National Instruments

1

• National Instruments
• Educational Laboratory
• Virtual Instrumentation Suite
• ( NI ELVIS )

2
NI ELVIS What is it?

• System appropriate to teach electrical system
  design and prototyping
• System designed to develop LabVIEW-based
  measurement applications aided by a suite of
  virtual instruments
• Suitable for measurements and design applications
  in EE, ME, Biomedical and physical sciences
  instructional labs
• Source code for virtual instruments provided
• Basic design developed by an instructor
• Curriculum under development

3
Overview

• Integrated
• All the functionality needed to develop
  measurement applications in one single system
• Industry standard user interface
• Open, flexible
• Modifiable software rather than stand-alone
  executables
• Slot for a protoboard or custom signal
  conditioning PCB
• Adaptable to various experiments and courses
• Robust
• High-voltage and short-circuit protection

4
Overview

• Easy to use / repair
• Standard connectivity with banana and 9-pin D Sub
  (Digital I/O)
• Smooth transition from manual knob to LabVIEW
  front panel
• Removable protoboard, protection board
• Low cost
• Fraction of the cost of a suite of traditional
  instruments
• Curriculum
• Proposal submitted to NSF for the development of
  six courses
• Contact National Instruments if you are
  interested

5
ELVIS Components
Cable
LabVIEW
E Series Data Acquisition Board
Workstation and Protoboard
6
Small Footprint
7
Virtual Instrument Set

• Signal Analyzers
• Oscilloscope, DSA, Bode analyzer,
  Current-Voltage Analyzers
• DC Measurements
• DMM
• Sources
• Function Generator, Arbitrary Waveform Generator
• Timing / Digital
• Frequency and Interval counters, Digital I/O
• DC Power Supply
• Manual and Programmable Control

8
Instrument Launcher

• Source code provided
• Multiple instruments at once
• LabVIEW instrument driver for customization

9
Virtual Oscilloscope

• Features
• Up to 1.25 MHz Sampling rate
• 12 bit vertical resolution
• 100 mV-10 V full scale
• Analog or digital trigger
• Data Storage

10
Virtual DMM

• Features
• Measurements
• Volts DC, AC
• Current DC, AC
• Resistance
• Capacitance
• Diode tester
• Audible Continuity tester
• Autoranging
• 3 digit precision

11
Virtual Function Generator

• Features
• Manual or software control
• Sine, triangle, square waveforms
• Frequency Sweep
• TTL sync pulse out
• AM, FM modulation

12
Virtual Bode Analyzer

• Features
• Frequency and phase plots
• Frequency range and step control
• Logarithmic or linear frequency spacing
• Data Storage
• Cursors, Auto Scaling
• Ch 0 response, Ch 1 stimulus

13
Virtual DSA

• Features
• Frequency and time domain plots
• Frequency range based on E series board sampling
  rate
• Averaging modes
• Data Storage
• Markers, Auto Scaling
• Linear, dB scales

14
Arbitrary Waveform Generator

• Features
• Dual channel (DAC 0,1)
• 10 V, 12 bit
• One-shot or continuous generation
• 1 MHz update rate max
• Waveform Editor
• Periodic sine, triangle, square, ramp, brush,
  heartbeat
• Harmonic waveform composition up to 9th
  harmonic in amplitude phase
• Pulse impulse, rect, sinc, exponential,
  Gaussian, Lorentzian
• Noise white, 1/f, 60 Hz harmonics,
  superpositions of all three for realistic
  testing
• General Combinations Any additive or
  multiplicative (AM or FM modulation)

15
Current Voltage Analyzer

• Features
• /- 10 V, /- 10 mA
• Two point and three point capability
• Current or voltage control
• Data Storage

16
Summary

• Product is under development expected to be
  released in 2003
• Comprehensive analog and digital electronics
  curriculum under development
• Appropriate for EE, ME, BME and Physics
• Please contact Ravi Marawar (ravi.marawar_at_ni.com)
  for further information

17
Thank You, Thank You Very Much!
