Title: Core System Design


1
APO 02 - SNP 00Supply Network Planning
overview
2
Course Objectives
  • Course objectives
  • Be aware of how APO covers the Supply Planning
    requirements within Danone
  • Understand the SNP concept
  • Understand the data models and navigation tools
  • Be able to navigate on your own

3
Agenda
Course introduction SNP concepts Forecast
release Network planning (DRP) Medium Long term
production planning (MPS) Deployment Purchase
finished products Intercompany Subcontracting Tool
s Alert monitor cockpit
4
How APO covers supply chain process
Supply Network Planning (SNP)
Material requirement planning (MRP-R/3)
Demand planning (DP)
1.1 LONG TERM DEMAND
2.1 INDUSTRIAL and LOGISTICS VISION and STRAGTEGY
2.2 MATERIAL CONTRACTS
Strategic 3 years horizon
1.2 MIDDLE-TERM DEMAND
2.3 DISTRIBUTION REQUIREMENT
2.4 MID-TERM MASTER PLANNING
2.5 MATERIAL REQUIREMENT PLANNING
Tactical 1 Year horizon
3.2 SCHEDULING
3.3 MATERIAL RELEASE AND USAGE
3.1 DISTRIBUTION REQUIREMENT PLANNING
1.3 SHORT-TERM DEMAND
Operational 3 weeks
3.4 DEPLOYMENT
Very short-term 3 days
Production planning Detailed scheduling (PPDS)
5
SNP CONCEPTS
Course introduction SNP concepts Forecast
release Network planning (DRP) Medium Long term
production planning (MPS) Deployment Purchase
finished products Intercompany Subcontracting Tool
s Alert monitor cockpit
6
Supply Network locationsconcept
external supplier
production site
site with product tranformationcomponents in BOM
sourced from external suppliers
copacking site
site with product transformationcomponents in
BOM could be sourced in other internal sitef.e.
biscuits promo copacking sites
expedition centre
no product transformationno deliveries to the
final customerf.e. water seasonal storage
 greniers
distribution centre
no product transformationdeliveries to the final
customer
external customer
7
Master Data Location
8
Master Data Product at location
9
user environmentSNP planning books
Header (used for drill down)
Selection(available data)
selection profile (predefined data groups)
planning book(defines lines in planning
book) - data view (defines columns in
planning book)
10
Unit of measure
  • All DP environments are based on one UOM
  • dairy TON
  • biscuits TON
  • water KBT
  • this is the one and only available UOM on the
    aggregated levels
  • on the lowest (product) level the default UOM
    could be set per user per planning book (specific
    development to be switched on) to any UOM defined
    in the material master (carton, pallet,)
  • on the lowest (product) level UOM could be
    manually changed to any UOM defined in the
    material master (carton, pallet,)

11
user environment SNP planning book concept
12
user environmentSNP planning books
  • Planning area
  • one planning area common for WBU (all data is
    stored in same database !)
  • defines the UOM used in the planning books (see
    later)
  • key figure what ?
  • Characteristics what ?
  • Planning book
  • what ?
  • Data view
  • what ?
  • Time bucket profile what ?
  • Planning books used by SNP planners
  • core_prod_ST/MT/LT for analysis of production
    planning on product level
  • core_capacity for analysis of production line
    capacity
  • core_purch_ST/MT/LT for planning of purchased
    finished products
  • core_depl_xxxx for deployment purpose

13
FORECAST RELEASE in SNP
Course introduction SNP concepts Forecast
release Network planning (DRP) Medium Long term
production planning (MPS) Deployment Purchase
finished products Intercompany Subcontracting Tool
s Alert monitor cockpit
14
Supply Network Planning release of the demand
plan in SNP
The Supply Planning Flow The starting point of
Supply Planning is the expression of Demand In
our case, almost all demand is based on
Forecast Forecast quantities are transferred as
independent demand and are expressed at item
level in a specific location
SUPPLY NETWORK PLANNING
DEMAND PLANNING
Elaborate Demand Plan
Forecast Sales
Run Distribution Plan (long/medium term)
demand
PlanPromotionsProductintroduction /Life end
Run Production Plan (long/medium term)
15
interface demand planning - supply network
planning
  • Forecast data will be transferred on the level
  • article (SKU)
  • per warehouse (Distribution Center - DC)
  • total for all clients distributed from concerned
    DC
  • biscuits and water day (up to end
    w3) week (up to end m4) month (up to end
    m18)
  • only for future (period split 1)

umbrella brand product brand
clientcountry
totalcountryDC
nationalforecastaccount
product variant (PV)
regionalforecast account
forecast unit (FU)
DC
article (SKU)
articlehierarchy
clienthierarchy
logistichierarchy
16
Demand release in the network
production site
copacking site
expedition centre
distribution centre
independent demand (forecast) on DC
17
Forecast consumption (1)
SUPPLY NETWORK PLANNING
DEMAND PLANNING
Elaborate Demand Plan
Forecast Sales
demand
PlanPromotionsProductintroduction /Life end
APO
shipments
orders

R/3
..
..
18
forecast consumption (2)consumption by orders
  • No Forecast consumption all planning will be
    based on forecast, no order impact
  • mostly used for all WBU, because planning cycle
    is much longer than order cycle (ex. dairy
    orders still arrive on delivery date)
  • Forecast consumption orders  consume
    forecast for a predefined period when they exceed
    the forecast
  • this strategy could occasionally been used for
    CBU s with a long order lead time.
  • Forecast  replacement  forecast will be
    replaced by order book,during predefined
    horizon. This option will only be used for
    specific articles.
  • for biscuits e.g. export articles produced on
    orders horizon 3 weeks
  • for dairy e.g. specific private label
    products horizon 1 week
  • for water e.g. export clients not in VMI
    horizon 8-12 weeks
  • Forecast  corrections  (in DP) forecast will
    be corrected based on order book.E.g. at the
    end of w-1, order book contains half of the
    estimated forecast for week w0
  • this will be managed in DP
  • mainly for articles with low revision frequency

19
forecast consumption (3)forecast update by
input/output transactions
  • Goods issue and Production Transactions are real
    time interfaced with R/3
  •  goods issues  forecast consumption
  • gt stock is reduced when goods issues is executed
  • gt forecast is reduced at same moment by the
    shiped quantity
  • remark also  production orders  influence
    stock on line
  • gt stock is increased when goods are confirmed in
    production
  • gt plan order remaining quantity to be produced
    is reduced by production confirmation
  • forecast will only be reduced at the
    current day

20
Product master data - forecast consumptiondemand
view
21
NETWORK PLANNINGDRP
Course introduction SNP concepts Forecast
release Network planning (DRP) Medium Long term
production planning (MPS) Deployment Purchase
finished products Intercompany Subcontracting Tool
s Alert monitor cockpit
22
Master Data Transportation Lanes
factory 0007
DC 0012
DC 0010
TLB profile
23
supply plan on a distribution center
production site
copacking site
Receipts requested( distribution receipts SNP)
expedition centre
stock
Demand - forecast- distribution demand-
dependent demand
Requested receipts
distribution centre
independent demand (forecast) on DC
24
Network planningconcept
production site
copacking site
expedition centre
Requested receipts
distribution centre
stock
independent demand (forecast) on DC
25
SNP networkexample
factory 0007
DC 0012
DC 0010
planning book article 795 on factory 0007
planning book article 795 on DC 0010
Product 795
safety stock in DC 10days
26
Supply Planningmanaging projected stocks
Goods Receipt
Stockon-hand
time
Goods Demand
27
Supply Planning processSNP heuristic (network
calculation)
  • Processes
  • lot for lot supply follows demand (used for all
    WBU)
  • fixed lot size
  • fixed period
  • reorder point / supply coverage

Constraints used for Danone lead time min/max
lot size rounding value safety stock
Stock
Max. level
Reorderpoint
Safetystock
Time
R
R
R
28
Distribution requirement planplanning
constraints for Danone
  • no multisourcing one article/DC combination
    will be sourced from one location
  • sourcing network will be considered as static
    changes are possible but not planned or
     optimised
  • minimum rounding profile
  • in regular all inter site shipments will be
    organised with one pallet minimum
  • for low rotating articles (mainly dairy) a pallet
    layer is accepted as minimum (to be specified
    per article)
  • multiple rounding profile
  • in regular multiples of full pallets
  • low rotating articles for dairy also multiples
    of layers for specific articles
  • no inventory optimisation is considered in a
    first phase
  • no warehouse capacity management
  • push/pull strategies are only available on short
    term deployment

29
Product master data lot size view
30
Medium Long term production Planning (MPS)
Course introduction SNP concepts Forecast
release Network planning (DRP) Medium Long term
production planning (MPS) Deployment Purchase
finished products Intercompany Subcontracting Tool
s Alert monitor cockpit
31
supply plan on a plant
Planned orders
production site
stock
Demand - forecast- distribution demand-
dependent demand
copacking site
Receipts requested( distribution receipts SNP)
expedition centre
stock
Demand - forecast- distribution demand-
dependent demand
requested receipts
distribution centre
independent demand (forecast) on DC
32
Master planning (MPS)Resource load
  • All planned orders are totalised
  • in the production plant
  • per article
  • from all DC s
  • per period
  • production plan model (PPM)puts the demand on a
    resource
  • resource groups receives the load
  • total of all the planned orders

100(from DC1 for week 2 )
200(from DC2for week 2 )
production site
300 Planned order art. A for week 2
PPM
production line (resource)
load
300
art A
time
week 2
33
Resource definitionAPO concept
  • A resource in APO represents a production line
  • different resource types could be defined,
    depending on the module
  • SNP bucket resources manual master data entry
  • PPDS single and multi resources automatic
    upload, based on R/3 master data

Calendar W8 always open
34
ResourceUOM issue
  • for SNP bucket resources, UOM should be defined
  • time UOM (Hours) represents most relevant
    business approach, but there is no possibility to
    totalise two production lines with different
    output and independent capacity planning
    example Evian has two production lines,
    different output (bottles/hour), but they could
    be independently planned (line 1 3 shifts/day ,
    line 2 2 shifts/day)
  • mass UOM (Tons or Kbottles) is less transparant
    for planner, and the output should be equal for
    all products.example a biscuit production
    line, produces 2 types of biscuits biscuit A is
    produced at 1Ton/H, biscuit B is produced at
    2Ton/H. The output of the production line is
    defined in Tons it should be defined as a
    weighted average of both products.

EXAMPLE with UOM MASS line capacity 15 T (5T
average/shift - 3 shifts) prod A 1000 PC 1T
capacity prod B 1000 PC 2 T capacity plan
order A 1000 PC 1T resource load
EXAMPLE with UOM TIME line capacity 24H (3
shifts) prod A 1000 PC 1 H capacity conso
(average output) prod B 2000 PC 1
H capacity conso (average
output) plan order A 1000 PC 1 H resource
load
ZFACTORS transaction
35
Resourcecapacity definition
Enter number of shifts
  • enter the number of shifts you want to plan
  • the system will make the conversion to the
    capacity of the resource, based on the zfactors
    table
  • remark 1 in order to validate the entry, you
    should leave the transaction
  • remark 2 the unit SH could be interpreted by
    the local CBU

36
Production process model
APO PPM concept
PPM application for DANONE
37
Production process modelAPO view
38
Use of SNP resources and PPM models for Danone
  • PPM models could be defined for several purpose
  • standard resource resource related to physical
    production line
  • general resource resource related to group of
    production lines
  • business concept
  • situation with multiple production lines with
    similar products
  • planner prefers to plan them as one general
    production line
  • each of the underlying production lines could be
    planned individually
  • see next slide for APO concept
  • family resource resource related to families
  • business concept
  • planner wants to group SKUs in same family
  • planner plans families in specific time buckets
    (w)
  • see next slide for APO concept
  • labor resource resource for labor planning
  • business concept labor pool (f.e. pool of
    packaging labor) is planned per week

39
general resourceconcept
  • business concept
  • situation with multiple production lines with
    similar products
  • planner prefers to plan them as one general
    production line
  • each of the underlying production lines could be
    planned individually
  • example
  • 3 actimel filling machines, all of them could
    produce 100g format in different perfumes
  • Prince Fourré production lines line 7 (standard
    rolls) line 8 (standard rolls pocket)
  • 2 EVIAN PET lines in Evian factory, able to
    produce all 1,5 l SKUs
  • APO concept
  • define UOM (TON is recommended) for each line
  • enter capacity in planning book CORE_CAPACITY
  • level on general resource

production line 1
production line 2
general resource(line 1 line 2)
40
general resourceexample
  • In plant 0031 two production lines produce the
    same type of products and are considered as one
    resource for medium long term planning
  • 0006_WROAL1314
  • these resource is defined in tons, because output
    is different on each of the production lines
  • 0006_WROAL1314 - line 1 (WROAL13) 35,640 T/H
  • 0006_WROAL1314 - line 2 (WROAL 14) 36,564 T/H

Total capacity is calculated based on - number
of shifts- output rate in zfactors
41
family resourceconcept
  • business concept
  • planner wants to group SKUs in same family
  • planner wants to plan family in specific time
    buckets (weeks)
  • example
  • f.e. 3 dairy yohourt filling lines all 3
    lines can fill 100g packs, only one can fill 400g
    family pack
  • f.e. Petit ecolier lines 2 lines can produce
    milk fondant chocolate, one can produce other
    perfumes
  • f.e 2 PET lines in Riardo can produce the
    same products but at a different capacity rate
  • APO concept
  • define each family as a resource
  • define in PPM
  • consumption of concerned physical production line
  • consumption of concerned family resource
  • plan capacity on each of the resource
  • assure manually consistency total capacity of
    the families capacity of physical resource
  • level each of the family resource individually
    analyse afterwards total on physical resource

SKU2(line1, fam2)
SKU1(line1,fam 1)
SKU4(line2, fam2)
SKU3(line2, fam1)
Family 2choc
Family 1vanilla
42
family resourceexample
  • In plant 0007 one specific family on the
    production line WP1
  • Products on this production line should be
    grouped and planned together (f.e. 1x/2weeks)
  • For this purpose an extra resource has been
    defined 0007_WP1_POLOMACENE

43
Family resource PPMexample
  • The PPM for Article 867 has 2 activities
  • standard production activity on resource
    0007_WP_1
  • calendar activity, representing the family on
    0007_WP1_POLOMACENE

Capacity consumption is defined on 2 resources
WP1 production
lineWP1_POLOMACENE family
44
Master planning (MPS)Resource load
  • All planned orders are totalised
  • in the production plant
  • per article
  • from all DC s
  • per period
  • production plan model (PPM)puts the demand on a
    resource
  • resource groups receives the load
  • total of all the planned orders

100(from DC1 for week 2 )
200(from DC2for week 2 )
production site
300 Planned order art. A for week 2
PPM
production line (resource)
load
300
art A
time
week 2
45
MPS Planning Capacity evaluation
Resource x(production line)
Backward leveling
Over Capacity
Capacity load
Resource capacity
Resource load
Time
time bucket
46
Capacity planningdairy
Check if total capacity matches with resource
load. Modify eventually capacity on one of the
production lines in the general resource
47
Capacity planningbiscuits / water
Check if total capacity matches with resource
load. Launch eventually automatic capacity
leveler as a first planning optimisation, before
manual plan modifications
48
Product planningbiscuits
Planning book Core_Global_stock Selection all
articles on one line / all locations
analyse the proposal of SNP plan run and the
leveler. Enter new or modify existing plan orders
with continuous check of the constraints -
total load of the line. Check also total load in
the capacity planning book (see former slide) -
stock coverage of the product
49
Family planning
Products 854 and 855 belong to a family with low
volume, planning for these SKUs is grouped every
3 weeks. - define calendar open every 3 weeks for
the family resource 0007_WP_Prince_ovoce - level
on this family resource - orders for the
concerned products are automatically put on the
open weeks
50
Multilevel supply plan process
4 stepproduction planning on production plants
3 stepaggregation of demand to production sites
3
2
2 stepproduction planning on dependent
copacking sites
1
1 stepaggregation of demand to copacking and
production sites
51
Planning processsummary (biscuits/water)
  • Run network SNP heuristic
  • Run factory SNP heuristic (outside offset period)
  • evaluate product plan in core_prod_MT
  • evaluate capacity load in core_capacity gt make
    capacity modifications gt run leveler
  • make manual modifications (for next period,
    entering in offset) analysing
  • stock per product in core_global_stock
  • plan per product in core_global_stock
  • capacity load of the line in core_capacity
  • convert w1 to PPDS (Wednesday morning)

52
SNP lt-gt PPDS
  • SNP long/medium term planning , PPDS short
    term planning
  • SNP until end of M6 gt one order per
    week until end of M18 gt one order per month
  • PPDS 16 days rolling for dairy gt correct
    start/end time end of next week for biscuits

53
DEPLOYMENT
Course introduction SNP concepts Forecast
release Network planning (DRP) Medium Long term
production planning (MPS) Deployment Purchase
finished products Intercompany Subcontracting Tool
s Alert monitor cockpit
54
Deployment concept
production site
stock
Demand from plant A
Demand from DC1
copacking site
plant A
expedition centre
DC1
distribution centre
independent demand (forecast) on DC
55
Deployment master data
  • Push strategy (define push strategy X)
  • define push horizon on factory max horizon
    where (expected) stock will be included for
    deployment (if also included in deployment
    horizon)
  • Pull strategy horizon (define push strategy
    blank)
  • define push horizon on factory max horizon
    where (expected) stock will be included for
    deployment (if also included in deployment
    horizon)
  • define pull horizon on factory max horizon
    where demand will be fulfilled at due date (if
    in deployment horizon and supply is available)
  • Combined Push/Pull horizon (define push strategy
    P)
  • define push horizon on factory max horizon
    where (expected) stock will be included for
    deployment (if also included in deployment
    horizon)
  • define pull horizon on factory max horizon
    where demand will be fulfilled immediately (if
    in deployment horizon and once supply is
    available)
  • deployment horizon horizon used by job for
    daily deployment plan calculation

56
Deployment master dataproduct master - SNP2 view
57
Deployment process Available to deploy stock
and plan orders
Demand from DC on factoryresult of SNP run
plan distrib. receipts
D1
D0
Available to deploy at D1
PLANORDERS
STOCKD0
PRODUCTIONORDERS
Deployment based on daily buckets !
Deployment calculation for D1based on
available to deploy quantity
D1 is depending on local situation
58
shortage managementfair share rules (1)
Fair share A percentage repartition by
requirements base concept used by all BU Fair
share B percentage of target stock not
used Fair share C percentage repartition by
quota arrangement used for manual shortage
mgmt Fair share D repartition by priority not
used
59
Fair share rules (2)
Total demand 100available 60 gt all DCs
receive 60 of their demand
DC 2demand 60
DC 1demand 40
- National level (between CBUs) - Between CBUs
clients (not in APO)
Fair share on two levels
60
Fair share rules (3)
61
Deployment process
Requirement plan calculated in network planning
Planned demand
Deployment run check demand vs availability apply
fair share
Confirmed demand
TLB runtransport truck building
TLB Confirmed demand
R/3 Execution
62
Deployment run
independent demand (forecast) on DC
forecast
forecast
stock
factory
stock
confirmed distribution receipts (gt TLB)
distribution receipts (purchase requisition)
deployment run
Confirmed distribution demand (gt TLB)
Distribution demand
stock
stock
DC
Plan order
Production order
63
Deployment in APO
64
Deployment in APOTLB view
The result of the deployment run (overnightjob),
is the input of the TLB view. Here the deployment
planner will built the trucks. He could launch
the automatic TLB run (eventually with deployment
anticipation for truck completion)
Example- truck capacity 10 pallets-
transport lead time 0007-gt0010 1 day
an investigation is currently made on truck
optimisation in function of multiple constraints
as min and max stock coverage in DC, min lot
size per layer or per pallet,..
65
Deploymentmodifications
Eventually modifications could be made in the TLB
view (manually modifying or creating STO order
lines, manual truck creation). After saving, the
results could be analysed on the plants in two
available planning books.
Evaluation stock in DCcore_storage_ST
Evaluation stock in plantcore_depl_ST
66
Deployment processindicative deployment
Deployment calculation is based on result of SNP
plan. If you do not exactly ship what is required
by the DC (pure pull scenario), two scenarios
are possible - push enlarge the deployment
horizon and the deployment run will give an
indication of the volumes to be shipped in the
near and eventually long future - pull with
modifications if these modified volumes have to
be known in advance (because f.e. they are
important or this plan is the indication for a
just-in-time deployment), the result of the SNP
heuristic could be modified in an offset horizon
(that will not be recalculated by the heuristic)
The deployment run will deploy, following the
modified planned distribution receipts.
an investigation is currently made to analyse
how the distribution demand could be
automatically optimised in function of a list of
constraints in the network (f.e. warehouse
capacity, costs, min/max stock coverage,.)
67
Deployment processindicative deployment plan
Make modifications in distribution demand and
check stock in all locations. The offset should
be set that this period will not be recalculated,
but managed by alerts.
68
Deployment processQuarantaine management
definitions
  • Definition
  • hard quarantine goods could not leave the
    factory for the DC before hard quarantine is
    cleared (also for Slovakia deliveries)
  • soft quarantine goods could not leave for
    client delivery before soft quarantine is
    cleared.
  • Constraint for APO Hard quarantine is fixed in
    APO at xx h for all products (no exceptions)
  • Business principle will be designed that there is
    no possibility in APO planning to send
    productsunder hard quarantine to a DC
  • it will only be possible to break this rule in
    R/3 (manual non planned shipment)
  • soft quarantine is not managed in APO

Soft quarentaine
Available stock
Hard quarentaine
business
R/3
Available stock
Stock in quality inspection
Available stock
Stock in quality inspection (CF)
APO
different status from blocked stock (status
CI in APO)
69
Deployment process with quarantineavailable to
deploy stock
Demand from DC on factory
D1
D0

ATD total stock (in out Q)
stock in hard quarentine
Soft Q
In production
available
Soft Q
In production
available
stock in hard quarentine
Deployment based on daily buckets !
Deployment calculation for D1based on
available to deploy quantity
70
Deployment including quarentineexample (1)
71
Deployment including quarentineexample (2)
  • HARD QUARENTAINE Deployment run will be
    launched at D0 800
  • !! prerequisite quarantine is for all products
    fixed at 12h (no possibility to differentiate
    between products)gt consequence no product
    will leave factory before hard quarantine is
    cleared
  • !! prerequisite production after 800 will stay
    in the factory until D1 2000
  • gt consequence there could be 36 hours stock
    due to quarantine
  • analysis of actual stock in DC
    (incl. soft quarantine) confirmed planned
    dist.reciepts
  • analysis of forecast for D0 and D1
  • calculation of overnight transferrequirements
    (APO Plan DistReciepts)
  • analysis of total stock available for deployment
    (at 2000) in Benesov ( total
    physical stock at 800)

Deployment run at 800
If shortage appearsthen fair shareanalysis is
applied.
SNP demand run at 500
72
Summary Deployment for Danone application in
function of business case
  • calculate transport only based on available
    stock. Suitable for
  • pull/push dairy
  • with quarantine
  • with immediate execution (very short lead time
    between calculation and execution)
  • pull biscuits with (almost) immediate execution
    or possibility to stock in factory
  • with indicative deployment plan (auto/manual)
    and/or manual modifications in TLB
  • push biscuits with (almost) immediate execution
  • depending on factory stock capacity, if time
    delay is acceptable
  • remark there is no indicative deployment plan
    available based on the push deployment run
  • include prod/plan orders in extrapolated
    situation. Suitable for
  • pull/push dairy for WE (or other situation with
    longer lead time between calculation and
    execution)
  • remark quarantine is not included in prod/plan
    order)
  • pull biscuits for WE (or other situation with
    longer lead time between calculation and
    execution)
  • with indicative deployment plan (auto/manual)
    and/or manual modifications in TLB
  • push biscuits if indicative deployment plan is
    required on LT
  • remark SNP calculation could only be made once
    a day gt stock is staying max for one day in
    factory
  • only possible if full push scenario is applicable

recommended scenarios
73
PURCHASEFINISHED PRODUCTS
Course introduction SNP concepts Forecast
release Network planning (DRP) Medium Long term
production planning (MPS) Deployment Purchase
finished products Intercompany Subcontracting Tool
s Alert monitor cockpit
74
Purchasing FPmaster data
  • Supplier will exist as a location in APO,
    product/loc should manually created
  • transportation lane will automatically be
    created, based on the contract
  • lead time of the contract will be applied on the
    transportation lane
  • the SNP heuristic will create purchase
    requisitions
  • these purchase requisitions could be manually
    modified during an offset horizon (where the SNP
    heuristic will not recalculate)
  • the purchase requisitions have to be converted
    manually in R/3
  • APO and R/3 are integrated with purch.req. and
    purch.orders
  • an investigation will be made if the conversion
    could be done automatically for a predefined
    horizon

Supplier 210004329
R/3 contract will create transportation lane
DC 0012
DC 0010
75
Purchasing FPAPO
Make modifications in distribution demand and
check stock. The offset should be set that this
period will not be recalculated, but managed by
alerts.
EXPORT TO EXCEL FILE and send to supplier
The Purchase requisitions have to be converted
into purchase orders in R3 with the transactions
ME58 and ME59
76
INTERCOMPANY
Course introduction SNP concepts Forecast
release Network planning (DRP) Medium Long term
production planning (MPS) Deployment Purchase
finished products Intercompany Subcontracting Tool
s Alert monitor cockpit
77
APO will become the leverage to optimise an
integrated European supply chain
APO biscuits, water or dairyenvironment
Manufacturer DC
Manufacturer Plant
Supplier Plant
Customer DC
All products, factories, warehouses,. will be in
one system ! APO ignores boundaries and companies
!
78
Intercompany process version 1 traditional
process managed by client
1. Forecast calculation 2. Requirement
calculation. including transportation
constraints
requirements
3. Production planning 4. Production execution.
5. Shortage management
7. Execution
6. Transportation
requirements
79
Intercompany process version 2 optimised
supply chain management VMI based
1. Forecast calculation 2. Requirement
calculation. including transportation
constraints
requirements
3. Production planning 4. Production execution 5.
Shortage management.
Shortage information
5. Transportation 6. Execution
Delivery confirmation
80
Intercompany process constraints
  • Intercompany process should always be based on a
    pull processor combination push/pull
  • a distribution plan optimisation, based on
    min/max stock levels of the client DC is
    recommendable. This optimisation could actually
    only be executed manually.
  • 4 scenarios
  • only client in APO
  • scenario purchasing finished products process
  • only supplier in APO
  • client sends forecast to supplier, uploaded in
    suppliers DP
  • orders, entered in R/3, replace forecast on fixed
    horizon
  • supplier and client in APO, deployment organised
    by client
  • scenario pull with indicative deployment plan
  • supplier and client in APO, deployment organised
    by supplier
  • scenario standard scenario for internal planning

81
SUBCONTRACTING
Course introduction SNP concepts Forecast
release Network planning (DRP) Medium Long term
production planning (MPS) Deployment Purchase
finished products Intercompany Subcontracting Tool
s Alert monitor cockpit
82
Subcontractingscenario 1
  • Subcontracting is considered as an activity in
    the plant that will be supplied by the
    subcontractor in this plant both a purchase
    order (for a subcontracting service) and a
    production order will be defined.
  • This process can only be managed in PPDS for
    this reason the production horizon for
    subcontracted products will be defined at 999
    days. (see PPDS training)

Purchase order

10 .....................
20 .....................
30 .....................
Production order
83
Subcontractingscenario 2
  • In some situations it might be recommendable to
    define a representing virtual plant for the
    subcontractor
  • if deployment has to be organised
  • if stock in subcontracted plant has to be managed
    in APO
  • if subcontractor receives or ships goods from/to
    different plants of the CBU
  • if the subcontractor does direct client
    deliveries
  • in this situation the PPDS plan run calculation
    will be followed by a SNP heuristic run, in order
    to calculate the requirements of the components
    of the subcontractor on the DC.

1
3
Components transfer posting
2
Virtual plant
Finished product tranfer posting
5
Finished product tranfer
4
SNP
PP/DS
84
TOOLS
Course introduction SNP concepts Forecast
release Network planning (DRP) Medium Long term
production planning (MPS) Deployment Purchase
finished products Intercompany Subcontracting Tool
s Alert monitor cockpit
85
Alertsconcept
  • Alerts are available
  • in planning books
  • in alert monitor
  • several alert types are defined. They are
    calculated in background and could be presented
    in alert monitor.
  • The alerts in the planning book are interactively
    calculated. The alerts in the alert monitor are
    calculated in background and could be presented
    in alert monitor or the supply chain cockpit.
  • every user could define an alert profile for his
    personal use

86
Alert monitorset user settings
87
Alerts in planning book
88
Alerts inAlert Monitor
89
Details on SNP Alertson products and resources
  • Alert on safety stock shortfall
  • alert will appear when stock gets below safety
    stock
  • Alert on shortage (backlog)
  • alert will appear when shortage occurs
  • resource overload
  • alert will appear when resource overload is over
    5
  • insufficient resource utilisation
  • alert will appear when resource is utilisation is
    lower than 70

90
Supply chain cockpit
91
Models and Planning versions
Master Data for
R/3
PP/DS
Master data in APO
Simulation
Simulation
model N
model 1
Active model 000
Resources
Resources
Locations
Resources
PPM
PPM
PPM
Products
Active
planning version
000
Planning version N
Planning version 1
Active
planning version
000
Planning version 1
Planning version N
version-dependent master
version-dependent master
version-dependent master
version-dependent master
version-dependent master
version-dependent master
data and transaction data
data and transaction data
data and transaction data
data and transaction data
data and transaction data
data and transaction data
92
Model/versions
Plants
A version is always related to amodel. A model
may havemore than one planning versions,for
simulation purpose A planning version will use
themaster data of the model towhich it is
associated and alsothe related transactional
data Master Data transferred from R/3 is
automatically assigned to model 000.Only one
version is LIVE in the systemAll other versions
are for simulation purposes
DCs
Resources
Products
PPMs
Model 1
Model 2
93
Planning book tricks tips
  • display note display details
  • drill down and dependent data
  • header
  • user settings
  • hide
  • decimals
  • UOM
  • user dependent selection list
  • how to define selection profiles

See training document on navigation tools
94
Course conclusion
QUESTIONS?
Write a Comment
User Comments (0)
About PowerShow.com
