On the Security of RFID

1
On the Security of RFID

• Hung-Min Sun (???)
• Information Security Lab.
• Department of Computer Science
• National Tsing Hua University

2
What is RFID?

• Radio-Frequency Identification Tag

Reference http//glossary.ippaper.com
3
Roles of RFID applications
Secure channel
Tags
Reader
Server(Database)
4
Barcode v.s. RFID
Barcode
RFID

• can be read at much greater
• distances
• unique object id
• more expensive

• require a direct line of sight to the
• printed barcode
• have no read/write capability
• cheap

Reference www.cs.utexas.edu/shmat/
5
Where Are RFID Used?

• Physical-access cards
• Inventory control
• Gillette Mach3 razor blades, ear tags
• on cows, kid bracelets in waterparks,
• pet tracking
• Logistics and supply-chain management
• Track a product from manufacturing through
  shipping to the retail shelf
• Gas station and highway toll payment
• Mobile SpeedPass

Reference www.cs.utexas.edu/shmat/
6
Commercial Applications of RFID

• RFID cost is dropping dramatically, making it
  possible to tag even low-value objects
• Around 5c per tag, 100 for a reader
• Logistics and supply-chain management is the
  killer application for RFID
• Shipping, inventory tracking, shelf stocking,
  anti-counterfeiting, anti-shoplifting
• Massive deployment of RFID is in the works
• Wal-Mart pushing suppliers to use RFID at pallet
  level, Gillette has ordered 500,000,000 RFID tags

Reference www.cs.utexas.edu/shmat/
7
Future Applications of RFID

• Location Awareness
• Health Care
• Apparel
• Smart Shelf

Reference http//www.rfidjournal.com/
8
RFID Tag Power Sources

• Passive (this is what mostly used now)
• Tags are inactive until the readers
  interrogation signal wakes them up
• Cheap, but short range only
• Semi-passive
• On-board battery, but cannot initiate
  communication
• Can serve as sensors, collect information from
  environment for example, smart dust for
  military applications
• More expensive, longer range
• Active
• On-board battery, can initiate communication

Reference www.cs.utexas.edu/shmat/
9
Security Problems of RFID

• Eavesdropping
• Hot-listing
• Attacker has special interests in certain items
• Replay attack
• Cloning
• Tracing
• Data forging
• Denial of Service

Fundamental problem Lack of mutual authentication
10
Cryptography and Authentication
11
Cryptographic System
12
Four Basic Services of Cryptography

• Confidentiality (Secrecy) The intruder cannot
  read the encrypted message from the ciphertext.
• Authentication It should be possible for the
  receiver of a message to ascertain its origin an
  intruder should not be able to masquerade as
  someone else.
• Integrity It should be possible for the receiver
  of a message to verify that it has not been
  modified in transit an intruder cannot
  substitute a false message for a legitimate one.
• Nonrepudiation A sender should not be able to
  falsely deny later that he sent a message.

13
Cryptographic System

• Symmetric Cryptosystem The encryption
  decryption keys are
• the same. (EK(M) C DK(C) M).
•  Asymmetric Cryptosystem Encryption
  decryption keys are
• different. (EK1(M)C DK2(C)M)
• The encryption key is public, while the
  decryption key can not be
• calculated from the public key.

14
Symmetric Cryptosystem

• DES (1977)
• IDEA (1992)
• RC5 (1994)
• AES (2001)

15
Asymmetric Cryptosystem

• RSA (1978)
• El-Gamal (1984)
• McEliece (1978)
• Knapsack (1978)

16
RSA (Encryption Decryption)

• Public key n pq, p and q are large primes
  (512 bit),
• e ( gcd (e, (p-1)(q-1)) 1)
• Private key d, where ed 1 mod (p-1)( q-1)
• Encryption CM e mod n
• Decryption M C d mod n
• p47, q71, gt n3337
• e79, gt d 1019
• M688
• Encryption CM e mod n 68879 mod 3337 1570
• Decryption M C d mod n 15701019 mod 3337 688

17
One-way hash function

• A hash (also known as a message digest) is a
  one-way function. It is considered a one-way
  because its not practical to figure out what
  input corresponds to a given output.
• We will use the term hash and message digest
  interchangeably. The NIST message digest function
  is called SHA-1, which stands for secure hash
  algorithm, whereas the MD in the MD2,MD4,MD5
  algorithm stands for message digest.

18
One-way hash function

• Input X (unlimited length)
• Output YH(X) (fixed length, e.g., 160 bit)
• Given X, it is easy to compute Y.
• Given Y, and H( ), it is computational infeasible
  to compute X.
• Given X and Y, it is computational infeasible to
  find X such that YH(X).

19
One-way hash function

• There certainly will be many message that yield
  the same message digest, because a message can be
  of arbitrary length and the message digest will
  be fixed length, for instance 128bits.
• By trying lots of messages, one would eventually
  find two that mapped to the same message digest.
• The problem is that lots is so many that it is
  essentially impossible.

20

• The significant difference between a secret key
  algorithm and a message digest algorithm is that
  a secret key algorithm is designed to be
  reversible and a message digest algorithm is
  designed to be impossible to reverse.
• In this section well use MD as a generic
  message digest algorithm.

21
Computing a MAC with a Hash

• The obvious thought is that MD(m) is a MAC for
  message m. But it isnt. anyone can compute
  MD(m).
• We concatenate a shared secret KAB with the
  message m, and use MD(KABm) as the MAC.
• Some proposals with no known weaknesses are
• Put the secret at the end of the message instead
  of at the beginning.
• Use only half the bits of the message digest as
  the MAC

22

• Concatenate the secret to both the front and the
  back of the message.
• We call any hash combining the secret key and the
  data a keyed hash.

23
HMAC

• HMAC result from an effect to find a MAC
  algorithm that could be proven to be secure if
  the underlying message digests compression
  function was secure.
• They defined secure as having two properties
• Collision resistance
• An attacker doesnt know the key K cannot compute
  the proper digest(K,x) for data x, even if the
  attacker can see the value of digest(K,y) , for
  arbitrary numbers of inputs y, with y no equal to
  x.

24
How to achieve Mutual Authentication between
two parties?
25
Authentication functions

• By Message encryption
• The ciphertext of the entire message serves as
  its authenticator
• By Message authentication code (MAC)
• A public function of the message and a secret key
  that produces a fixed-length value that serves as
  the authenticator
• By Hash function
• A public function that maps a message of any
  length into a fixed-length hash value, which
  serves as the authenticator

26
Authentication (a)

• Symmetric encryption

Stores Key K
Stores Key K
RFID tag is authenticated If M DK(C)

• Confidentiality and authentication

27
Authentication (b)

• Public-key encryption

Uses Readers private key
Uses Readers public key
RFID tag is authenticated If M Dprivate_key(C)

• Only Confidentiality

28
Authentication (c)

• Public-key encryption

Uses tags public key
Uses tags private key
RFID tag is authenticated If M Dpublic_key(C)

• Authentication and signature

29
Authentication (d)

• Hash function

Stores key K
Stores key K
RFID tag is authenticated If DK(C)Hash(M)

• Confidentiality and authentication

30
Authentication (e)
Authentication (e)

• 30

31
However, RFID tag

• No or very limited power
• Little memory
• Static 64- or 128-bit identifier in current
  5-cent tags
• Little computational power
• A few thousand gates at most
• Static keys for read/write access control
• Not enough resources to support public- or
  symmetric-key cryptography
• Cannot support modular arithmetic (RSA, DSS),
  elliptic curves, DES, AES hash functions are
  barely feasible
• Is resettable
• Passive tag resets when power off

32
Physical Solutions for RFID
33
Physical Solutions

• Kill tag after purchase
• Faraday cage
• Active jamming
• Disables all RFID, including legitimate
  applications
• Guardian
• Blocker Tag

34
Killing approach

• Special command permanently de-activates tag
  after the product is purchased
• Disables many futuristic applications

Reference www.rsa.com/rsalabs/staff/bios/ajuels/
35
Faraday Cage

• Container made of foil or metal mesh,
  impenetrable by radio signals of certain
  frequencies
• Shoplifters are already known to use foil-lined
  bags
• Maybe works for a wallet, but huge hassle in
  general

Reference www.rsa.com/rsalabs/staff/bios/ajuels/
36
Active Jamming (Guardian)

• A mobile battery-powered device that offers
  personal RFID security and privacy management.

Reference http// www.rfidguardian.org
37
Blocker Tag (The RXA Pharmacy)
Reference http// www.rfidjournal.com
38
Blocker Tag How Does the Reader Read a Tag?

• When the reader sends a signal, more than one
  RFID tag may respond this is a collision
• Reader cannot accurately read information from
  more than one tag at a time
• Example every tagged item in a supermarket cart
  responds to the cashiers RFID reader
• Reader must engage in a special singulation
  protocol to talk to each tag separately
• Tree-walking is a common singulation method
• Used by 915 Mhz tags, expected to be the most
  common type in the U.S.

Reference www.cs.utexas.edu/shmat/
39
Blocker Tag Tree Walking
Reference www.cs.utexas.edu/shmat/
prefix0
prefix1
Reader broadcasts current prefix
Each tag with this prefix responds with its next
bit
prefix00
prefix01
prefix10
prefix11
If responses dont collide, reader adds 1 bit to
current prefix, otherwise tries both
possibilities
000
001
010
011
100
101
110
111
Every tag has a k-bit identifier
This takes O(k ? number of tags)
40
Blocker Tag Example
Reference www.cs.utexas.edu/shmat/
1. Prefixempty
prefix0
prefix1
1a. Prefix0
1b. Prefix1
2. Prefix00
2. Prefix11
prefix00
prefix01
prefix10
prefix11
000
001
010
011
100
101
110
111
41
Blocker Tag
Reference www.cs.utexas.edu/shmat/
Rivest, Juels, Szydlo

• A form of jamming broadcast both 0 and 1 in
  response to any request from an RFID reader
• Guarantees collision no matter what tags are
  present
• To talk to a tag, reader must traverse every tree
  path
• With 128-bit IDs, reader must try 2128 values
  infeasible!
• To prevent illegitimate blocking, make blocker
  tag selective (block only certain ID ranges)
• E.g., blocker tag blocks all IDs with first bit1
• Items on supermarket shelves have first bit0
• Cant block tags on unpurchased items
  (anti-shoplifting)
• After purchase, flip first bit on the tag from 0
  to 1

42
EPCglobal Class 1 Generation 2

• Most popular in long-range RFID applications
• Frequency 860-960 MHz
• Reading range10-20 Feet
• ISO 18000-6C

Reader
RFID tag
Memory Read/Write Other commands

• slide 42

43
Problems in EPCglobal C1G2

• Long reading range
• A naïve protection
• Use of 16-bit random number
• Tag ID is transmitted in plaintext
• Lack of reader-to-tag authentication

Malicious Reader
RFID tag
Memory Read/Write Other commands

• slide 43

44
Secure Protocols for RFID
45
Secure RFID Protocols

• Hash-based Approaches
• 1 S. Weis, Security and Privacy in
  Radio-Frequency Identification Devices, masters
  thesis, Massachusetts Inst. of Technology (MIT),
  Massachusetts, USA, May 2003.
• 8 M. Ohkubo, K. Suzuki, and S. Kinoshita,
  Cryptographic Approach to Privacy-Friendly
  Tags, RFID Privacy Workshop, MIT, Massachusetts,
  USA, Nov. 2003.
• 9 T. Dimitriou, A Lightweight RFID Protocol to
  protect against Traceability and Cloning
  Attacks, Proc. 1st IEEE Conf. Security and
  Privacy for Emerging Areas in Comm. Networks
  (SecureComm 05), Sep. 2005.
• 12 G. Tsudik, YA-TRAP Yet Another Trivial
  RFID Authentication Protocol, Proc. 4th IEEE
  Intl Conf. Pervasive Computing and Comm.
  (PerCom06), Mar. 2006.
• 13 G. Avoine and P. Oechslin, A Scalable and
  Provably Secure Hash Based RFID Protocol, Proc.
  3rd IEEE Intl Workshop Pervasive Computing and
  Comm. Security (PERCOMW 05), Mar. 2005.
• 14 D. Henrici and P. M uller, Hash-Based
  Enhancement of Location Privacy for
  Radio-Frequency Identification Devices Using
  Varying Identifiers, Proc. First IEEE Intl
  Workshop Pervasive Computing
• and Comm. Security (PerSec 04), Mar. 2004.
• 36 Ohkubo, M., Suzuki, K., and Kinoshita, "RFID
  privacy issues and technical challenges," Commun.
  ACM 48, 9 (Sep. 2005).

46
Secure RFID Protocols

• Lightweight Approaches
• 23 A. Juels, Strengthening EPC Tags Against
  Cloning, Manuscript, RSA Laboratories, Mar.
  2005.
• 24 Y.C. Chen, W.L. Wang, and M.S. Hwang, RFID
  Authentication Protocol for Anti-Counterfeiting
  and Privacy Protection, Proc. 9th IEEE Intl
  Conf. Advanced Comm. Technology (ICACT 07), Feb.
  2007.
• 25 A. Juels, Minimalist Cryptography for
  Low-Cost RFID Tags, Proc. 4th Intl Conf. on
  Security in Comm. Networks (SCN 04), Sep. 2004.
• 26 Y.Z. Li et al., Security and Privacy on
  Authentication Protocol for Low-cost RFID, Proc.
  Intl Conf. Computational Intelligence and
  Security (CIS 06), Nov. 2006.
• 27 P. Peris-Lopez et al., M2AP A Minimalist
  Mutual-Authentication Protocol for Low-Cost RFID
  Tags, Proc. 3rd Intl Conf. Ubiquitous
  Intelligence and Computing (UIC-06), Sep. 2006.
• 29 H.Y. Chien, SASI A New Ultralightweight
  RFID Authentication Protocol Providing Strong
  Authentication and Strong Integrity, IEEE T.
  Dependable Secure Comput., vol. 4, no. 4, pp.
  337340, 2007.
• 32 D.N. Duc et al., Enhancing Security of
  EPCglobal Gen2 RFID Tag against Traceability and
  Cloning,
• Proc. 3rd Conf. Symp. Cryptography and Inf.
  Security (SCIS06), Jan. 2006.
• 35 A. Juels and S. Weis, Authenticating
  Pervasive Devices with Human Protocols. Crypto,
  Aug. 2005.

47
Security Analysis of RFID Protocols
48
SoHow to design a secure protocol for low-end
RFID Tag?
49
Hung-Min Sun and Wei-Chih Ting , A Gen2-based
RFID Authentication Protocol for Security and
Privacy, accepted by IEEE Transactions on
Mobile Computing, Dec. 2008.
50
Gen2

• Setup at manufacturer
• After sold

Write Tag keypool
M
Write Tag keypool
M
Tag keypool
U
End users or companies
51
Gen2

• In use

Reader
RFID tag
U
End users or companies
52
Gen2
a
b
(a,b)
U
53
Gen2

• Results before enhancement

54
Gen2

• In use

Reader
RFID tag
U
End users or companies
55

• Results after enhancement

lt 10 rounds
56
Possible applications

• Scenario A (Express gate)

ck
Verify ck
57
Possible applications

• Scenario B (Indoor self management)

mobile RFID (reader embedded) e.g. ETRI WCDMA
phone
Payment, advertisement, touretc
Documents, drugs, foodetc
58
Possible applications

• Scenario C (Outdoor passive blocking)

???
Query
59
Thank YouQ A
