A 2'4GHz 0'18um CMOS SelfBiased Cascode Power Amplifier

1
A 2.4-GHz 0.18-um CMOS Self-Biased Cascode Power
Amplifier
IEEE JOURNAL OF SOLID-STATE CIRCUITS, VOL. 38,
NO. 8, AUGUST 2003
Tirdad Sowlati, Member, IEEE, and Domine M. W.
Leenaerts, Senior Member, IEEE

• ???????
• ?????
• ???????

2
Introduction (1)

• Oxide breakdown sets a limit on the maximum
  signal swing on drain.
• Hot carrier degradation is a reliability issue.
  It increases the threshold voltage and
  consequently degrades the performance of the
  device.
• Cascode configuration and thick-oxide transistors
  have been used.

3
Introduction (2)

• This work demonstrates a 0.18-um CMOS self-biased
  cascode RF power amplifier that operates at 2.4
  GHz and provides 23 dBm from a 2.4-V supply
  voltage for Class-1 Bluetooth application.
• By using standard oxide thickness devices in the
  process, the design takes full advantage of the
  technology and its high Ft.

4
Conventional cascode amplifier and Voltage
waveforms versus time
5
Self-biased cascode amplifier and Voltage
waveforms versus time
6
Bootstrapped cascode amplifier and Voltage
waveforms versus time
7
Two-stage self-biased cascode PA
8
Simulate output power, gain, and PAE
9
Conventional and Self-biased Cascode PA
10
Microphotograph of the PA
11
Measured Pout , gain, and PAE versus Pin
12
Pout versus time of continuous operation
13
Bluetooth spectrum at the output of the PA
14
SLIDING BIAS TECHNIQUE

• To improve the linearity of a PA
• Operate the PA in class A/AB mode
• Use a bias boosting or gain boosting at the
  compression point
• Employ a de-biasing technique at low and
  intermediate power levels to have the same gain
  at the maximum power

15
Measured Gain and PAE versus Pout for
constant/sliding gate bias voltages
16
Measured phase variations versus inputs power for
constant/sliding bias
17
Conclusion

• A self-biased cascode topology was applied to
  reduce hot carrier effects.
• No performance degradation occurs after ten days
  of continuous operation under maximum output
  power conditions.
• Using a sliding biasing technique on both stages,
  improve the PAE at low/mid-power level and
  linearize the PA.
