SESSION 2 FACTORIAL ANOVA AND RELATED TOPICS

1
SESSION 2 FACTORIAL ANOVA AND RELATED
TOPICS
2
The one-way ANOVA

• In Mondays session, I revised the one-way ANOVA.

• We saw that merely obtaining a significant F and
  therefore rejecting the null hypothesis of
  equality of the means was just the first step.
• Before leaving the one-way ANOVA, we must look at
  some more of the techniques that are used in the
  follow-up analysis.

3
Does SIGNIFICANT mean SUBSTANTIAL?

• The F test produced a significant result.
• The null hypothesis of equality of the five
  treatment means must be rejected.
• With large numbers of observations, however, a
  statistical test can have too much POWER to
  reject the null hypothesis, that is, even tiny
  differences among the means will result in a
  significant F.
• Significant does not necessarily mean
  substantial.

4
Partition of the total sum of squares
5
Eta squared

• The oldest measure of effect size is suggested by
  the partition of the total sum of squares.
• In this measure, the between groups sum of
  squares is expressed as a PROPORTION of the total
  sum of squares.
• The greater the proportion of the total sum of
  squares that is accounted for by the between
  groups sum of squares, the greater should be the
  spread among the means in the population.

6
Eta squared (where eta is the CORRELATION RATIO)
7
Maximum value of eta squared

• If there were differences among the treatment
  means and NO ERROR VARIANCE AT ALL (everyone in
  each group got the same score), the value of eta
  squared would be 1.

8
Minimum value

• If there were no differences among the means, the
  between groups sum of squares would be zero and
  so would the value of eta squared.

9
Range of eta squared

• Theoretically, therefore, eta squared can take
  values between zero and (plus) one.
• In practice, its values will lie somewhere
  between these limits.

10
Why is eta called the correlation ratio?

• Suppose that opposite each of the 50 scores in
  the one-way drug experiment, we were to place the
  value of the mean of the participant group in
  which the score was achieved.
• The correlation between the column of scores and
  the column of means gives the value of eta.
• Lets demonstrate this.

11
Use the Aggregate command
12
The Aggregate procedure

• In SPSS, the Aggregate procedure places opposite
  each score a value (such as the mean but other
  statistics can be chosen) which summarises the
  scores in the group.
• The group is specified as the BREAK VARIABLE.
• The participants score (the DV) is the VARIABLE
  TO BE SUMMARISED.

13
(No Transcript)
14
The column of means has been created
15
Now correlate the means with the scores
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
The square of the correlation between the
scores and the group means is eta squared.Eta
is the correlation between the group means and
the scores.
20
(No Transcript)
21
What eta squared is supposed to be measuring in
the population
22
Positive bias

• Eta squared is positively biased as an estimate
  of effect size.
• Were the experiment to be repeated many times,
  the long run average or EXPECTED VALUE of eta
  squared would be higher than the population
  value.

23
Omega squared

• Omega squared is another measure of effect size,
  intended to be an unbiased estimate of the
  following

24
This estimate of omega squared tries to overcome
the positive bias in eta squared
25
GPower

• There is an excellent package, available free on
  the Internet, which can answer many important
  questions about power and sample size.
• You must explore this package and get to know how
  to use it.
• To use GPower, you must express your questions
  in terms of another measure of effect size, known
  as Cohens f.

26
Cohens f
27
(No Transcript)
28
(No Transcript)
29
Equivalent values

• We have found that the estimate of omega squared
  from our data is 0.39.
• Applying the equivalence formula, we find that

30
Which measure?

• SPSS provides only the eta squared measure.
• A journal editor might ask you to provide an
  estimate of omega squared or f.
• On the other hand, there are experimental designs
  for which it is difficult to produce unbiased
  estimates of omega squared and f. In such
  situations, we must make do with eta squared.

31
Using the table

• If you have only a value of eta squared, compare
  it with the values in the omega squared column of
  the table. Your reader, however, may expect you
  to convert your eta squared to the equivalent
  value of omega squared.

32
Multiple comparisons

• When there are three or more groups, the
  rejection of the null hypothesis leaves many
  important questions unanswered, such as the
  location of robust differences among the
  individual treatment means.
• On Monday, I discussed the making of specific
  PRE-PLANNED comparisons, simple and complex,
  among the individual treatment means.

33
Two-group t test
34
k-group t statistic for multiple pairwise
comparisons
35
More power

• If you use the error term for the whole design,
  rather than one calculated from the two groups
  concerned, your test will be more powerful.
• When the degrees of freedom of the error term are
  increased, a lower value of t will achieve
  signficance.

36
Type I errors

• Returning to the two-group experiment and the
  independent samples t test, if the sigificance
  level a is set at 0.05, any p-value less than
  0.05 will result in the rejection of the null
  hypothesis.
• If the null hypothesis is true, it will be
  wrongly rejected on 5 of occasions with repeated
  sampling. A false rejection of the null
  hypothesis is known as a Type I error, and the
  significance level is therefore also known as the
  Type I or alpha error rate.

37
The per comparison and familywise Type I error
rates

• Returning to ANOVA and our array of k treatments
  means, suppose that we plan to make a set of c
  comparisons among a set of means.
• If the alpha or significance level is set at
  0.05, the Type I error rate PER COMPARISON is
  0.05.
• But what is the probability that AT LEAST ONE
  COMPARISON will show significance, even when the
  null hypothesis is true?
• This probability is known as the FAMILYWISE Type
  I error rate.

38
Capitalising upon chance

• With a large array of treatment means, we might
  decide to make a large number of comparisons.
• Even if the null hypothesis is true, the
  familywise Type I error rate might be 0.90 or
  even higher!
• Failure to take the heightened probability of a
  Type I error into account when making sets of
  comparisons is known as CAPITALISING UPON CHANCE.


39
The Bonferroni formula

• If alpha is the significance level for each
  comparison, it can be shown that the familywise
  Type I error rate is approximately c times alpha,
  where alpha is the usual significance level.
• Lets call this the BONFERRONI FORMULA, from a
  related theorem in probability theory.

40
Conservative tests

• A CONSERVATIVE TEST adjusts the p-value per
  comparison upwards in order to to control the
  familywise Type I error rate.
• This is equivalent to setting the per comparison
  significance level at a lower value than the
  traditional significance level.
• There are many different approaches to the making
  of conservative tests to avoid capitalising upon
  chance.

41
The Bonferroni correction

• The Bonferroni formula suggests how a
  conservative test might be made.
• Simply multiply the p-value of each comparison by
  c and reject the null hypothesis only if the
  adjusted p-value is smaller than the intended
  FAMILYWISE significance level, which is usually
  set at 0.05.
• Alternatively, set the per comparison
  significance level at 0.05/c, where c is the
  number of comparisons you intend to make.

42
The Bonferroni correction
43
Application to contrast sets

• The Bonferroni correction was first applied to
  sets of planned comparisons such as Helmert
  contrasts or simple contrasts.
• If you plan to make c contrasts, just divide the
  traditional significance level (0.05) by c.
• So if you plan to make 4 contrasts, you would
  require a p-value of less than 0.05/4 0.01,
  approximately, before declaring a comparison
  significant.

44
Unplanned or post hoc comparisons

• Often, the researcher isnt in a position to plan
  a specific set of comparisons before the data
  have been gathered.
• More usually, once the data have been gathered,
  the initial ANOVA is followed by an a posteriori
  process of data-snooping, which involves the
  making of unplanned or POST HOC comparisons.
• Many post hoc tests have been proposed.

45
(No Transcript)
46
Which one?

• The Bonferroni is the most conservative of these
  tests. With a large array of means its almost
  impossible to get anything significant.
• In between subjects experiments, the Tukey test
  is preferred.
• The Dunnet is the most powerful test, but
  suitable only for the situation where you are
  comparing the mean of the controls with each of
  the other treatment means, that is, when you are
  making simple comparisons.

47
Factorial experiments

• In a FACTORIAL experiment, there are two or more
  treatment factors.
• The ANOVA really comes into its own when it is
  applied to the analysis of data from factorial
  experiments.

48
Types of ANOVA design

• The three most common types of ANOVA design are
• BETWEEN SUBJECTS FACTORIAL designs, in which ALL
  factors are between subjects.
• WITHIN SUBJECTS FACTORIAL designs, in which ALL
  factors are within subjects.
• MIXED FACTORIAL designs, in which SOME factors
  are between subjects and some are within
  subjects.

49
An experiment with two treatment factors

• Suppose that a researcher has been commissioned
  to investigate the effects upon simulated driving
  performance of two new anti-hay fever drugs, A
  and B. It is suspected that at least one of the
  drugs may have different effects upon fresh and
  tired drivers, and the firm developing the drugs
  needs to ensure that neither drug has an adverse
  effect upon driving performance.
• The researcher decides to carry out a two-factor
  factorial experiment, in which the factors are
• Drug Treatment, with levels Placebo, Drug A and
  Drug B
• Alertness, with levels Fresh and Tired.

50
(No Transcript)
51
(No Transcript)
52
Main effects and interactions

• A factor is said to have a MAIN EFFECT if, in the
  population, there are differences among the means
  at its different levels, ignoring any other
  factors there may be in the design.
• In factorial experiments, interest usually
  centres not on main effects, but on the interplay
  among the treament factors, that is, upon
  INTERACTIONS.

53
Observations

• Main effects are evident in the MARGINAL TOTALS.

• Not surprisingly the Fresh participants
  outperformed the Tired participants.
• Performance was higher in the Drug B group.
• But the cell means are the main focus of
  interest, because certain patterns indicate the
  presence of an INTERACTION.
• A PROFILE PLOT is of great assistance in
  interpreting cell means.

54
Profile plots

• Profile plots are the best way of determining
  whether any interactions are present and the
  precise nature of any interactions there may be.
• More than one plot is possible your choice
  depends upon which factor is of principal
  interest.

55
Two body state profiles
56
Three drug profiles
57
An interaction

• In neither plot are the profiles parallel.
• In the first profile, the factor of Body State
  seems to reverse its effect at different levels
  of the Drug factor.
• In the second profile, the ordering of the means
  at the three levels of the Drug factor changes
  from level to level of the Body State factor.
• When one factor does not have the same effect at
  all levels of another, the two factors are said
  to INTERACT.

58
In summary

• If the profiles are parallel, there may be main
  effects, but there is no interaction.
• Main effects are indicated by separation of the
  profiles and slope.
• NON-PARALLELISM of the profiles indicates the
  presence of an interaction.

59
Partition of the sum of squares in the two-factor
(two-way) ANOVA
60
Partition in the two-way ANOVA
61
Three F tests
62
Two-way ANOVA summary table
63
Effect size in factorial experiments

• A controversial area.
• The measure known as COMPLETE ETA SQUARED
  expresses the contribution of a source (whether a
  main effect or an interaction) to the total
  variance in the presence of all other treatment
  or group sources.
• The measure known as PARTIAL ETA SQUARED excludes
  all other treatment or group sources.

64
Complete eta squared for Alertness
65
Partial eta squared for Alertness
66
Estimate of partial omega squared
67
Simple effects

• The main effect of one factor at ONE LEVEL of
  another is known as a SIMPLE MAIN EFFECT.
• If an interaction is significant, it is common
  practice to unpack it by testing for the
  presence of simple main effects.

68
(No Transcript)
69
Simple main effects of Body State
70
Simple main effects of Drug
71
Testing for a simple effect
72
Simple effects with SPSS

• Simple effects are not an option in the ANOVA
  dialog windows.
• It is easy to run simple effects on SPSS, but we
  must use SYNTAX to achieve this.
• A small problem is that we must use, not the
  ANOVA syntax command, but the command for what is
  known as Multivariate Analysis of Variance or
  MANOVA.

73
Multivariate analysis of variance (MANOVA)

• In the ANOVA, there is just ONE dependent
  variable.
• Multivariate Analysis of Variance (MANOVA) is a
  generalisation of the ANOVA to the analysis of
  data from experiments of ANOVA design with two or
  more DVs.
• We can, therefore, regard the ANOVA as a special
  case of the MANOVA.

74
Using MANOVA to run ANOVA

• If there is only one DV, running the MANOVA
  procedure will run a univariate ANOVA and produce
  the usual ANOVA summary table.

75
The basic MANOVA command
76
Get into the syntax editor
77
Run the procedure
78
You get exactly the same ANOVA summary table as
before.
79
The /ERROR and /DESIGN subcommands for simple
effects of Drug
80
Output for simple effects analysis
81
The need for multiple comparisons
82
The need for a smaller comparison family

• An interaction is significant.
• We want to make unplanned or post hoc multiple
  comparisons among the treatment means.
• But there may be many cells in the design, so
  that the critical difference for significance may
  be impossibly large.
• In terms of the Bonferroni test, you could be
  multiplying the p-value by a large factor or
  setting the per comparison significance level at
  a tiny value.
• We need to justify making the comparisons among a
  smaller array of means.

83
First, we test for simple main effects

• We might argue that if we have a significant main
  effect of the Drug factor at one level of Body
  State or Alertness, we can define the comparison
  family in relation to those means at the Fresh
  level of Body State only. This will produce a
  less conservative test.
• When testing for simple main effects, however, we
  should use the Bonferroni correction to control
  the familywise Type I error rate.
• In our example, since there are two simple main
  effects, the criterion for significance should be
  that p is less than 0.025, rather than 0.05.

84
Reduce the data set.

• There is more than one way of making the multiple
  comparisons.
• You can easily run a one-way ANOVA on the data
  from the scores of the fresh participants only,
  then ask for a Tukey test.

85
Select the data from the Fresh participants only
86
Choose Tukey multiple comparisons
87
The results
88
Summary

• A report of an ANOVA F test should be accompanied
  by a measure of effect size, such as eta squared
  or (preferably) omega squared. Follow Lisa
  DeBruines guidelines.
• Beware of capitalising upon chance follow-up
  tests should be conservative.
• When unpacking significant interactions, use
  syntax to test for simple main effects.
• A significant simple main effect can be an
  argument for a smaller comparison family.

89
Recommended reading

• For a thorough and readable coverage of
  elementary (and not so elementary) statistics, I
  recommend
• Howell, D. C. (2007). Statistical methods for
  psychology (6th ed.). Belmont, CA
  Thomson/Wadsworth.

90
For SPSS

• May I immodestly suggest
• Kinnear, P. R., Gray, C. D. (2008). SPSS 16
  for windows made simple. Hove and New York
  Psychology Press.
• In addition to practical advice about using SPSS
  16, we also offer informal explanations of many
  of the techniques.
