PeerDirect Distributed Enterprise

1
PeerDirect Distributed Enterprise
Reach Your Technical Peak The Final
Ascent Session IV Q4 2003
2
PeerDirect Distributed Enterprise
Agenda

• Introduction to Database Replication
• Architecture Overview
• Configuration
• Replication Rule Design
• APIs and Event Callback
• Administration

3
PeerDirect Distributed Enterprise
Agenda

• Introduction to Database Replication
• Architecture Overview
• Configuration
• Replication Rule Design
• APIs and Event Callback
• Administration

4
Introduction to Database Replication
Why Database Replication?

• Back-up
• Fail-over
• Latency avoidance
• Load balancing
• Reporting
• Distributed environments

5
Introduction to Database Replication
Define Distributed?
Remote Offices
Data Center
Remote Users
6
Introduction to Database Replication
Goals of a Distributed Enterprise

• Latency avoidance
• Risk avoidance
• Application functionality

7
Introduction to Database Replication
What if
Remote Offices
Data Center
Remote Users
8
Introduction to Database Replication
PeerDirect Distributed Enterprise

• Breaks dependency on centralized application
  architectures
• Radically improves employee productivity with
  decentralized applications
• Disconnected use
• Creates an inherently resilient application
  architecture
• Eliminates the latency and availability problems
  caused by the centralized model

9
Introduction to Database Replication
Approaches

• Log based
• Database activity logged for periodic replay at
  all locations
• Queue based
• Middleware intercepts application to database
  activity for periodic replay at all locations
• Table based
• Captures changes, queries source and duplicates
  values at all locations

10
Introduction to Database Replication
Drawbacks of each approach

• Log based
• Log size
• Can not remain dormant long
• Periodically need to re-synch
• Inefficient use of bandwidth
• Typically only hub and spoke topology
• Queue or Message based
• All of the above
• Application must be modified
• Table based
• Not real-time
• Increases database size

11
PeerDirect Distributed Enterprise
Agenda

• Introduction to Database Replication
• Architecture Overview
• Configuration
• Replication Rule Design
• APIs and Event Callback
• Administration

12
Architecture Overview
The Basics

• Table based
• Vs Log or Queue based
• System tables for storing metadata
• Engine appears as another user
• Access via SQL and ODBC

13
Architecture Overview
Features and benefits
Feature
Benefit

• Bi-directional update-everywhere model
• Read-write data between multiple databases

• Replicate, synchronize, and distribute corporate
  data across multiple locations

14
Architecture Overview
Features and benefits
Feature
Benefit

• Scheduled synchronization
• Net change compression
• Strong encryption
• Subset data using slices

• Maximize network efficiency, reduce costs
• Security
• Controlled access to data

15
Architecture Overview
Features and benefits
Feature
Benefit

• Replicates between different database types
• MS SQL Server and Progress
• Oracle and PostreSQL
• Supported databases
• Progress
• Oracle
• SQL Server
• DB2

• Share data in mixed environments
• Consolidated view of corporate data

16
Architecture Overview
Features and benefits
Feature
Benefit

• Multiple topologies supported
• Peer-to-peer
• Hub and spoke
• Load balance clustering

• Provide new options for building scalable systems
• Flexible configurations

17
Architecture Overview
Features and benefits
Feature
Benefit

• Auto-discovery of nodes within the replication
  network

• Improve quality of service and system
  availability
• Improved system administration
• Allows mobile workers who are disconnected or
  have low-bandwidth limitations access to
  enterprise applications

18
Architecture Overview
Features and benefits
Feature
Benefit

• Database level configuration
• Adds needed tables to replicated database to
  manage replication
• Does not modify user-defined tables

• Existing application does not necessarily need to
  be altered

19
Architecture Overview
Patented replication technology

• Dynamic Data Slicing Architecture (DDSA)
• Table partitioning - schema
• Work set partitioning - query
• Column level partitioning - fragment
• Dynamic data migration
• Dynamic Bandwidth-Managed Partner Selection (DBP)
• Auto-discovery, auto-balanced
• Avoids overloading any one server
• Backbone, server and workstation algorithms
• Collision Avoidance Methodology (CAM)
• Record fragment management related columns
• Consistent resolution contracts
• Rich API for custom resolution

20
Architecture Overview
Table-based
Application
Database
Data Table M Rows
PK
Control Tables 1 table per database table
Control Table M Rows
PK
System Tables 41 tables of setup data
21
Architecture Overview
PeerDirect Distributed Enterprise

• Principal components

PeerDirect Distributed Enterprise
(PDDE)
ReplicationEngine(PDRE)
ReplicationDesigner(PDRD)
ReplicationAdministrator(PDRA)
22
PeerDirect Distributed Enterprise
Agenda

• Introduction to Database Replication
• Architecture Overview
• Configuration
• Replication Rule Design
• APIs and Event Callback
• Administration

23
Configuration
Replication Engine

• Communicates via SQL through ODBC
• The closer the Replication Engine is to the
  database, the better the performance
• Supports Win32 and Linux
• Configuration of InnerEdge and OuterEdge servers
  affect the way in which sites will be replicated

24
Configuration
PDRE setup
25
Configuration
Site Types

• Site Types
• 3 Types
• Complete
• High Availability
• Low Availability
• Based upon
• Data set
• Connectivity
• Determines replication partner selection

26
Configuration
Engine placement

• Considerations
• A Replication Engine should be on either end of
  any WAN connection
• PDRE traffic is compressed and encrypted whereas
  ODBC traffic is not
• On a LAN, consider fault tolerance and
  performance vs. cost of hardware
• Engine may reside on a different platform
• Win32 and Linux

27
Configurations
Site types

• Dynamic partner selection algorithms allow for
  load balancing and fault tolerance
• Partner selection is affected by a sites type
• Available site types
• Low Availability
• High Availability
• Complete

28
Configurations
Site types

• Low Availability
• Sites that are mostly or occasionally
  disconnected
• Compact
• High Availability
• Sites that are mostly connected but do not
  contain all data
• Spine sites

29
Configuration
Simple Topologies Inner Edge

• High Availability sites
• All or most data slices
• Reliable connectivity

Data Center
30
Configuration
Simple Topologies Outer Edge

• High or Low availability sites
• Pertinent data slices
• Questionable connectivity

Remote Office
31
Configuration
Sample PDDE Topology
Remote Office
Remote Office
Data Center
32
Configuration
Distributed Enterprise

• Aircraft Manufacturer
• Aircraft maintenance application
• Maintenance records were handled either on paper
  or in different centralized databases
• Maintenance issues cause commercial aircraft
  delays and military readiness issues
• Solution One PeerDirect InnerEdge Server and
  multiple OuterEdge Workstations
• Remote capabilities, work sets, and occasionally
  connected users
• Aircraft maintenance data captured while aircraft
  is being maintained resulting in significant cost
  savings

InnerEdge
33
Configuration
Distributed Enterprise

• Medical Imaging
• Patient test results contain images and complex
  data sets
• Data only available at site where test performed
• Collaboration with doctors at other locations
  nearly impossible
• Solution One PeerDirect InnerEdge Server and
  multiple OuterEdge Workstations
• New test introduced into replication network
• Can be viewed by physician at any location at
  anytime

InnerEdge
34
PeerDirect Distributed Enterprise
Agenda

• Introduction to Database Replication
• Architecture Overview
• Configuration
• Replication Rule Design
• APIs and Event Callback
• Administration

35
Replication Rule Design
Basic steps to defining rules

• Specify the application database
• Select the tables to replicate
• Define fragments to minimize the number of data
  collisions
• Subset data into work sets
• Arrange tables in transaction sets and/or groups
• Verify and save rules
• Prepare to activate replication-enabled database

36
Replication Rule Design
Partial Sports2000 Schema
Analyze the schema
37
Replication Rule Design
Generic replication

• Unit of replication is whole record
• Changes occur at multiple locations
• One user changes Addr
• One user changes Limit
• Can cause False Collisions

Name
Addr
City
Zip
Ctry
Pymt
Rating
Limit
?
?
38
Replication Rule Design
Common solution to generic replication

• Unit of replication is each field
• Changes occur at multiple locations
• One user changes Addr and Limit
• One user changes Addr and Zip
• Can cause Silent Data Corruption

Name
Addr
City
Zip
Ctry
Pymt
Rating
Limit
Name
Addr
City
Zip
Ctry
Pymt
Rating
Limit
?
?
?
?
39
Replication Rule Design
PeerDirect solution - fragments

• Unit of replication is a group of fields
• Changes occur at multiple locations
• One user changes Addr and Limit
• One user changes Addr and Zip
• Helps avoid False Collisions
• Optimizes the replication cycle

Name
Addr
City
Zip
Ctry
Pymt
Rating
Limit
?
?
?
?
40
Replication Rule Design
Introduction to work sets

• PeerDirect allows you to define the business
  rules for sub-setting around base tables

Ctry
Prod
Off
Off
Prod
Cust
Price
Price
Hist
Credit
Acct
ADetl
Trans
TDetl
41
Replication Rule Design
Defining work sets

• Define the Ctry base table
• Subscribe the site to its country

42
Replication Rule Design
Work sets

• Each site stores "all and only" the data it needs
• Tables belonging to work sets are replicated
  based on a request, called a subscription
• Nesting work sets allows for further sub-setting
  of data

43
Replication Rule Design
Introduction to transactions

• A set of insert, update or delete operations
• A single unit of work
• Must be completed as a whole
• Offer the ability to enforce data integrity
• Two types of transactions supported
• Transaction sets
• Transactions groups

44
Replication Rule Design
Transaction sets

• Maintains transaction integrity of dependant
  table during incomplete replication session
• Updates all dependant records in a single unit of
  work
• Must include a base table
• Creation process similar to work sets

45
PeerDirect Distributed Enterprise
Agenda

• Introduction to Database Replication
• Architecture Overview
• Configuration
• Replication Rule Design
• APIs and Event Callback
• Administration

46
APIs and Event Callback
APIs

• Available for use by all third-party developers
• Available in both Unicode and ANSI
• 32-bit C-style function calls (standard calling
  convention)

47
APIs and Event Callback
API categories

• Errors and Logging
• Control
• Command
• Configuration
• Database Record Information
• Event Handling
• Miscellaneous

48
APIs and Event Callback
Event handler callbacks

• Allows you to modify some behavior
• Receive various kinds of event notifications
• PDRE events include
• Replication monitoring
• Custom conflict resolution
• Enhanced logging
• Write and register custom DLLs
• Sample code
• C\Program Files\PeerDirect\pdre\Samples\EvntClbck

49
PeerDirect Distributed Enterprise
Agenda

• Introduction to Database Replication
• Architecture Overview
• Configuration
• Replication Rule Design
• APIs and Event Callback
• Administration

50
Administration
Remote protocol

• PDRE process listens for commands on port 2584
• Network security infrastructure must be
  configured to pass TCP data on this port
• ASCII protocol
• Provides interactive or programmatic interface

51
Administration
Remote protocol example
52
Administration
GUI Administrator

• Administers the replication network
• Maintenance of site information
• Subscribing and unsubscribing to and from slices
• Setting up replication schedules
• Allows for remote administration of all tasks
