Facilitated Transaction Checkout Improving Operational Efficiency

1
Facilitated Transaction Checkout Improving
Operational Efficiency

2
Outline

• Why Facilitated Transaction Checkout (FTC)?
• What is Facilitated Transaction Checkout?
• Operational Benefits
• Displays
• Technology Considerations
• Implementation Status
• Questions

3
Why Facilitated Transaction Checkout ?

• The Northeast Market Operators are having
  increasing problems performing inter-control area
  checkout in real-time
• Each market is prone to having its own unique
  rules and timelines for clearing external
  transactions
• The volume and complexity of transactions
  significantly increased time required for manual
  checkout
• Marketers were learning how to arbitrage the
  markets

4
Why Facilitated Transaction Checkout ?

• These problems increase the likelihood of
  real-time discrepancies in inter-control area
  schedules affecting transaction data accuracy.

5
What is Facilitated Transaction Checkout ?

• A tool for data exchange to support real-time
  transaction checkout
• Each Control Area provides a service that
  enables neighboring CAs to view their current
  transaction stack prior to verbal checkout

6
What is Facilitated Transaction Checkout ?

• Individual Control Areas can integrate this data
  into their existing displays to meet the unique
  needs of their Operators
• Changes made on FTC screen seamlessly carry
  into current scheduling software
• Supplemental data (e.g Ramp info) may be added
  for one Control Area and available for all
  without it being required for all.

7
What is Facilitated Transaction Checkout?

• Current implementation allows Neighboring Control
  Area to compare, in real-time, transaction
  information for scheduling on common interfaces
• Tag ID
• MW value

8
What is Facilitated Transaction Checkout?

• Seamless integration for all markets that require
  the NERC E-tag as a common identifier
• Physical or Financial transmission
• Schedule or Tag based markets

9
System Operator Benefits

• Operators can improve overall efficiency in
  real-time
• Streamline communication between Operators
  thereby reducing overall checkout time
• Allow the Operator to focus on the discrepancies
  in transaction schedules between Control Areas
• Flexible enough to allow the Operator to access
  transaction schedules for future hours
• Results in fewer failed transactions
• Reduced administrative burden allows more time
  for System Operators to operate the system

10
Additional Benefits

• No requirement for changing Market Rules
• Business as usual up to the point of
  inter-control area checkout
• The Markets continue to independently clear
  transactions for next hour
• Provides a solution for moving towards 15 minute
  transaction scheduling

11
Additional Benefits

• Financial Benefits
• Open Architecture (free code sharing)
• No monthly fee or upgrade costs to third party
• Total Project cost is limited to internal
  development time and server costs
• (45 to 60K US dollars)
• Project Costs are quickly recovered with
  reductions in additional staff required for
  checkout

12
Time Savings Utilizing FTC
Based on production or test usage
13
Displays
ISO New England view into New York Transactions
14
151632NY Checkout ready
15
151709Checkout Complete
35 seconds
16
NYISO CA View
17
IMO CA View
18
HQT CA View
19
Technology Requirements

• Must be standards based
• Technology independent
• Cost effective implementation
• Scalable for other collaboration efforts
• Secure information transfer
• Led to a Service Oriented approach

20
Service Oriented Architecture
21
Technology Benefits

• Established a repeatable, collaborative process
• Model Driven Integration (MDI)
• Driven by the CIM and the NERC Functional Model
• Standards-based messages and predictable
  processes
• Efficiency gains will minimize cost and
  accelerate schedule going forward
• Implemented a scalable Web Services Architecture
  for Control Area data exchange
• Can be leveraged for future initiatives
• Will maximize return on investment

22
Best Practice Technology

• Drafting the Service-Oriented Architecture
  Blueprint
• Gestalt - Energy Excerpts Volume 1 issue 3
• It is this need for better data flow between
  members of the utility grid that is driving the
  migration to an SOA service-oriented
  architecture and Web Services. If every power
  system operator, independent system operator and
  regional transmission organization implemented
  Web Services, the opportunity for efficient data
  sharing would be increased.
• The entire article can be found at
• http//www.rsvpnow.com/gestalt/gnl.asp?id265nli
  d12

23
Implementation Status - NPCC

• HQTE
• Checkout Service and Control Room Integration
  Testing with ISO-NE
• IMO
• Checkout Service and Control Room Integration In
  service
• Utilizing NY checkout service in production.
• ISO-NE
• Checkout Service and Control Room Integration In
  service
• Utilizing NY checkout service in production.
  Testing with HQTE
• NB / NS
• Checkout Service and Control Room Integration
  Expected in-service in spring 2005.
• NYISO
• Checkout Service In service
• Control Room Integration Deployment scheduled
  for early 2005 to follow SMD2 implementation.

24
Implementation Status - Other

• MISO
• Checkout Service and Control Room Integration
  Expected in-service in early 2005.
• PJM
• Under review.

25
Questions?
26
Contact Information

• General Questions
• Jim Hartwell
• jhartwell_at_npcc.org
• 212-840-4904
• Operational / Scheduling Questions
• Mike Zeoli
• mzeoli_at_iso-ne.com
• 413-535-4349
• Technical Questions
• Michael Martin
• mmartin_at_nyiso.com
• 518-356-7617
