Title: Spatial Information Systems SIS


1
Spatial Information Systems (SIS) COMP
4025 Spatial access methods Indexing
2
Spatial Indexes
Used to speed up spatial queries Example Point
query return the geometric object that contains
a given query point Sequentially scanning all
objects of a large collection to check whether
they contain the query point involves a high
number of disk accesses and the repetition of the
evaluation of computationally expensive geometric
predicates (e.g., containment, intersection,
etc.) Reducing the set of objects to be
processed is highly desirable
3
Indexes for object-based and space-based
representations
Indexes for raster data based on recursive
subdivision of the space Example
quadtrees Indexes for vector data differ
depending on the type data (extensions of
quadtrees are used also for vector data)
4
Vector Data Indexing
  • Different indexing methods are used for point,
    linear and polygonal data
  • In the case of collections of polygons, instead
    of indexing the object geometries themselves,
    whose shapes might be complex, we consider an
    approximation of the geometry and index it
    instead
  • Most commonly used approximation minimum
    bounding rectangle (MBR) also called minimum
    bounding box (MBB)

5
MBRs
  • By using the MBR as the geometric key for
    building the spatial index, we save the cost of
    evaluating expensive geometric predicates during
    index traversal (as geometric tests againsts an
    MBR is constant)
  • Example point-in-polygon test
  • In addition, the space required to store a
    rectangle is constant (2 points)

(x,y)
(x,y)
6
MBRs (cont.d)
  • An operation involving a spatial predicate on a
    collection of objects indexed on their MBRs is
    performed in two steps
  • Filter step selects the objects whose MBR
    satisfies the spatial predicate (by traversing
    the spatial index and applying the predicate to
    the MBRs)
  • Refinement step the objects that pass the
    filter step are a superset of the solution. An
    MBR might satisfy the predicate but the
    corresponding object might not

P
MBR
obj
7
Refinement step
Refinement step the objects that pass the
filter step are a superset of the solution. An
MBR might satisfy the predicate but the
corresponding object might not Therefore, in
this step the spatial predicate is applied to the
actual geometry of the object
8
Oracle Spatial Query Model
Exact Result Set
9
Oracle Spatial Indexing Methods
  • Two types of indexes are implemented in Oracle
    Spatial
  • R-trees
  • Quadtrees

10
R-trees
  • Based on MBRs (minimum bounding rectangles)
  • Defined for indexing 2D objects (can be extended
    to higher dimensions but implemented only for 2D
    in Oracle Spatial)
  • MBRs of geometric objects form the leaves of the
    index tree
  • Multiple MBRs are grouped into larger rectangles
    (MBRs) to form intermediate nodes in the tree
  • Repeat until one rectangle is left that contains
    everything

11
R-trees
R-tree
1
2
3
4
8
6
5
9
7
12
Remark nodes
  • Intermediate nodes store
  • MBRs of collections of objects
  • Leaf nodes store
  • MBRs of individual object
  • Pointers to storage location of the exact
    geometry

13
Searching R-tree
  • We consider two types of queries
  • point query what object contains the query
    point
  • window query what objects intersect the query
    window

14
Basic spatial queries (1)
  • Containment Query Given a spatial object O, find
    all objects in the collection that completely
    contain O. When O is a point, the query is called
    Point Query

P
Containment Query
Point Query (also Point-in-polygon, or Point
Location)
15
Basic spatial queries (2)
  • Region Query Given a region R, find all objects
    in the collection that intersect R. When R is a
    rectangle, the query is called Window Query

R
R
Region Query
Window Query
16
Searching R-trees window query
  • Compare search window with MBRs stored at each
    node
  • starting at root node
  • Stop at leaf nodes
  • compare contained geometries with search window

17
Searching R-trees window query
  • Example

R-tree
1
2
3
4
8
6
5
9
7
18
Example remarks
  • If no MBRs are used check the query window
    against all geometries for intersection
    (computationally expensive)
  • In some cases, using R-trees to structure the set
    of MBRs can cause more tests (against MBRs) to be
    done. In general, this is not the case

19
Searching R-trees point query
  • Test query point for inclusion in MBRs stored at
    each node
  • starting at root node
  • Stop at leaf nodes
  • Test query point for inclusion in exact
    geometries

20
Searching R-trees window query
  • Example

R-tree
1
2
3
4
8
6
5
9
7
21
Building R-trees
  • An R-tree is a depth-balanced tree in which each
    node corresponds to a disk page (i.e., the number
    of entries in each node is limited)
  • The structure satisfies the following properties
  • For all nodes in the tree (except the root) the
    number of entries is between m and M
  • The root has at least two children (unless it is
    a leaf)
  • All leaves are at the same level

22
Example (1)
R-tree
1
2
3
4
8
6
5
9
7
m 2 M 3
23
Example (2)
R-tree
m 2 M 4
24
Important remarks
  • Note that the MBRs (at all levels) can overlap
  • A rectangle is stored as child of a bigger
    rectangle only if completely contained in it
  • Example
