more
  precisely F2 - F1) and the volume of the
  front-cavity resonance
• The height parameter is closely linked to the
  frequency of F1
• In the classic vowel triangle segments are
  positioned in terms of the tongue positions
  associated with their production, as follows

13
Duration/Amplitude/Int. Energy - Which?

• There are supposed to be large differences in the
  intrinsic amplitude and duration of vowels
• Could such differences be compensated for in
  terms of stress?
• Lets take a closer look!

14
Amplitude Differences - Stressed/Unstressed

• There are very small differences in amplitude
  between stressed and unstressed nuclei
• The lax monophthongs tend to be have a slightly
  larger dynamic range than diphthongs

15
Durational Differences - Stressed/Unstressed

• There is a large dynamic range in duration
  between stressed and unstressed nuclei
• Diphthongs and tense, low monophthongs tend to
  have a larger range than the lax monophthongs

16
Int. Energy Differences - Stressed/Unstressed

• There is a large dynamic range in integrated
  energy between stressed and unstressed nuclei
• Diphthongs and tense, low monophthongs tend to
  have a larger range than the lax monophthongs

17
Spatial Patterning of Duration and Amplitude

• Lets return to the vowel triangle and see if it
  can shed light on certain patterns in the
  vocalic data
• The duration, amplitude (and their product,
  integrated energy, will be plotted on a 2-D
  grid , where the x-axis will always be in terms
  of hypothetical front-back tongue position (and
  hence remain a constant throughout the plots to
  follow)
• The y-axis will serve as the dependent measure,
  sometimes expressed in terms of duration, or
  amplitude, or their product

18
Dipthongal Amplitude and Vowel Height
All nuclei
19
Monopthongal Amplitude and Vowel Height
All nuclei
20
Amplitude - Monophthongs vs. Diphthongs
Monophthongs
Diphthongs
All nuclei
21
Diphthongal Duration and Vowel Height
All nuclei
22
Monopthongal Duration and Vowel Height
All nuclei
23
Duration - Monophthongs vs. Diphthongs
All nuclei
24
Dipthongal Int. Energy and Vowel Height
All nuclei
25
Monopthongal Int. Energy and Vowel Height
All nuclei
26
Int. Energy - Monophthongs vs. Diphthongs
All nuclei
27
Dipthongal Amplitude and Vowel Height
Stressed nuclei
28
Dipthongal Amplitude and Vowel Height
Unstressed nuclei
29
Monopthongal Amplitude and Vowel Height
Stressed nuclei
30
Monopthongal Amplitude and Vowel Height
Unstressed nuclei
31
Amplitude - Monophthongs vs. Diphthongs
Monophthongs
Diphthongs
Stressed
Unstressed
32
Diphthongal Duration and Vowel Height
Stressed nuclei
33
Diphphthongal Duration and Vowel Height
Unstressed nuclei
34
Monopthongal Duration and Vowel Height
Stressed nuclei
35
Monopthongal Duration and Vowel Height
Unstressed nuclei
36
Duration - Monophthongs vs. Diphthongs
Monophthongs
Diphthongs
Stressed
Unstressed
37
Dipthongal Int. Energy and Vowel Height
Stressed nuclei
38
Dipthongal Int. Energy and Vowel Height
Unstressed nuclei
39
Monopthongal Int. Energy and Vowel Height
Stressed nuclei
40
Monopthongal Int. Energy and Vowel Height
Unstressed nuclei
41
Int. Energy - Monophthongs vs. Diphthongs
Monophthongs
Diphthongs
Stressed
Unstressed
42
Mystery Parameter

• There is one other parameter which when plotted
  in a vowel triangle plot shows an interesting
  pattern
• This is - proportion of stressed an unstressed
  nuclei

43
Proportion of Stress Accent and Vowel Height
44
Amplitude - Monophthongs vs. Diphthongs
Monophthongs
Diphthongs
All nuclei
45
Duration - Monophthongs vs. Diphthongs
All nuclei
46
Int. Energy - Monophthongs vs. Diphthongs
All nuclei
47
Summary and Conclusions

• There is an intimate relationship between vocalic
  identity, nucleic duration and stress accent in
  spontaneous dialogue (at least in the
  Switchboard corpus)
• Stressed syllables tend to have significantly
  longer nuclei than their unstressed
  counterparts, consistent with the findings
  reported by Silipo and Greenberg in previous
  years meetings regarding the OGI Stories
  corpus (telephone monologues)
• Certain vocalic classes exhibit a far greater
  dynamic range in duration than others
• Diphthongs tend to be longer than monophthongs,
  BUT .
• The low monophthongs (ae, aa, ay, aw,
  ao) exhibit patterns of duration and dynamic
  range under stress (accent) similar to diphtongs
• The statistical patterns are consistent with the
  hypothesis that duration serves under many
  conditions as either a primary or secondary cue
  for vowel height (normally associated with the
  frequency of the first formant)

48
Summary and Conclusions

• Moreover, the stress-accent system in spontaneous
  (American) English appears to be closely
  associated with vocalic identity
• Low vowels are far more likely to be fully
  stressed than high vowels (with the mid vowels
  exhibiting an intermediate probability of being
  stressed)
• Thus, the identity of a vowel can not be
  considered independently of stress-accent
• Thus, vowel duration may be an important factor
  in disambiguating spoken language and therefore
  should be of interest to the speech
  recognition community
