Title: FILTERING


1
FILTERING
  • In cognitive experiments
  • Based on Luck 2005

2
Whats a filter
  • Gain the ratio of output to input
  • Amplifier system designed to boost signal
    magnitude
  • Gain 1 ? output of amp. larger than input
  • Filter system designed to reduce signal
    magnitude at particular frequencies
  • Gain given frequencies

3
Why do filtering?
  • The Nyquist Theorem
  • An analog signal can be converted to digital as
    long as the rate of digitization is twice as high
    (at least) as the highest frequency in signal
    being digitized
  • If the signal contains any frequencies higher
    than this limit (at least half or less than rate
    of digitization) they will show up as artifactual
    low frequencies (aliasing).
  • This second part is why you have to do at least
    some (online) low-pass filtering

4
Why do filtering?
  • EEG consists of a signal plus noise, and some of
    the noise is sufficiently different in frequency
    content from the signal that it can be suppressed
    simply by attenuating different frequencies, thus
    making the signal more visible
  • Unfortunately, this benefit needs to be weighted
    against the cost of distortion in your signal,
    because ANY FILTER DISTORTS AT LEAST SOME PART OF
    THE SIGNAL.

5
More on distortion
  • What kind of filter distortion are we talking
    about?
  • Filters can change the relative amplitude of ERP
    components, the timing of ERP components, and can
    add peaks that werent even there before.
  • So not just innocuous smoothing!
  • But still useful in limited capacity.

6
How to describe filter properties
  • Properties of a filter are defined by its
    TRANSFER FUNCTION.
  • Transferring signal to filter output
  • Transfer function has two components
  • Frequency response function
  • How filter changes amplitude of each frequency
  • Phase response function
  • How filter changes phase of each frequency

7
Frequency Response Function
  • Filters in ERP research often described with one
    parameter only, the half-amplitude cutoff
  • The frequency at which the amplitude is cut by
    half (50) of its original value
  • Notice that in most cases this does not mean that
    no frequencies above this value pass, they just
    pass with amplitudes between 50-0 of their
    original value

8
How to describe filter properties
  • High-pass filters are often described in terms of
    time constants instead of half-amplitude cutoffs.
  • If input to high-pass filter in time domain is
    constant, will ultimately return toward zero
  • Time constant is how long it takes for it to get
    down to 1/e of starting value

Input
Output
9
What kinds of filtering typically get done in ERP?
  • MANDATORY
  • Initial, online, low-pass filter built into the
    hardware to ensure the sampling rate is twice as
    high as highest signal frequency recorded (so you
    dont get aliasing)
  • OPTIONAL
  • High-pass filter to get rid of slow, non-neural
    potentials like skin potentials (
  • Notch filters to eliminate electrical noise (60
    Hz)
  • BAD LAST RESORT!
  • Low or high-pass to clean up data

10
What kinds of filtering typically get done in ERP?
  • Online filters can also be described as analog,
    as they are applied to a continuous voltage
    contrast
  • Offline filters can also be described as digital,
    as they are applied to data that has already been
    converted from the continuous voltage to a
    digital representation on the computer

11
What kinds of filtering typically get done in ERP?
  • Best policy is to do as little online/analog
    filtering as possiblejust the little you need to
    prevent aliasing and minimize the impact of very
    slow voltage shifts
  • Digital filtering has important advantages
  • Not permanentcan always return to unfiltered
    data
  • Easier to construct phase-invariant filters
  • Easier to adapt than a hardware filter

12
Reminder DISTORTION
  • Famous tenet of filterers
  • Precision in the time domain is inversely
    related to precision in the frequency domain
  • Kind of analogous to the Uncertainty Principle
  • The more certainly you specify what frequencies
    are in your data, the less certain you can be
    about what happened in the time domain

Low-pass filter
High-pass filter
13
Lucks Recommendations
  • Use a sampling rate of between 200 and 500 Hz,
    and make your online low-pass filter between 1/3
    and 1/4 of that
  • Use online high-pass filter (AC recording) of .01
    Hz
  • If averaged waveforms are fuzzy, can use a
    low-pass with a gentle, half-amplitude cutoff of
    between 20-40 Hz

14
Phase
  • You really want the phase portion of the filters
    transfer function to be zero for all frequencies,
    so that the phase of the ERP waveform wont
    change (you dont want to move latencies)
  • This is usually possible with offline digital
    filters
  • For this to happen with your online filter, your
    amplifier needs to incorporate special filters
    like Bessel filters that shift all frequency
    phases equally so that the original phases are
    easily recoverable.

15
Why distortions?Look at 10 Hz notch filter on 10
Hz data.
16
Why distortions? Look at a notch filter.
  • Time-domain waveforms in the Fourier analysis are
    represented as the sum of a set of
    infinite-duration sine waves
  • PROBLEM transient ERP waveforms are finite in
    durationthey consist of finite-duration voltage
    deflections, not infinite-duration sine waves
  • Thus, a notch filter of 10 Hz is equivalent to
    computing amplitude and phase in 10 Hz band of
    signal and then subtracting a sine wave with this
    amplitude from the waveform.
  • This is going to create an inverse 10 Hz
    oscillation is the portions of the ERP waveform
    where you didnt have this frequencyin fact
    possibly increasing 10 Hz noise

17
Offline Filtering
18
Filtering as a time-domain procedure a
common-sense view
  • Whats the intuitive way we could imagine of
    getting rid of the jagged lines in our waveform?

19
Filtering as a time-domain procedure
  • For each point, we could average it with the
    nearby points for a smoother waveform
  • Point x ( x1x2x3xx-1x-2x-3)
    / 7
  • More generally
  • filtERP(t) weight x ERP(tj)

20
Filtering as a time-domain procedure
  • If you just averaged together the /- 3
    surrounding points, all 6 contribute equally to
    xs new value (regardless of their distance from
    x) and this reduces temporal precision
  • Instead you can weight them by their distance
    from x ( ERP(t))
  • filterERP(t) Weight(j) ERP(tj)

21
Flip
  • Last equation shows how the many values
    surrounding one point are incorporated into
    filter equation to give transformed value for the
    one point
  • New question how does the original value of a
    given point influence all of the values in the
    waveform through the filter
  • If we think of filtering as smearing individual
    point values over time, were asking, what is the
    extent and amount of the smear?

22
Impulse Response Function (IRF)
  • The extent and amount of smear for a given point
    in a given filter is represented as a function
    over time, where t0 is when the given point
    occurs. Positive points represent smear forwards,
    negative points represent smear back (acausal
    smear)

23
Impulse Response Function (IRF)
  • If you imagine plotting the IRF at every single
    individual point, the filter it corresponds to is
    just going to be the sum of all those IRFs scaled
    to each points original value.

24
CONVOLUTION
  • Therefore, the filter equation in the time domain
    can be re-represented as
  • filterERP(t) IRF(j) x ERP(t-j)
  • Note that we have been treating the ERP waveform
    as a function over time. When you combine two
    functions in this way, you say that youre
    CONVOLVING them
  • filterERP IRF ERP

25
Convolution
  • For each point in the ERP waveERP(t)substitute
    the sum offor every scaled instantiation of the
    IRF along the timecourse of the ERP functionthe
    scaled IRFs value at that point in time t
  • filterERP(t) IRF(j) x ERP(t-j)
  • filterERP(100) IRF(1) x ERP(99) IRF(2) x
    ERP(98) IRF(3) x ERP(97)IRF(99) x ERP(1)
  • the first term on the right gives you the effect
    of point t99 on point t100, the second gives
    you the effect of point t98 on point t100, etc.

26
Properties of Convolution
  • Convolution is
  • Commutative A B B A
  • Associative A (B C) (A B) C
  • Distributive A (B C) (A B) (A C)
  • This helps answer a common question that you may
    find yourself asking What happens if you filter
    twice?
  • (ERP IRF1) IRF2 ERP (IRF1 IRF2)
  • E.g., the convolution of two gaussians ? a wider
    gaussian, SO, filtering twice with same gaussian
    is like filtering once with a wider gaussian

27
Properties of Convolution
  • Also, since convolution in time domain is equal
    to multiplication in frequency domain, frequency
    response function of double filtering equals the
    product of the two filters
  • So if you high-pass and then low-pass, like
    multiplying the two functions, usually gives you
    a band pass of the middle frequencies
  • But watch out b/c if the two freq resp functions
    have a gradual attenuation, you could get much
    MORE attenuation than you wanted of the middle
    frequencies

28
Time ?? Frequency
  • What is the relationship between the IRF and the
    HP/LP filters we were talking about before?
  • Multiplication in the frequency domain is
    equivalent to convolution in the time domain

29
Frequency MultiplicationEx low-pass filter
  • x
  • ? inv
    FFT?

30
Time ConvolutionEx 60 Hz Notch filter


31
Time ?? Frequency
32
Time ?? Frequency
  • Usually faster to filter using convolutions than
    Fourier Transforms, so most digital filters
    implemented this way
  • Thus you create your desired transfer function
    for the filter and then transform into time
    domain to create IRF
  • Ex you want to bandpass just 60 Hz
  • ?IFFT?

33
Time ?? Frequency
  • In fact, not perfect transfer
  • IRF for 60 Hz should be just 60 Hz wave
  • Problem is that sine-wave is finite, so you get
    power at other freqs too.
  • Thats why tapered function better

34
Back to distortion
  • Lets pretend our ERP waveform is just this
    portion of a perfect 10 Hz sine wave

35
Back to distortion
  • In fact, even though we defined the waveform as
    containing only a 10 hz sine wave, the spectrum
    of this waveform contains power at other
    frequencies. Why?
  • This is because the waveform is finite

36
Back to distortion
  • Remember that when time range is limited,
    frequency range is broadened, and vice versa.
  • That means that if you were to apply a filter to
    remove the 10 Hz component, you wont remove the
    entire waveform, even though we defined it as a
    purely 10 Hz sine wave

37
Back to distortion
  • The reason you see artifactual peaks is that the
    original spectrum had a lot of power in
    frequencies near 10 Hz, such that they sum with
    the 10 Hz oscillations in the IRF

38
Back to distortion
  • For the same reason, you dont see as much
    artifactual oscillation in 20 Hz or 60 Hz notch
    filters, b/c there isnt a lot of power in this
    or nearby frequencies in the original spectrum

39
Low-pass distortions
  • Shape of window (freq response function) has a
    big impact on amount of distortion
  • General rule of thumb unless you have a really
    good trick, the more ideal the filter in the
    frequency domain, the less ideal it is in the
    time domain
  • Since we usually care most about time domain for
    interpreting data, and the filtering is just an
    optional way to improve the image, usually better
    to idealize the time domain

40
Low-pass distortions
  • Shape of window has a big impact on amount of
    distortion (back to our 10 hz sine wave)

41
Low-pass distortions
  • Running average filter (here, 12.5 Hz)
  • Much less temporal spread than windowed ideal
  • Problem substantial attenuation in 10-hz band
    where most of original power located, so
    amplitude reduction
  • Problem side lobes in freq response f (due to
    sharp onset and offset of IRF) let substantial
    high-freq noise pass
  • Can be especially good for dealing with precisely
    defined line freq noise

42
Low-pass distortions
  • Gaussian filter (12.5 Hz)
  • Still a little smear in onset/offset, but almost
    complete attenuation of freq 30 Hz
  • Problem still some amplitude reduction in freq
    of interestmaybe should set cutoff higher
  • Good compromise between time and freq domain
  • Can be harder to implement than running avg.
  • Easy to describe time-domain just full-width at
    half-maximum of gaussian (FWHM)

43
Low-pass distortions
  • Causal filter (12.5 Hz)
  • An event at particular times cant affect events
    at subsequent times
  • One positive if the IRF has a fairly rapid,
    monotonic fall-off, they may produce relatively
    little distortion in onset latency, which may be
    key in some analyses.

44
A note about offline low-pass filtered data
  • Reviewers often want you to do numbers on
    (offline) unfiltered data. Does this really make
    a difference?
  • Probably doesnt have a huge effect if you use
    type of filter just recommended
  • However, helps to keep things straight in your
    head, because taking mean amplitude in a
    particular latency window from filtered waveforms
    is equivalent to taking mean amplitude from a
    larger window in the original data
  • Thus, if you use unfiltered data for this kind of
    average-over-time measurement, high frequency
    noise will average out anyway, and youll be more
    clear in your head about what latencies your
    measure is coming from
  • Note that for non-averaged measures like peak
    amplitude, this is less of an option b/c the high
    frequency noise will corrupt these measures
    significantly

45
High-pass filtering in time domain
  • A little more complicated
  • We implement this as doing a low-pass and
    subtracting it from the original waveform,
    yielding the left-over high frequencies.
  • ERPh ERP ERPl ERP (IRFl ERP)

46
High-pass filtering in time domain
  • If we substitute IRFu ERP for ERP (where IRFu
    is the unity impulse response, 1 at 0 and 0
    everywhere else) and do some more algebra, we get
    the following
  • IRFh IRFu - IRFl

47
High-pass distortions
  • Application of same 2.5 Hz high-pass filter to
    three different waveforms

48
High-pass distortions
  • Effect of high-pass filter can be very sensitive
    to shape of waveform, b/c of the negative shape
    of the IRF
  • If waveform consists of roughly equal positive
    and negative subcomponents, will lead to
    opposite-polarity copies of the IRF which will
    cancel each other out.

49
High-pass distortions
  • Effect of high-pass filter can be very sensitive
    to shape of waveform, b/c of the negative shape
    of the IRF
  • If one polarity dominates waveform, the overshoot
    will be greater

50
High-pass distortions
  • Can imagine this as reversed polarity of
    distortions low-pass produced
  • In low-pass, you get spreading of peaks in same
    polarity as peaks, giving earlier onset/later
    offset
  • High-pass filter inverts the gaussian of the
    low-pass response, so produces opposite-polarity
    spreading
  • This can be worse b/c makes it look like they are
    artifactual peaks
  • This is what makes high-pass filtering more
    dangerous than low-pass.

51
High-pass distortions
  • Interesting difference between causal and
    non-causal high pass filters
  • Noncausal hp filters take low-freq info away from
    time zone of waveform and push it forwards and
    backwards in time
  • Causal hp filters only push it forward

52
Linearity
  • Most (all?) of filters discussed here have been
    linear
  • If your filter is linear, remember that you can
    combine it with other linear operations in any
    order (e.g. signal averaging or baselining) with
    no change in the result. (artifact rejection is
    nonlinear though)
  • Keep this in mind when youre designing your
    analysis protocol, by switching things around you
    can save computing time and human time

53
Bottom line of Off-line Filtering
  • Try not to have to filter very much (e.g., get
    good data)
  • If you have to filter offline, try not to do any
    high-pass filtering (b/c of the danger of
    artifactual peaks)
  • If you have to filter offline, try filtering on a
    simulated data set firstthen you can see exactly
    what distortions are possible.

54
Reporting filters
  • Especially important if you report stats on data
    that has any offline filtering
  • Often filters reported like A low-pass filter of
    30 Hz was applied to the averaged data
  • 2 problems
  • No description of shape
  • No explicit description of what 30 Hz applies to

55
Reporting filter shape
  • We saw that amount and type of distortion heavily
    depends on shape of frequency response
    functione.g. a sharp cutoff leads to more
    oscillatory artifacts than a gradual one
  • Therefore important to report shape of filter you
    used
  • Can be a classic type with well-known
    featuresHanning, Butterworth, etc.
  • If gaussian, can specify FWHM

56
Specifying measure Amplitude vs Power
  • Although directly related, voltage amplitude is
    not the same as power
  • Voltage current x resistance
  • Power voltage x current
  • Power voltage2 / resistance

57
Specifying measure Amplitude vs Power
  • Filters can reported in terms of either, but note
    that HALF-POWER CUTOFF DOESNT EQUAL
    HALF-AMPLITUDE CUTOFF
  • .7072 (V) .5 (P)
  • So frequency at which power is reduced by 50
    will be frequency at which voltage is reduced by
    29
  • Bottom-line important to know (and report) which
    one youre using

58
Online Filtering
59
Back to the Nyquist Theorem
  • The Nyquist Theorem
  • An analog signal can be converted to digital as
    long as the rate of digitization is twice as high
    (at least) as the highest frequency in signal
    being digitized
  • If the signal contains any frequencies higher
    than this limit (at least half or less than rate
    of digitization) they will show up as artifactual
    low frequencies (aliasing).

60
Nyquist Theorem
  • Ex 100 Hz sampling rate x ½ 50 Hz Limit

10 cycles ? correct 20 cycles ? correct 40
cycles ? correct (but choppy) 40 cycles ?
incorrect (aliased to 40 Hz) 3 cycles ?
incorrect (aliased to 3 Hz)
10 Hz signal 20 Hz 40 Hz 60 Hz 97 Hz
1 sec
61
Nyquist rule
  • Requires sampling at twice the fastest frequency
    present in original waveform to prevent aliasing
  • Not just the fastest that you care about
  • This is why an online filter is necessary, to
    make sure that certain frequencies dont even
    make it to the digitization stage

62
Nyquist rule
  • Does NOT ensure that data will be smooth, only
    that the frequencies will be accurate
  • The rule assumes that the signal is perfectly
    sinusoidal, not necessarily true in physiological
    systems
  • For these reasons, you often want to limit the
    frequencies to even less than half the sampling
    rate1/3, 1/5, 1/10..
  • (some refs Attinger, Anne McDonald 1966 in
    Coles, Donchin Porges 1986 book)

63
Nyquist rule
  • If you dont have very much high frequency noise,
    you can sample less and ignore the small amount
    of aliased noise
  • Also if all your noise is at a given frequency
    (e.g. 60 Hz), you can play some tricks with the
    sampling rate to limit the aliasing
  • But these techniques probably demand some amount
    of sophistication

64
Other filtering references
  • Glaser Ruchkin, 1976, Principles of
    neurobiological signal analysis
  • Cook Miller, 1992, Psychophysiology
  • Ruchkin, 1988, in Pictons Handbook of
    electroencephalography and clinical
    neurophysiology
Write a Comment
User Comments (0)
About PowerShow.com
