Cellular Respiration

1
Cellular Respiration

• Chapter 9

2
Cellular Respiration

• Cellular Respiration is the process by which food
  is broken down to produce energy
• 6O2 C6H12O6 ? 6CO2 6H2O Energy

3
Three Steps to Cellular Respiration

• Glycolysis
• Citric Acid Cycle (Krebs Cycle)
• Electron Transport Chain
• Figure 9-2

4
(No Transcript)
5
Glycolysis
6
Glycolysis

• Happens in the cytoplasm
• Does not require oxygen (anaerobic)
• Converts glucose to pyruvic acid
• Creates electron carrier NADH

7
Energy in Glycolysis

• Energy used 2 ATP
• Energy produced 4 ATP
• 2 NADH
• Net ATP 2 ATP
• Figure 9-37

8
Citric Acid Cycle
9
Citric Acid Cycle

• Happens in the mitochondria
• Requires oxygen (aerobic)
• Pyruvic acid enters the cycle and is broken down
• Creates electron carriers NADH, FADH2
• CO2 leaves the cycle

10
Energy in the Citric Acid Cycle

• Energy produced 4 NADH
• 1 FADH2
• 1 ATP
• Figure 9-6

11
Electron Transport Chain
12
Electron Transport Chain

• Happens in the mitochondria between the inner
  membrane and the matrix
• Requires oxygen (aerobic)

13
Electron Transport Chain

• NADH and FADH2 donate their electrons
• Electrons flow down a series of proteins and are
  finally accepted by H
• H and O2 form a molecule of H2O
• The movement of the electrons creates a
  concentration gradient of H

14
Electron Transport Chain

• ATP Synthase uses the energy from diffusion of H
  to power the synthesis of ATP
• Purpose of Electron Transport Chain Formation of
  ATP

15
Energy in Electron Transport Chain

• Energy Used 2 NADH
• 1 FADH2
• Energy Produced 32 ATP
• Figure 9-7

16
Electron Transport Chain
17
Fermentation

• Fermentation releases energy from food molecules
  in the absence of oxygen
• What happens after glycolysis if no oxygen is
  present
• Anaerobic No oxygen required! No oxygen present!

18
Fermentation

• Two major types of fermentation
• 1. Lactic Acid Fermentation
• 2. Alcoholic Fermentation

19
Lactic Acid Fermentation

• Happens in the muscles
• Uses NADH produced in glycolysis to convert
  pyruvic acid to lactic acid
• Pyruvic acid NADH ? lactic acid NAD
• Figure 9-4

20
(No Transcript)
21
Alcoholic Fermentation

• Happens in yeasts and other microorganisms
• Uses NADH to convert pyruvic acid to alcohol and
  CO2
• Pyruvic acid NADH ? alcohol CO2 NAD

22
(No Transcript)
