PDA Programming Using J2ME

1
PDA Programming Using J2ME

• Presenter???
• Date2003/4/8

2
Out line

• Introduction J2ME
• CLDC/MIDP API
• Preparation of programming
• Examples
• HTTP Connection, RMS DB, SOAP, XML
• Instruction of application development
• Step by step

3
What is J2ME

• Java platform for small devices
• A subset of Java 2 Standard Edition
• For programming the Plam
• For programming the mobile device (e.g mobile
  phones or WinCE)

CDC (Connected Device Configuration) CLDC
(Connected Limited Device Configuration)
4
What is J2ME (cont)
Profiles Layer
Configuration Layer
5
Configurations Layer

• A configuration defines the minimum set of
  libraries and VM capabilities
• Devices have similar processing and power and
  memory constraints
• EX CDC (Connected Device Configuration)
• CLDC (Connected Limited Device Configuration)

6
Profiles Layer

• A profiles layer is a set of Java Based API that
  extend the J2ME definition
• UI and presentation capabilities are generally
  defined at this layer
• EX CLDC gt MIDP (Mobile Information Device
  Profile)
• CDC gt Personal Profile
• CDC gt Foundation Profile

7
CLDC (Connected Limited Device Configuration)

• Addresses
• Java language and virtual machine features
• Core Java Libraries
• Input/Output
• Networking
• Security
• Not Addresses (but in MIDP)
• User Interface functionality
• Event handling
• High-Level application model
• Application life-cycle management

8
CLDC API

• io
• InputStream, OutputStream, Reader, Writer
• lang - No floating point support
• util
• Calendar, Date, Hashtable, Random, Stack,
  TimeZone, Vector, Enumeration
• javax.microedition.io
• Connection, Datagram, InputConnection,
  OutputConnection, Connector

9
MIDP API

• javax.microedition.midlet
• (application management)
• javax.microedition.lcdui
• High-level development
• Form, TextBox, List, Alert
• Low-level development
• Canvas Game applications will likely make heavy
  use of the
• javax.microedition.rms
• RecordStore
• A record store consists of a collection of
  records which will remain persistent across
  multiple invocations of the MIDlet

10
MIDP API Tree
View
Displayable
Form
Text Box
List
Alert
Canvas
Date Field
Text Field
String Item
Command
Ticker
Choice Group
11
Third-party API

• XML Parser KXML1.2, KXML2.0, Xparse-J 1.1 ...
• Web Services KSOAP 1.2
• Floating support MathFP 2.06

API must based on CLDC/CDC or MIDP
12
Programming the Palm Part 1 Choice
Development Environment

• J2ME CLDC API
• Contains a subset of the standard J2SE classes
• J2ME KJAVA API(J2ME1.0.3)
• GUI components
• Access the Palm database (PDB)
• Access to IR port
• Kawt API(J2ME1.0.3)
• Rich GUI components
• J2ME MIDP API
• Works on the top of CLDC
• Some GUI components

13
Programming the Palm Part 2 Choice KVM or
Java Virtual Machine

• Different KVM has different support
• KVM (Support J2ME)
• IBM J9 (Support J2ME and specific devices API
  support)

14
Programming the Palm Part 3 Choice
Development Toolkit

• J2ME Wireless Toolkit
• Support Palm
• IBM WebSphere (Device Developer)
• Support Palm, WinCE and other devices
• JBuilder 7,8 MobileSet
• Based on J2ME Wireless Toolkit

15
XML Example Using KXML1.2 API
16
RMS Example
17
HTTP Connection Example
18
SOAP Example Using KSOAP API
19
Links

• http//cs.mis.nsysu.edu.tw/J2ME/
• http//www.javaworld.com/channel_content/jw-j2me-i
  ndex.shtml
