Title: Grid Computing Sun Grid Engine SGE


1
Grid ComputingSun Grid Engine (SGE)
Manoj Katwal
2
Outline
  • Grid and Cluster Terminology
  • What is a Cluster vs. a Grid?
  • Types of Grids
  • Benefits of Grid Computing
  • Areas of concern
  • What is Sun Grid Engine?
  • Example N1 Grid Network Setup

Do you know?
Grid computing market will reach 12 billion by
the end of 2007 (IDC)
3
Outline, Cont.
  • Managing Jobs and Resources with a Grid Sun N1
    Grid Engine
  • Concepts in Sun Grid Engine
  • Job Submission
  • Queues
  • QMON
  • Useful commands
  • References

Do you know?
Grid computing market will reach 12 billion by
the end of 2007 (IDC)
4
Grid and Cluster Terminology
  • A GRID is a collection of computing resources
    that perform tasks. A grid appears to users as a
    large system that provides a point(s) of access
    to powerful distributed resources.
  • Resources Computer hardware, data,
    applications,networking etc.
  • Cluster
  • Tightly coupled homogenous computers, resources
  • Redundant interconnections that appears as single
    system with high availability (HB)
  • Not truly distributed system

5
Grid and Cluster Terminology, Cont.
  • Grid
  • Loosely coupled heterogeneous computers or
    resources
  • Resources can come and go
  • High scalability dynamically resources can be
    added and removed
  • It is distributed virtually everywhere
  • High Performance Computing (HPC)

Do you know?
The current version of Sun Grid Engine is
downloadable for free.
6
What is a Cluster vs. a Grid?
  • Gentzsch, Grid Computing A New Technology for
    the Advanced Web

7
Types of Grids
8
Benefits of Grid Computing
  • Better utilization of resources
  • Increased user productivity
  • Faster time-to-solution of complex scientific,
    engineering, and enterprise computational tasks

Do you know?
You can register to http//www.network.com and
get 200 CPU hours free of charge. No obligation
9
Areas of Concern
  • Users concern about Grid operation and Management
    include
  • Confusion about what grid is and how it works
  • Cross-vendor interoperability
  • CPU and application usage billing and accounting
  • Security and user authentication
  • Standardization
  • Global enterprise grids across international
    boundaries

10
What is Sun Grid Engine?
  • Open source Grid management software accepts
    jobs submitted by users
  • Software driving job distribution to compute
    nodes in a grid
  • By job means Unix like jobs (batches) or parallel
    programs (MPICH- MPI Interface)
  • Enable scheduling and prioritizing of jobs
  • Management of jobs submit, suspend, abort
  • Accounting and reporting (Arco, web based)
  • Almost all operating systems are supported

11
Example N1 Grid Network Setup
12 billions dollars
12
Managing Jobs and Resources with a Grid
13
Concepts in Sun Grid Engine
  • Hosts Four types
  • Master host, Secondary Fail over host (optional)
  • Execution hosts
  • Admin host
  • Submit hosts
  • A system can act as more than one type of host.

14
Job Submission
15
Queues
  • Cluster queues
  • Job slots
  • Resource reservation
  • Parallel environment (MPI support)
  • Policy based resource allocation
  • Job checkpointing

16
QMON
17
Useful commands
  • Qsub to submit job
  • Qhost getting an overview of available
    resources
  • Qacct job accounting information
  • Qmod managing queue state
  • Qmon graphical admin tool
  • Qconf configuring queues

18
References
  • By Jan Stafford, Editor, 30 Aug 2005
    SearchOpenSource.com http//searchenterpriselinux.
    techtarget.com/originalContent/0,289142,sid39_gci1
    120769,00.html
  • California State University, LA cluster (1 head
    node with 10 clients) http//oscar.calstatela.ed
    u/
  • Sun Grid Compute Utility Web Portal
    http//www.network.com
