TBG1 UBL Convergence Project

1
TBG1 - UBL Convergence Project

• Core Group Progress Report
• New Delhi - October 2006

2
TBG1 UBL core group

• Basis documents
• UBL 2.0 trade messages
• Approved TBG1 Business Requirements
  Specifications (BRS) and the existing BRS
  documents in production
• TBG1 - UBL core group
• TBG1 (Pat Toufar , Anders Grangard, Freddy De
  Vos) - UBL (Mark Leitch, Martin Forsberg, Peter
  Borresen)
• Draft a convergence document dealing with
  mission, deliverables, work plan
• Gap analysis for the messages having a UBL and a
  TBG1 version, based on an Gap analysis evaluation
  how to integrate
• Set up of a joint project for the UBL messages
  not yet in development in TBG1 (Despatch advice,
  Receipt advice)
• Common production of updated or new BRS documents

3
TBG1 UBL core group

• Organisation
• Set-up of the core group for the Gap analysis and
  integration planning
• Define work plan of the projects for the
  integration of the UBL messages for which there
  are not yet TBG1 developments
• Should report at the next UN/CEFACT forum on
  their work plan and progress
• Incorporation of the UBL Procurement group into
  TBG1
• Should be finalised at the next UN/CEFACT forum
  meeting (October 2006)
• Assimilation of the UBL procurement members as
  full TBG1 members
• Should be finalised by the end of 2007

4
TBG1 UBL core group

• Present situation
• Two meetings of 3 days (July, September)
• Gap analysis of the invoice (including credit
  note and debit note)
• Gap analysis of the remittance advice
• Next steps
• Present the Gap analysis to TBG1 and OASIS UBL TC
• Distribute full report (gap analysis and proposed
  amendments) for approval
• Draft of updated version of the BRS documents
• Present the BRS documents for approval to
  UN/CEFACT
• Work plan (start July 2006 planned end
  September 2007)
• November 2006 meeting Gap analysis Order
• December 2006 meeting Gap analysis Order
  response, Order change, Order cancellation
• January 2007 meeting Gap analysis Despatch
  advice, Packing list, Receipt advice
• March 2007 meeting Gap analysis Catalogue
  messages
• July 2007 meeting Gap analysis Self-billing

5
TBG1 UBL core group

• Gap analysis of the Invoice (incl. Credit Note
  Debit Note)
• High degree of match between TBG1 and UBL
• e.g. document header, totals etc.
• Some gaps in other areas
• e.g. Item/Product, Party etc.
• Proposed additions in Invoice Header (examples)
• Subset and Profile IDs (may be part of a new
  SBDH)
• Receipt, Originator and Additional Document
  References
• Prepaid amount
• Payable Rounding Amount
• Review the structure of pre-payments and split
  payments
• Structure Financial Account within Payment Means
  (used by Sweden)
• Open issues in Invoice Header (examples)
• Version ID
• Signature
• Naming of Party Roles (Invoice Issuer / Invoicee
  - Accounting Supplier Party / Accounting Customer
  Party)
• Only a few UBL identified elements were not
  accepted
• Evaluated by the UBL core members as not relevant
• Will be presented to OASIS UBL

6
TBG1 UBL core group

• Gap analysis of the Invoice (Credit Note / Debit
  Note)
• Proposed additions to Invoice Line (examples)
• UUID
• Free of Charge indicator
• Receipt and Billing Document cross referencing
  using existing ABIE Reference_ Documents
• Allowance charge independent of the Price
• Delivery terms
• Latest delivery date
• Delivery address and location
• Discrepancy response (credit note, debit note)
• Open issues in Invoice Line (examples)
• Pricing reference
• Delivery
• Product and Product unit (Item and Item instance)
  incl. Lot ID
• Only a few UBL identified elements were not
  accepted
• Evaluated by the UBL core members as not relevant
• Will be presented to OASIS UBL

7
TBG1 UBL core group

• Gap analysis of the Invoice (Credit Note Debit
  Note)
• Proposed additions to existing classes (ABIEs)
• Reason information in Allowance charge
• Calculated amount in Allowance charge
• Tax information in Allowance charge
• Note (free text) in Contact
• Other Communication in Contact
• Effective date, Document type, Attachment in
  Referenced documents
• Exchange market identifier, Exchange Contract in
  Currency Exchange
• Care Of, Attention Of, Logo, Website, Physical
  Location in Party
• Party Legal Entity, Party Tax Scheme to Party
• Payment Channel, Instruction and Financial
  Account to Payment Means
• Information regarding penalties for Late Payments
• Tax Per Unit information in Tax

8
TBG1 UBL core group

• Gap analysis of the Invoice (Credit Note Debit
  Note)
• Open issues in existing classes
• Loss risk information in Delivery Terms
• Currency in Financial Account
• Address of the Financial Institution to be
  discussed with TBG5
• Tax Evidence Indicator to Tax Totals
• Difference between UBL Invoice (Credit Note
  Debit Note)
• Same content with addition of
• Discrepancy Response in Header
• Discrepancy Response in Line
• Billing Document Reference in Line
• Sender / Receiver roles are reversed for Debit
  Note
• Supplier side sends Invoice and Credit Note
• Customer side sends Debit Note (to obviate Credit
  Note)
• To be decided
• One document covering Invoice, Credit Note and
  Debit Note or
• Three distinct documents

9
TBG1 UBL core group

• Gap analysis of the Remittance Advice
• Matches between TBG1 and UBL
• Very high level of commonality
• UBL Remittance Advice based largely on work of
  TBG1
• Proposed additions in Remittance Advice Header
• Subset and Profile IDs (may be part of a new
  SBDH)
• UUID
• Line Count
• Invoice Period covered rather than specific
  Invoice reference
• Open issues in Remittance Advice Header
• Version ID
• Signature
• Total Credit and Debit Amounts (in addition to
  Balance)
• Tax Totals per Tax Rate

10
TBG1 UBL core group

• Gap analysis of the Remittance Advice
• Difference in structure
• TBG1 1 Line is equal to one invoice
• UBL 1 line can be equal to one Invoice plus all
  Credit Notes and Debit Notes related to the
  Invoice
• Proposed additions in Remittance Advice Line
• UUID
• Open issues in Remittance Advice Line
• Total Credit and Debit Amounts
• Buyer and Seller
• Naming of Party Roles (Invoice Issuer / Invoicee
  - Accounting Supplier Party / Accounting Customer
  Party)
• Invoice Period covered rather than specific
  Invoice reference
• Billing Reference

11
Work plan
12
OASIS UBL Perspective

• Core group is working well and according to
  planned schedule
• highly pragmatic approach
• Level of shared requirements is high
• Common understanding of goals
• to take the best of UBLs work and the best of
  TBG1s work and create a converged, unified
  standard suite of business documents
• to propose new candidate core components where
  deemed necessary

13
OASIS UBL Perspective

• Work on the fiscal documents to date has
  highlighted two main issues
• UBLs approach to message assembly is different
  to that of TBG1
• the core group has identified potential problems
  with core components such as Party (and Product)
• The core groups issues are predominantly
  mechanical
• business issues are more in line

14
OASIS UBL Perspective

• Future work
• continue convergence of the business documents as
  per the schedule
• November - Order
• December - Order Response, Order Change Order
  Cancellation
• Hold the results in abeyance
• wait for UN/CEFACT advice regarding
• the agreed method of message assembly
• the use of core components e.g. when a
  transaction moves from the Tendering phase to the
  Purchasing phase to the Shipment phase etc.
• UN/CEFACT advice required urgently

15
Modelling Approach

• Differences in modelling approach
• UBL has a high degree of reusable components
• CII uses core components in a more specific way
• In UBL
• when an ABIE is associated from e.g. Invoice
  Line, all BBIEs and ASBIEs within the ABIE are
  imported
• In CII
• only the BBIEs required are picked

16
Example from CII
Document context specific content in ABIEs

• UBL always imports the entire ABIE from the
  library, even though only parts of it are needed
  (as in EDIFACT, where all qualifiers are
  available to a segment without regard to the
  message where it is used)
• Profiling or subsetting required to make the
  documents more specific
• This makes the GAP analysis more difficult but we
  have a great deal of help from NES (Northern
  European Subset of UBL) where the profiling is
  already done

17
UBL
Example from CII
CII
18
UBL
Example from CII
CII
Reused in order and other documents
19
UBL Approach
UBL 2.0
REFINEMENT
NES Subset
Stand Alone Order
Stand Alone Invoice
Basic Procurement
20
EDIFACT Approach
EDIFACT
REFINEMENT
EANCOM
Profile 1
Profile 2
Profile 3
21
UBL NES Approach
Subset Level
NES Common Library
NES Generic Documents
Order
Order Response
Invoice
22
CII approach
CC06B Core Components
Qualify, restrict and extend
CC06B BIE Library (Supply Chain Context)
Assembled in
Containers (Message specific BIEs)
Results in
Cross Industry Invoice
23
UBL Component Re-use Restriction
24
UBL Component Re-use Restriction
25
UBL Component Re-use Restriction
26
UBL Component Re-use Restriction
