game playing

1
game playing
Notes adapted from lecture notes for CMSC 421 by
B.J. Dorr
2
Outline

• What are games?
• Optimal decisions in games
• Which strategy leads to success?
• ?-? pruning
• Games of imperfect information
• Games that include an element of chance

3
What are and why study games?

• Games are a form of multi-agent environment
• What do other agents do and how do they affect
  our success?
• Cooperative vs. competitive multi-agent
  environments.
• Competitive multi-agent environments give rise to
  adversarial problems a.k.a. games
• Why study games?
• Fun historically entertaining
• Interesting subject of study because they are
  hard
• Easy to represent and agents restricted to small
  number of actions

4
Relation of Games to Search

• Search no adversary
• Solution is (heuristic) method for finding goal
• Heuristics and CSP techniques can find optimal
  solution
• Evaluation function estimate of cost from start
  to goal through given node
• Examples path planning, scheduling activities
• Games adversary
• Solution is strategy (strategy specifies move for
  every possible opponent reply).
• Time limits force an approximate solution
• Evaluation function evaluate goodness of game
  position
• Examples chess, checkers, Othello, backgammon

5
Types of Games
6
Game setup

• Two players MAX and MIN
• MAX moves first and they take turns until the
  game is over. Winner gets award, looser gets
  penalty.
• Games as search
• Initial state e.g. board configuration of chess
• Successor function list of (move,state) pairs
  specifying legal moves.
• Terminal test Is the game finished?
• Utility function Gives numerical value of
  terminal states. E.g. win (1), lose (-1) and
  draw (0) in tic-tac-toe (next)
• MAX uses search tree to determine next move.

7
Partial Game Tree for Tic-Tac-Toe
8
Optimal strategies

• Find the contingent strategy for MAX assuming an
  infallible MIN opponent.
• Assumption Both players play optimally !!
• Given a game tree, the optimal strategy can be
  determined by using the minimax value of each
  node
• MINIMAX-VALUE(n)
• UTILITY(n) If n is a terminal
• maxs ? successors(n) MINIMAX-VALUE(s) If n is
  a max node
• mins ? successors(n) MINIMAX-VALUE(s) If n is
  a min node

9
Two-Ply Game Tree
10
Two-Ply Game Tree

• MAX nodes
• MIN nodes
• Terminal nodes utility values for MAX
• Other nodes minimax values
• MAXs best move at root a1 - leads to the
  successor with the highest minimax value
• MINs best to reply b1 leads to the successor
  with the lowest minimax value

11
What if MIN does not play optimally?

• Definition of optimal play for MAX assumes MIN
  plays optimally maximizes worst-case outcome for
  MAX.
• But if MIN does not play optimally, MAX will do
  even better. Can be proved.

12
Minimax Algorithm
function MINIMAX-DECISION(state) returns an
action inputs state, current state in game
v?MAX-VALUE(state) return the action in
SUCCESSORS(state) with value v
function MAX-VALUE(state) returns a utility
value if TERMINAL-TEST(state) then return
UTILITY(state) v ? 8 for a,s in
SUCCESSORS(state) do v ? MAX(v,MIN-VALUE(s))
return v
function MIN-VALUE(state) returns a utility
value if TERMINAL-TEST(state) then return
UTILITY(state) v ? 8 for a,s in
SUCCESSORS(state) do v ? MIN(v,MAX-VALUE(s))
return v
13
Properties of Minimax
?
?
?
?
14
Tic-Tac-Toe

• Depth bound 2
• Breadth first search until all nodes at level 2
  are generated
• Apply evaluation function to positions at these
  nodes

15
Tic-Tac-Toe

• Evaluation function e(p) of a position p
• If p is not a winning position for either player
• e(p) (number of a complete rows, columns, or
  diagonals that are still open for MAX) (number
  of a complete rows, columns, or diagonals that
  are still open for MIN)
• If p is a win for MAX
• e(p) ?
• If p is a win for MIN
• e(p) - ?

16
Tic-Tac-Toe - First stage
x
o
6-42
5-41
x
o
4-6-2
x
o
x
x
MAXs move
o
6-60
x
4-5-1
o
x
o
5-6-1
5-50
x
x
o
o
6-51
5-50
o
x
x
5-50
o
x
x
5-6-1
x
o
6-51
x
o
17
Tic-Tac-Toe - Second stage
o
MAXs move
3-21
x
o
x
o
x
x
x
o
o
o
x
o
4-22
4-31
x
o
x
o
x
x
x
o
o
o
x
o
3-21
o
x
o
x
4-31
4-22
x
x
x
5-23
o
x
o
o
o
x
o
x
3-30
o
x
4-22
x
x
o
x
x
3-21
x
o
o
x
o
o
5-32
x
o
o
x
3-21
x
x
x
o
4-22
o
x
o
x
o
3-30
5-23
3-30
o
x
x
x
o
x
x
o
o
x
o
4-31
o
x
o
x
4-22
4-31
x
x
o
o
x
o
o
x
4-22
4-31
o
x
x
o
x
o
18
Multiplayer games

• Games allow more than two players
• Single minimax values become vectors

19
Problem of minimax search

• Number of games states is exponential to the
  number of moves.
• Solution Do not examine every node
• Alpha-beta pruning
• Alpha value of best choice found so far at any
  choice point along the MAX path
• Beta value of best choice found so far at any
  choice point along the MIN path
• Revisit example

20
Tic-Tac-Toe - First stage
Beta value -1
B
x
Alpha value -1
4-5-1
o
x
5-50
x
o
o
6-51
x
5-50
o
x
x
5-6-1
A
x
o
C
6-51
x
o
21
Alpha-beta pruning

• Search progresses in a depth first manner
• Whenever a tip node is generated, its static
  evaluation is computed
• Whenever a position can be given a backed up
  value, this value is computed
• Node A and all its successors have been generated

• Backed up value -1
• Node B and its successors have not yet been
  generated
• Now we know that the backed up value of the start
  node is bounded from below by -1

22
Alpha-beta pruning

• Depending on the back up values of the other
  successors of the start node, the final backed up
  value of the start node may be greater than -1,
  but it cannot be less
• This lower bound alpha value for the start
  nodea

23
Alpha-beta pruning

• Depth first search proceeds node B and its
  first successor node C are generated
• Node C is given a static value of -1
• Backed up value of node B is bounded from above
  by -1
• This Upper bound on node B beta value.
• Therefore discontinue search below node B.
• Node B. will not turn out to be preferable to
  node A

24
Alpha-beta pruning

• Reduction in search effort achieved by keeping
  track of bounds on backed up values
• As successors of a node are given backed up
  values, the bounds on backed up values can be
  revised
• Alpha values of MAX nodes that can never decrease

• Beta values of MIN nodes can never increase

25
Alpha-beta pruning

• Therefore search can be discontinued
• Below any MIN node having a beta value less than
  or equal to the alpha value of any of its MAX
  node ancestors
• The final backed up value of this MIN node can
  then be set to its beta value
• Below any MAX node having an alpha value greater
  than or equal to the beta value of any of its
  MINa node ancestors
• The final backed up value of this MAX node can
  then be set to its alpha value

26
Alpha-beta pruning

• during search, alpha and beta values are computed
  as follows
• The alpha value of a MAX node is set equal to the
  current largest final backed up value of its
  successors
• The beta value of a MINof the node is set equal
  to the current smallest final backed up value of
  its successors

27
Alpha-Beta Example
Do DF-search until first leaf
Range of possible values
-8,8
-8, 8
28
Alpha-Beta Example (continued)
-8,8
-8,3
29
Alpha-Beta Example (continued)
-8,8
-8,3
30
Alpha-Beta Example (continued)
3,8
3,3
31
Alpha-Beta Example (continued)
3,8
This node is worse for MAX
-8,2
3,3
32
Alpha-Beta Example (continued)
,
3,14
-8,2
3,3
-8,14
33
Alpha-Beta Example (continued)
,
3,5
-8,2
3,3
-8,5
34
Alpha-Beta Example (continued)
3,3
2,2
-8,2
3,3
35
Alpha-Beta Example (continued)
3,3
2,2
-8,2
3,3
36
Alpha-Beta Algorithm
function ALPHA-BETA-SEARCH(state) returns an
action inputs state, current state in game
v?MAX-VALUE(state, - 8 , 8) return the action
in SUCCESSORS(state) with value v
function MAX-VALUE(state,? , ?) returns a utility
value if TERMINAL-TEST(state) then return
UTILITY(state) v ? - 8 for a,s in
SUCCESSORS(state) do v ? MAX(v,MIN-VALUE(s,
? , ?)) if v ? then return v ? ?
MAX(? ,v) return v
37
Alpha-Beta Algorithm
function MIN-VALUE(state, ? , ?) returns a
utility value if TERMINAL-TEST(state) then
return UTILITY(state) v ? 8 for a,s in
SUCCESSORS(state) do v ? MIN(v,MAX-VALUE(s,
? , ?)) if v ? then return v ? ?
MIN(? ,v) return v
38
General alpha-beta pruning

• Consider a node n somewhere in the tree
• If player has a better choice at
• Parent node of n
• Or any choice point further up
• n will never be reached in actual play.
• Hence when enough is known about n, it can be
  pruned.

39
Final Comments about Alpha-Beta Pruning

• Pruning does not affect final results
• Entire subtrees can be pruned.
• Good move ordering improves effectiveness of
  pruning
• Alpha-beta pruning can look twice as far as
  minimax in the same amount of time
• Repeated states are again possible.
• Store them in memory transposition table

40
Games that include chance

• Possible moves (5-10,5-11), (5-11,19-24),(5-10,10-
  16) and (5-11,11-16)

41
Games that include chance
chance nodes

• Possible moves (5-10,5-11), (5-11,19-24),(5-10,10-
  16) and (5-11,11-16)
• 1,1, 6,6 chance 1/36, all other chance 1/18

42
Games that include chance

• 1,1, 6,6 chance 1/36, all other chance 1/18
• Can not calculate definite minimax value, only
  expected value

43
Expected minimax value

• EXPECTED-MINIMAX-VALUE(n)
• UTILITY(n) If n is a terminal
• maxs ? successors(n) MINIMAX-VALUE(s) If n
  is a max node
• mins ? successors(n) MINIMAX-VALUE(s) If n
  is a max node
• ?s ? successors(n) P(s) . EXPECTEDMINIMAX(s)
  If n is a chance node
• These equations can be backed-up recursively all
  the way to the root of the game tree.

44
Position evaluation with chance nodes

• Left, A1 wins
• Right A2 wins
• Outcome of evaluation function may not change
  when values are scaled differently.
• Behavior is preserved only by a positive linear
  transformation of EVAL.

45
Discussion

• Examine section on state-of-the-art games
  yourself
• Minimax assumes right tree is better than left,
  yet
• Return probability distribution over possible
  values
• Yet expensive calculation

46
Discussion

• Utility of node expansion
• Only expand those nodes which lead to
  significanlty better moves
• Both suggestions require meta-reasoning

47
Summary

• Games are fun (and dangerous)
• They illustrate several important points about AI
• Perfection is unattainable - approximation
• Good idea what to think about
• Uncertainty constrains the assignment of values
  to states
• Games are to AI as grand prix racing is to
  automobile design.
