Title: Flash and Flash Remoting with Building Blocks


1
Blackboard Building Blocks
Building Blocks and Macromedia Flash/Flash
Remoting
Timothy Chi, Senior Director of Technology
Monday, July 27, 2009
2
Presentation Overview
  • Blackboard and Macromedia corporate relationship
  • Breaking the HTML barrier
  • Introduction to Flash and Flash Remoting
  • Building Blocks and Flash
  • Case Study The Blackboard Group Management
    Project

3
Blackboard Inc and Macromedia Inc
  • Corporate Relationship

4
Blackboard and Macromedia
  • Corporate relationship since 2001
  • Various groups work together, usually with
    executive sponsorship
  • Many opportunities to explore as new products are
    brought to market
  • Exciting opportunities in e-Education arena

5
Examples of discussions
  • Publish to Blackboard feature in Macromedia
    Dreamweaver MX
  • Publish to Blackboard feature in Macromedia
    Contribute MX
  • Enhanced support for Flash applications within
    Blackboard environment
  • Upcoming Macromedia products (recently Macromedia
    Breeze)

6
Breaking the HTML Barrier
  • The value of Rich Internet Applications for
    e-Education

7
Rich Internet Applications
  • Rich client environment for Internet content and
    applications
  • Improved quality of end-user applications,
    leading to more relevant and easier to use
    end-use experiences
  • Providing dynamic data in a way that takes
    advantage of new media, layout, and design options

8
Rich IA using Flash MX
  • Allows developers and designers to break the
    HTML barrier
  • Creativity in layout, tweening, multimedia,
    navigation, and workflows
  • Build applications that are easier to use
  • Enhance the efficiency of a workflow
  • Delivers an entirely new experience to end
    users

9
Ideas for Blackboard
  • Drag-and-drag management of users to for course
    or organization
  • Rich UI for Gradebook for sorting, re-arranging
    columns, reporting
  • Rich UI for creating/managing assessments
    including using question pools, re-arranging
    questions, drag-and-drop questions
  • Many more

10
Flash MX and Flash Remoting
  • Just the basics

11
Flash MX Basics
  • Macromedia client software for developing highly
    visual interactive content and applications
  • The Flash Player is used by over 414 million
    people, and installed in 98 of all
    Internet-enabled devices

12
Flash MX Basics contd
  • The IDE has a timeline based metaphor for
    developing highly interactive and rich
    applications
  • Action Script is a proprietary scripting language
    used to extend functions built in the IDE
  • Pre-built User Interface Components accelerate
    time to market

13
Flash Remoting MX Overview
  • Gateway technology that connects Macromedia Flash
    MX components on the client side with server-side
    application services.
  • Flash Remoting enables a Flash MX client to
    seamlessly interface with remote components
    running on an application server in a fast,
    efficient, secure, and reliable way.
  • Flash Remoting service in ColdFusion MX can also
    be used with other server technologies, such as
    Java classes, EJBs, Mbeans,and .NET Framework
    languages like ASP.NET, VB.NET, and C.
  • Flash Remoting Components for Flash MX at
    http//www.macromedia.com/software/flashremoting/d
    ownloads/components/
  • Flash Remoting Server Files available at
    Macromedia Site

14
Building Blocks and Flash
  • Piecing it together to develop a compelling Rich
    UI Building Block

15
Review
  • Flash applications are designed to run within a
    web-browser
  • Flash Remoting is a technology that allows Flash
    applications to connect to server-side
    applications
  • For us, this means that Flash applications have
    access to all the objects, methods, and data
    available through Building Blocks!

16
Hooking It Up (part 1)
  • Install Flash Remoting Components for Flash MX
  • Install Flash Remoting Server Components on any
    machine
  • Drop the flashgateway.jar file into the Building
    Block package (WEB-INF/lib)
  • Edit the web.xml file to register the servlet
    mapping for the Remoting Component
  • FlashGatewayServlet
  • Flash Gateway Servlet
  • Servlet-based plugin to the Flash
    Server Gateway
  • flashgateway.controller.GatewaySer
    vlet 1
    tartup
  • FlashGatewayServlet
  • /gateway/

17
Hooking It Up (part 2)
  • Create your Java Data Access Layer, and ensure
    that you have complementary ActionScript objects
    (wrapper layer for Blackboard APIs)
  • Build the Flash application
  • Create a JSP page launch point for your Building
    Block
  • 4553540000" codebase"http//download.macromedia.c
    om/pub/shockwave/cabs/flash/swflash.cabversion6,
    0,0,0" WIDTH"600" HEIGHT"450" id"groupLaunch"
    name"groupLaunch" ALIGN""
  • eIdgatewayUrl"
  • bgcolorFFFFFF WIDTH"550" HEIGHT"400"
    NAME"groupLaunch" ALIGN"" TYPE"application/x-sh
    ockwave-flash" PLUGINSPAGE"http//www.macromedia.
    com/go/getflashplayer"

18
Hooking It Up (part 3)
  • Depending on your application server
    (Weblogic/Tomcat), edit the .policy file to allow
    for certain permissions to be used (necessary for
    Flash Remoting)
  • permission java.lang.reflect.ReflectPermission
    "suppressAccessChecks"
  • permission java.lang.RuntimePermission
    "accessClassInPackage.macromedia.mxExamples.groupM
    anagement"
  • 9. Package and try your new Flash Building Block
    out (on a development machine!)

19
Case Study Rich UI for Group Management
  • A joint project by Macromedia and Blackboard
    designed to reduce the learning curve for
    Building Block developers

20
Case Study The Bb Group Manager
  • Goals
  • Prove that Flash (via Flash Remoting) could
    indeed be used with Building Blocks
  • One of Macromedias first proof of concepts with
    the launch of the MX line of products
  • Showcase the power of Rich Internet Applications
    and the potential impact on user interface design
    for Blackboard

21
The Development Team
John Bennett Macromedia Inc Strategic Services
Group
Branden Hall FigLeaf Inc Product Development
Timothy Chi Blackboard Inc Product Development
22
Development Methodology
  • Initial meeting Design, architecture, and
    development of object model
  • Simultaneous development of Flash application,
    Data Access Layer, and Building Blocks code
  • Component testing
  • Joint testing after component testing completed
  • Beta, Release, etc

23
The End Result
  • One-click toggles for group options
  • Sort-able columns
  • Show Members feature
  • Drag-and-drop assignment of members to a group
    during creation and modification
  • User role displayed by different icons
  • Assign feature allows for multiple members to
    be assigned to multiple groups at same time
  • Random assignment of members to groups

24
Tips
  • Wherever possible, place both the data and logic
    on the server. Only send data for display to the
    client.
  • Take advantage of locating (or caching) data on
    the client for your application when possible.
    The client-side software is what makes a rich
    user experience possible.
  • Acquire Macromedia Flash and ActionScript
    development expertise
  • Leverage the Macromedia Flash component reuse
    model
  • Utilize available tools
  • Macromedia Flash debugger
  • NetConnection debugger
  • Macromedia Flash debug player
  • Application Server logfiles
  • Use component-based development to eliminate bugs
    early
  • Be creative!

25
Conclusion
  • Rich Internet Applications will bring us into the
    next creative frontier, adding a new dimension to
    online teaching and learning.
  • Having a platform for creating and delivering
    Rich Internet Applications will be increasingly
    important
  • Now you know how!

26
Thank You

Demos to Follow
