Chapter 3:Atoms and the Periodic Table

1
Chapter 3Atoms and the Periodic Table

• Section 1 and 2

2
Bell Ringer

• Name the following elements and give their atomic
  number

3
Atoms

• Smallest particle
• Neutrons
• Protons
• Electrons

4
Atoms

• Unreacted atoms have no overall charge.
• Although atoms are mode of charged particles,
  they do not have an overall charge because they
  have an equal number of protons and electrons
  whose charges cancel

5
Electrons

• Exist in energy levels
• The number of filled energy levels an atom has
  depends on the number of electrons

6
Energy Levels

• Electrons are found in orbitals within energy
  levels
• An orbital is a region in an atom where there is
  a high probability of finding electrons
• A s orbital is shaped like a sphere
• A p orbital is dumbbell shaped and can be
  oriented three different ways in space

7
Orbitals

• Every atom has between one and eight valence
  electrons
• Valence electrons are found in the outermost
  shell of an atom and determine the atoms
  chemical properties
• Valence electrons are the electrons in an atom
  that participate in chemical bonding

8
Bell Ringer

• Name the following elements and give their atomic
  number

9
Chapter 4-Atoms and the Periodic Table

• Section 2 A Guided Tour of the Periodic Table

10
Objectives

• Relate the organization of the periodic table to
  the arrangement of electrons within an atom
• Explain why some atoms gain or lose electrons to
  form ions
• Determine how many protons, neutrons, and
  electrons an atom has given its symbol, atomic
  number and mass number
• Describe how the abundance of isotopes affects an
  elements average atomic mass

11
Organization of the periodic table

• The periodic table groups similar elements
  together.
• This organization makes it easier to predict the
  properties of an element based on where it is in
  the periodic table.
• Elements are listed in order of number of
  protons, because the periodic law states that
  when elements are arranged this way, similarities
  in their properties will occur in a regular
  pattern

12
Organization of the periodic table

• The periodic table helps determine electron
  arrangement.
• Horizontal rows in the periodic table are called
  periods.
• Just as the number of protons an atom has
  increases as you move from left to right across a
  period, so does its number of electrons.

13
Organization of the periodic table

• Elements in the same group have similar
  properties.
• A group is a vertical column of elements in the
  periodic table.
• Atoms of elements in the same group have the same
  number of valence electrons, so these elements
  have similar properties.

14
Atoms Ions

• An ion is an atom or group of atoms that has lost
  or gained one or more electrons and has a
  negative or positive charge.
• A lithium atom loses one electron to form a 1
  charged ion
• A fluorine atom gains one electron to form a 1-
  charged ion

15
How do the structures of Atoms Differ?

• The atomic number, Z, of an atom equals the
  number of protons in the nucleus.
• The mass number, A, of an atom equals the number
  of protons plus the number of neutrons in the
  nucleus.

16
Atomic Number
17
Mass Number
18
How do the structures of Atoms Differ?

• An isotope is an atom that has the same number of
  protons as other atoms of the same element but
  have a different number of neutrons.
• Example Hydrogen has three isotopes, shown below.

19
How do the structures of Atoms differ?

• If you know the atomic number and mass number of
  an atom, you can calculate the number of
  neutrons it has.
• Example uranium-235 has a mass number of 235.
  Like all uranium atoms, it has an atomic number
  of 92. The number of neutrons it has is
  therefore
• Mass number (A) 235
• Atomic number (Z) 92
• Number of neutrons 143

20
Isotope
Another common form isotopes are written in
is Chlorine-35 or Chlorine-37
21
Atomic Mass Unit

• Because the mass of a single atom is so tiny,
  atomic masses are usually expressed in atomic
  mass units.
• An atomic mass unit (amu) is equal to one twelfth
  of the mass of a carbon-12 atom.
• The average atomic mass for an element is a
  weighted average of the masses of all
  naturally-occurring isotopes of an element.

22
Homework

• Section 2 Review
• Problems 1-8
• Page 119
• Study the first 30 elements of the periodic table

23
Bell Ringer

• Find the number of protons, electrons and
  neutrons for the following isotopes
• Oxygen-18
• Sulfur-38
• Iron-56
• Uranium-239
• Potassium-41
• Tungsten-163

24
Section Two Quiz

• Elements in the same horizontal row, or period,
  have the same number of valence electrons and
  similar chemical properties.
• True or False.
• What is an ion?
• How are isotopes of an atom different from one
  another?
• What unit is commonly used to express atomic
  masses?

25
Chapter 4-Atoms and the Periodic Table

• Section 3 Families of Elements

26
Objectives

• Locate alkali metals, alkaline-earth metals, and
  transition metals in the periodic table
• Locate semiconductors, halogens, and noble gases
  in the periodic table
• Relate an elements chemical properties to the
  electron arrangement of its atoms

27
How Are Elements Classified?

• The elements are classified into three groups.
• Most elements are metals, elements that are shiny
  and conduct heat and electricity well.
• Nonmetals, all except hydrogen of which are found
  on the right side of the periodic table, may be
  solids, liquids, or gases at room temperature.
• Between these groupings are semiconductors,
  elements that can conduct electricity under
  certain conditions.

28
How Are Elements Classified?

• The periodic table below shows the distribution
  of metal, nonmetals, and semiconductors in the
  periodic table.

29
Metals

• The alkali metals, found in Group 1 of the
  periodic table, are very reactive.

30
Metals

• The alkaline-earth metals, whichinclude calcium,
  are found in Group 2 of the periodic table, and
  are somewhat less reactive than the alkali
  metals.

31
Metals

• The transition metals, such as gold, iron, and
  mercury, occupy Groups312 of the periodic
  table.

32
Nonmetals

• Carbon is found in three different forms and can
  form many compounds.
• Nonmetals and their compoundsare plentiful on
  Earth.

33
Nonmetals

• Semiconductors are intermediateconductors of
  heat and electricity
• Silicon is the most familiar semiconductor
• Silicon is an important part of computer chips,
  as well as other semiconductor devices such as
  transistors, LED display screens, and solar cells

34
Halogens and Noble Gases

• Halogens, such as chlorine, are located in Group
  17
• Noble gases, such as neon, make up Group 18 and
  are unreactive

35
Classwork

• Section 3 Review
• Problems 1-8 on page 128

36
Homework

• Study for quiz on the first 30 elements

37
Bellringer

• List three nonmetals and tell what they are used
  for
• List three metals and tell what they are used for

38
Chapter 4-Atoms and the Periodic Table

• Section 4 Using Moles to Count Atoms

39
Objectives

• Explain the relationship between a mole of a
  substance and Avogadros constant
• Find the molar mass of an element by using the
  period table
• Solve problems converting the amount of an
  element in moles to its mass in grams, and vice
  versa

40
Counting Things

• There are many different counting units for
  example, eggs are packaged by the dozen.
• The mole is useful for counting small particles.
• A mole (abbreviation mol) is the number of
  particles that is the same as the number of atoms
  of carbon in 12 g of carbon-12.
• Avogadros constant is the number of particles
  per mole of a substance 6.022 1023

41
Counting Things

• Moles and grams are related.
• The mass in grams of 1 mol of a substance is
  called its molar mass.
• For example, 1 mol of carbon-12 atoms has a molar
  mass of 12.00 g.
• The molar mass of an element is its average
  atomic mass, which is listed in the periodic
  table.

42
Calculating with Moles

• To convert between moles and grams and vice
  versa, you can use a conversion factor a ratio
  that is derived from the equality of two
  different units.
• Lets say that a shopkeeper knows that exactly
  10 gumballs have a total mass of 21.4 g. This
  relationship can be written as either one of two
  equivalent conversion factors

43
Math Skills

• Using your conversion factor
• What is the mass of exactly 50 gumballs?

44
Calculating with Moles

• An elements molar mass can be used as a
  conversion factor.
• The diagram below shows how to set up the
  conversion factor, depending on whether you want
  to convert from amount to mass or the other way
  around.

45
Math Skills

• Converting Amount to Mass
• Determine the mass in grams of 5.5 mol of iron

46
Math Skills

• Converting Mass to Amount
• Determine the amount(mol) of iron present in
  352g of iron

47
Classwork

• Practice Problems 1-3 page 132
• Practice Problems 1-4 page 133
• HOMEWORK
• Section 4 Review
• Problems 1-9
• Page 134
• Study for Quiz
