Title: Computers and Networking Systems


1
Computers and Networking Systems
  • Class 3.1

2
Chapter 4
  • The Motherboard

3
You Will Learn
  • About the types of motherboards
  • About components on the motherboard
  • A basic procedure for building a computer
  • How to install a motherboard
  • How to troubleshoot a motherboard

4
Purpose of Motherboard
  • Houses the CPU
  • Allows all devices to communicate with the CPU
    and with each other

5
Types of Motherboards
6
ATX and AT Motherboards
7
Main Components on a Motherboard
  • CPU and chip set
  • System clock
  • ROM BIOS
  • CMOS configuration chip and its battery
  • RAM
  • RAM cache (optional)
  • System bus with expansion slots
  • Jumpers and DIP switches
  • Ports that are directly on the board
  • Power supply connections

8
An AT Motherboard
9
An ATX Motherboard
10
Components Determined by Motherboard Selection
  • Types and speeds of CPU
  • Chip set on the board (already installed)
  • Memory cache and size
  • Types/number of expansion slots ISA, PCI, AGP
  • Type of memory, including what kind and how much
    SRAM and DRAM (SIMMs, DIMMs, or RIMMs)
  • Maximum amount of memory you can install
    incremental amounts by which you can upgrade

continued
11
Components Determined by Motherboard Selection
  • Type of case you can use
  • ROM BIOS (already installed)
  • Type of keyboard connector
  • Presence/absence of proprietary video and/or
    proprietary local bus slots
  • Presence/absence of IDE adapters and SCSI
    controller
  • Presence/absence of COM ports, LPT ports, and
    mouse port

12
When Selecting a Motherboard
  • Designed so long expansion cards dont get in the
    way of CPU or other devices?
  • Support CPU you plan to use?
  • What type of BIOS does it use?
  • What bus speeds and type memory does it support
    how much memory can it hold?
  • Does it use many embedded devices?

continued
13
When Selecting a Motherboard
  • Does it fit the case?
  • Does it support your legacy cards?
  • What is the warranty?
  • Extensive user-friendly documentation?
  • How much support does manufacturer supply?

14
Motherboard Manufacturers
15
The System Clock
  • Keeps beat for motherboard activities
  • Frequency measured in megahertz (MHz)
  • Wait state
  • Occurs when CPU must wait for another component

16
CPU and Chip Set
  • IBM and IBM-compatible computers use a
    microprocessor chip made by Intel or AMD, and to
    a lesser degree by Cyrix

17
Attributes Used to Rate CPUs
  • Speed (in gigahertz)
  • Efficiency of programming code
  • Number of transistors
  • Number of registers
  • Word size
  • Data path
  • Maximum number of memory addresses
  • Amount of memory included
  • Multiprocessing abilities
  • Special functionality

18
The Pentium and Its Competitors
  • Pentium processor
  • A true multiprocessor (has two ALUs)
  • 64-bit external path size and two 32-bit internal
    paths (one for each ALU)

19
CPU Terminology
  • Bus speed
  • Frequency/speed at which data moves on a bus
  • Only the fastest bus connects directly to CPU
  • Processor speed
  • Speed at which CPU operates internally
  • The multiplier
  • System bus speed x multiplier processor speed
  • Memory cache
  • Small amount of RAM that is fast and does not
    need refreshing
  • Can hold data as long as power is available

20
Memory Cache on the CPU
  • Internal cache, primary cache, or Level 1 cache
  • Included on the CPU die
  • External cache, secondary cache, or Level 2 cache
  • Outside CPU microchip

21
Memory Cache on the CPU
22
(No Transcript)
23
The Pentium III
24
The Pentium 4
25
Advanced Pentium Competitors
26
The Cyrix III
27
The AMD Athlon
28
Intel ItaniumThe Next-Generation Processor
  • Intels first 64-bit processor for microcomputers
  • Designed for high-end enterprise servers
  • Uses a new instruction set called the EPIC
    (explicitly parallel instruction computing)
    architecture

29
Intel Itanium Processors
30
CPU Heat Sinks Cooling Fans
  • Heat sinks
  • Used by older CPUs to pull heat away from the CPU
  • Clip-on device that mounts on top of the CPU
  • Cooling fans
  • Keep temperatures below the Intel maximum limit
    of 185 degrees F/85 degrees C
  • Exotic options refrigeration, peltiers, water
    coolers

31
Heat Sinks and Cooling Fans
32
CPU Cooling Fan
33
CPU Package Types
  • SECC (Single Edge Contact Cartridge)
  • SECC2 (Single Edge Contact Cartridge, version 2)
  • SEP (Single Edge Processor)
  • PPGA (Plastic Pin Grid Array)
  • PGA (Pin Grid Array)
  • OOI/OLGA (Organic Land Grid Array)
  • FC-PGA (Flip Chip Pin Grid Array)
  • FC-PGA2 (Flip Chip Pin Grid Array 2)
  • PAC (Pin Array Cartridge)

34
Plastic Pin Grid Array
35
CPU Slots and Sockets
  • Physical connections used to connect CPU to
    motherboard
  • Motherboard and processor must match
  • Slots 1 and 2 are proprietary Intel slots
  • Slot A and Socket A are proprietary AMD connectors

36
Sockets and Slots Used by CPUs
continued
37
Sockets and Slots Used by CPUs
38
CPU Slots and Sockets
  • Earlier CPU sockets
  • Pin grid array (PGA) sockets
  • Staggered pin grid array (SPGA)
  • Low insertion force (LIF) sockets
  • Current CPU sockets
  • Zero insertion force (ZIF) sockets small lever
    on side of socket lifts CPU up and out of socket

39
CPU Slots and Sockets
40
The Chip Set
  • Set of chips on system board that collectively
    controls memory cache, external buses, and some
    peripherals
  • Intel dominates the market
  • Most compatible with Pentium family of CPUs
  • Investment in RD has led to other developments
    (eg, PCI bus, universal serial bus, AGP, and
    Accelerated Hub Architecture)

41
Accelerated Hub Architecture
42
Chip Set Manufacturers
43
ROM BIOS
  • One ROM chip on motherboard contains BIOS
  • BIOS manages startup process (startup BIOS) and
    basic I/O functions (system BIOS)
  • Most devices are not supported by system BIOS,
    but by device drivers
  • Flash ROM (erasable programmable read-only memory
    or EEPROM) allows ROM BIOS to be upgraded without
    changing ROM chip

44
BIOS Manufacturers
45
Sample Web Site for Flash ROM BIOS Upgrades
46
Buses and Expansion Slots
  • PCs have four or five buses, each with different
    speeds, access methods, and protocols
  • Buses evolved around data path and speed
  • So many buses because single speed is not
    practical
  • Buses carry electrical power, control signals,
    memory addresses, and data
  • On-board ports (eg, keyboard port and mouse port)
  • Expansion slots can be located on motherboard
    sometimes stacked vertically on a second board

47
Buses Listed by Throughput
48
Relationship of CPU Speedto Bus Speed
  • Overall performance is better when multiplier is
    small
  • Change speed of a computer by
  • Changing speed of system bus, or
  • Changing multiplier that determines speed of CPU

49
How CPU and Bus SpeedsAre Controlled
50
Hardware Configuration
  • Tells CPU what hardware components are present
    and how they can interface with the CPU
  • How much memory is available
  • Which power management features are present
  • Whether disk drives, hard drives, modems, serial
    ports are connected
  • Provided on motherboard in three ways
  • DIP switches
  • Jumpers
  • CMOS

51
Setup Data Storedby DIP Switches
52
Setup Data Stored by Jumpers
53
Setup Data Stored by Jumpers
54
Setup Data on a CMOS Chip
  • Also called real-time clock/nonvolatile RAM
    (RTC/NVRAM) chip
  • Retains data even when computer is turned off
  • Requires very little electricity to hold data
  • Setup cannot be changed unintentionally, but disk
    drive must be working before you can change the
    setup

55
Changing CMOS Using Setup
56
Changing CMOS Using Setup
57
Changing CMOS Using Setup
58
Changing CMOS Using Setup
59
Changing CMOS Using Setup
60
Battery Power to CMOS Chip
61
Battery Power to CMOS Chip
  • Types of CMOS batteries
  • 3.6V lithium battery with a four-pin connector
    connects with a Velcro strip
  • 4.5V alkaline battery with a four-pin connector
    connects with a Velcro strip
  • 3.6V barrel-style battery with a two-pin
    connector soldered on
  • 3V lithium coin-cell battery (most common)

62
Coin-Cell CMOS Battery
63
Building a Computer
  • Verify that you have all parts you plan to
    install
  • Prepare computer case
  • Install drives
  • Determine proper configuration settings for
    motherboard
  • Set jumpers or switches on motherboard
  • Install CPU and CPU cooler
  • Install RAM
  • Install motherboard and attach cabling

continued
64
Building a Computer
  • Install video card
  • Plug computer into power source attach monitor
    and keyboard
  • Boot system and enter CMOS setup
  • Make sure settings are set to the default
  • If booting from a floppy disk, insert a bootable
    setup disk
  • Observe POST
  • Prepare hard drive for the OS

continued
65
Building a Computer
  • Reboot the system and run ScanDisk on drive C
  • Connect mouse
  • Install the OS from CD or floppy
  • Change boot order in CMOS
  • Check for conflicts with system resources
  • Install any other expansion cards, and/or drives
  • Verify that all is operating properly make final
    OS and/or CMOS adjustments

66
Installing a Motherboard
  • Prepare motherboard to go into the case
  • Set jumpers
  • Add CPU, fan, and heat sink
  • Install motherboard in the case

67
Adding CPU, Fan, and Heat Sink
68
Adding CPU, Fan, and Heat Sink
69
Adding CPU, Fan, and Heat Sink
70
Adding CPU, Fan, and Heat Sink
71
Adding CPU, Fan, and Heat Sink
72
Installing the Motherboardin the Case
  • Install faceplate
  • Install standoffs
  • Place motherboard inside case and use screws to
    attach it to the case
  • Connect power cord from power supply to P1 power
    connection on motherboard
  • Connect wire leads from front panel of case to
    motherboard (reset switch, HDD LED, speaker,
    power LED, remote switch)

73
Installing the Faceplate
74
Installing the Faceplate
75
Standoffs and Screwholes
76
Wire Connectors
77
Wire Connectors
78
Completing the Installation
  • Install drives and other components
  • Turn on system and make sure everything is
    connected properly
  • Set configuration data and create rescue desk of
    settings

79
Troubleshooting the Motherboard
  • Look for clues from POST
  • Reports errors as beep codes
  • Cautiously substitute good hardware components
    for those you suspect are bad

80
Information about Beep Codes
81
Chapter Summary
  • How the components of a computer work in harmony
    and with accuracy
  • The motherboard
  • Central site of computer logic circuitry
  • Location of most important microchip in the
    computer, the CPU
Write a Comment
User Comments (0)
About PowerShow.com
