Blows the competition out of the water'

1
(No Transcript)
2

• UV Pure Technologies Introduces

• Blows the competition out of the water.

3
Upstream UV Water Disinfection System Series

• Six Models
• Upstream 10-75T
• Upstream 10-50T
• Upstream 15-75T
• Upstream 15-50T
• Upstream 30-75T-1
• Upstream 30.75T-1.5

4
Upstream UV Water Disinfection System Series
5
Upstream built on 5 years of success with the
revolutionary Hallett System.

• The Hallett series
• Certified to NSF/ANSI 55A market
• Crossfire Technology platform is globally
  recognized as best-in-class technology by
  industry, engineering firms, regulatory agencies
  and health officials
• 5000 systems installed world-wide
• Designed for commercial, residential and small
  community applications up to 1 Million Gallons
  per Day
• Used for water and wastewater installations

6
Upstream is worry free, maintenance-free,
affordable.

• Crossfire Technology for your entire range of
  customers
• Laboratory validated to achieve 40 mj/cm2 UV dose
  measured at end of lamp life with models for both
  50 and 75 UVT applications for a variety of
  flow rates
• UV Pure has gone Upstream to meet the needs of
  this market - without cutting corners on safety
  and worry-free performance
• Built on the Crossfire Technology platform,
• New engineering features for unique needs of
  non-NSF customers.

7
Upstream Crossfire Technology at an affordable
price

• Custom-engineered for the unregulated market
• Built on our industry acclaimed, robust and
  reliable Crossfire Technology platform - until
  now only available in the certified Hallett
  series
• Features new technology enhancements to the core
  Crossfire Technology
• Laboratory verified to meet the same high
  standards of NSF/ANSI 55 Class A certification!

8
A CrossfireTechnology Primer
9
Crossfire Technology versus Conventional UV
design
Conventional Technology
10
Old-Style (Conventional) UV Technology - like a
light in a pipe.
11
Challenges with light in a pipe

• System Challenges
• Inefficient use of UV Light
• UV Shadowing
• Quartz fouling
• Sensor fouling

12
More challenges

• System Challenges
• Inefficient use of UV Light
• UV Shadowing
• Quartz fouling
• Sensor fouling
• Quartz breakage, quartz mercury in water
• Over-heating

13
Limitations of old-style
OVERHEATING OF CONVENTIONAL SYSTEMS

• In No Flow Conditions
• Lamps lose up to 50 of UV output
• Require 2 to 4 minutes of new flow to cool the
  lamps sufficiently to re-establish maximum safe
  UV output levels

100
4 hours
UV OUTPUT
50
2 MIN.
4 HOURSNO FLOW
Start of New Flow
14
Crossfire Technology revolutionizes 100 year old
technology.

• Revolutionary Design
• No Shadowing
• 360o Coverage
• Dual Lamp Design
• No Fouling
• Self-cleaning
• Sensors in air
• No Overheating
• Air Cooled Lamps
• Enhanced Elliptical Shape
• 20 greater efficiency

15
Upstream doesnt cut cornersour UV dose
deactivates pathogens.
16
Old style systems dont kill viruses.
17
(No Transcript)
18
We dont mess with performance claims.All
customers need safe water!

• Laboratory tested to 40 mJ/CM2 dose, same as NSF
  55 Class A standard
• Dont be fooled - old-style, non-NSF brands are
  specified for 30 mJ/CM2 dose not strong enough
  to kill dangerous pathogens
• Tested at end of lamp life and not the beginning!

• Dont be fooled - old-style, non-NSF brands test
  at very beginning of lamp life. But all UV lamps
  lose efficacy as soon as they are plugged in and
  lose 25 of their efficacy over their lifespan!
• Tested for the transmittance of water specified
  at specified flow rate
• Dont be fooled - old-style, non-NSF brands test
  at 95 UVT (95 UVT distilled water quality does
  not exist in nature!)

19
Flow Restrictors are standard in Upstream.
Because were worry free.

• Flow restrictors are critical to user safety.
• Flow rate directly impacts dosage.
• If no flow restrictor is in place, system can be
  pushed to process greater flows. (This is
  dangerous in contaminated water circumstances.)
• Conventional non-NSF systems do not come with
  flow restrictors.

20
Once again weve out engineered the competition.
21
Weve left nothing on the table.Our customers
deserve it.

• Front entry bulb change
• Small footprint
• Small clearances
• Rugged stainless steel, impact resistant ABS
  plastic, anodized aluminum
• New elliptical shape of reflectors for 20 more
  UV dose
• LED display
• Remote alarm
• Improved ballast performance

22
So Clean It Cleans Itself.

• Mechanical, wiper-blade quartz cleaning system
  ensures quartz wont foul.
• New improved quartz - smoother interior
  topography and lowered organic content
• Automatic purge valve ensures no risk of fouling
  in very low or no-flow operates automatically
  by the system. No operator involvement required.
• No quartz breakage (quartz never has to be
  removed and cleaned by hand)
• Flawless operation in extreme water hardness
  levels - without pre-treatment

23
Smart System takes the guesswork out of
diagnostics.

• Onboard LED status display and self-diagnostic
  messages.
• Optional solenoid valve shuts off water supply in
  critical mode

• Enhanced microprocessor with digital display
  audible alarm
• Patented dual sensors monitor lamp output, water
  quality transmittance, water temp and air temp
• Indicates when water is not safe, diagnoses
  problem and keeps a record of all events for
  easy diagnostic and service

24
Plus New Wireless Remote Alarm

• Our latest major industry innovation
• LED display for Safe, Caution and Critical Status
• Audible Alert for Caution and Critical Status
  (like smoke alarms)
• Operates up to 100 feet from Upstream unit

25
Built for longevity and virtually zero
maintenance

• Self cleans and notifies when annual lamp change
  is due
• Air-mounted lamps
• No downtime and risk of problems due to system
  draining to change lamps
• Like changing a desk lamp bulb
• No risk of quartz breakage (common problem with
  conventional UV)
• Proprietary electronic ballast with built-in
  lightening protection works during power surges
  and brownouts
• Durable and corrosion free materials stainless
  steel, impact resistant molded ABS plastic,
  anodized aluminum
• Proprietary bulbs for higher output and
  longer-life (one year based on 24/7 use)

26
Easy to Install Contractors and Plumbers Love
This

• Mounted vertically simple keyholes for hanging
  a one person job
• Compact footprint space efficient
• Front panel access to controls and lamps
  minimal vertical and horizontal clearances for
  lamp changes
• Flexible stainless FIP connections for quick and
  simple installation

27
(No Transcript)
28
(No Transcript)
29
UV Pures warranty establishes the BEST PRACTICE
in our industry

• 5 years on mechanical systems
• 3 years on electronics
• 1 year on lamps

30
RecapUpstream The ONLY solution for non-NSF
installations

• Globally Acclaimed Crossfire Technology
• Most effective in wider range of UVT (Water
  Transmittance) conditions
• Third party verified to perform at NSF level of
  40 mJ/CM2 to kill all pathogens (vs 30 mJ/CM2)
• Tested at end of lamp life (vs at beginning of
  lamp life)
• Self cleaning quartz wont foul.
• SMART technology (sensors and microprocessor)
  takes the guesswork out of diagnostics
• Built for longevity and virtually zero
  maintenance
• Easy to install
• New and Improved Engineered Enhancements
• Refined elliptical shape for 20 more dosage
• Faster microprocessor
• Onboard LED display
• REMOTE Alarm

31
UV Pures service and customer support systems.

• Toll Free Help Line 1 888 407 9997
• Training for Certified Service representatives
  and technicians
• Web site dealer locator engine for sales and
  service
• Web site service FAQs for customers and end-users

32
