Bone and Cartilage tumors Benign and Malignant

1
Bone and Cartilage tumors Benign and Malignant

• Department of Pathology

2
Benign tumors of bone.

• OSTEOMA involves the skull and facial bones,
  w/extremely slow growth rate
• (HYPEROSTOSIS FRONTALIS)it may extends into
  the orbit or sinuses(Gardners
• syndrome)Peak incidence 40-50 years of age
• OSTEOID OSTEOMAbenign, painful growth of the
  diaphysis of a long bone (often the tibia or
  femur)
• - Age 5-25 years, mostly males

3
(No Transcript)
4
(No Transcript)
5
Benign tumors of bone.

• -Symptoms Pain is worse at night and is
  relieved with aspirin
• -X rays central radiolucency surrounded by a
  sclerotic rim.
• -Micro small (lt 2 cms) lesion of the cortex
  with central nidus of osteoid surrounded by dense
  sclerotic rim of reactive cortical bone.

6
Benign tumors.

• OSTEOBLASTOMA Similar to an osteoid osteoma but
  larger than 2 cms in size and often involving
  vertebrae.

7
Benign tumors.

• OSTEOCHONDROMA (exostosis)
• -Benign bone metaphyseal growths capped with
  cartilage that originates from epiphyseal growth
  plate.
• -It may affects adolescent males as a firm,
  solitary growth at the ends of long bones.
• -It may be asymptomatic or cause pain,
  producing deformity, and can undergo with
  malignant transformation ( rarely)

8
Osteochondroma
9
Benign tumors, Cartilage(cont.)

• OSTEOCHONDROMATOSIS ( Multiple hereditary
  exostosis)-Characterized with multiple, often
  symmetric, osteochondromas.
• ENCHONDROMA benign cartilaginous growth
  within the medullary cavity of bone, usually
  involving the hands and feet.
• -Is a typical solitary lesion often
  asymptomatic and require no treatment.

10
Enchondroma
11
Benign tumors. Cartilage

• MULTIPLE ENCHONDROMAS (Enchondromatosis)
• OLLIER DISEASE a non hereditary syndrome,with
  multiple enchondromas in hands and feet.
• It may presents with pain and spontaneous Fxs
• It may undergo malignant transformation to
  chondrosarcoma.

12
Benign tumors. Cartilage(cont.)

• MAFUCCI SYNDROME
• Multiple enchondromas
• Soft tissue hemangiomas
• Increased risk of malignant transformation,
  ovarian Ca. and brain gliomas.

13
Maffucci Syndrome
14
Maffucci Syndrome
15
Malignant Tumors of Bone.

• OSTEOSARCOMA ( Osteogenic sarcoma)

• - Most common primary malignant tumor of
  bone
• -Malesgt females. Most occur in teenagers (
  ages 10-25)
• -Patients with familial retinoblastoma have a
  high risk
• -Clinical features localized pain and swelling

16
Malignant tumors of bone OSTEOSARCOMA(cont.)

• Classic X ray findings-Codmans triangle (
  periosteal elevation)
• -Sunburst pattern
• -Bone destruction
• -Grossly often involves the metaphyses of
  long bones, usually around the knee (distal
  femur/pro
• ximal tibia.) and it may be seen as a large,
  firm,
• white mass with necrosis and hemorrhage.

17
Malignant Tumors of Bone .Osteosarcoma

• Micro Anaplastic cells producing osteoid and
  bone.
• Tx surgery/ chemotherapy
• Prognosis poor (hematogenous metastastasis to
  the lungs is a common complication)
• SECONDARY OSTEOSARCOMAS. Occur in elderly
  persons, associated with Pagets disease,
  irradiation and chronic osteomyelitis
• Highly agressive.

18
Osteosarcoma
19
Osteosarcoma
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
CHONDROSARCOMA

• Malignant tumor of cartilage
• -Malesgt females age 30-60
• -Tumor may arise primarily or secondary to a
  preexisting enchondroma,exostosis or Pagets
  disease.
• -Clinical presentation progressively
  enlarging mass with pain and swelling, that
  typically involves the pelvic bones, spine, and
  shoulder girdle.
• -Micro composed of atypical chondrocytes and
  chondroblasts, often with multiple nuclei in a
  lacunar structure

28
Chondrosarcoma
29
(No Transcript)
30
(No Transcript)
31
GIANT CELL BONE TUMOR (Osteoclastoma)

• Uncommon malignant neoplasm containing
  multinucleated giant cells admixed with stromal
  cells. Femalesgtmales, with ages between 20-50
  years
• Clinical features bulky mass with pain and Fx.
• X rays expanding lytic lession surrounded by a
  thin rim of bone.
• It may have also a soap bubble appearance
• Gross often involves the epiphyses of long
  bones, usually around the knee ( distal femur and
  proximal tibia) seen a red brown mass with
  cystic degeneration.

32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
GIANT CELL TUMOR(cont.)

• Micro multiple osteoclast-like giant cells that
  are distributed within a background of
  mononuclear stromal cells.
• Tx surgery/ curetage or block resection
• Prognosis locally aggressive with a high rate of
  recurrence.

37
Giant cell tumor
38
EWING SARCOMA

• Malignant neoplasm of undifferentiated cells
  arising within the marrow cavity
  Males are affected slightly more often than
  females, most occur in teenagers ( 5-20)
• Clinical features pain , swelling and
  tenderness
• Classic translocation t1122 which produces the
  EWS- FL11 fusion protein
• X-ray concentric onion skin layering of new
  periosteal bone.

39
Ewing sarcoma
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
EWING SARCOMA(cont.)

• Gross often affects the diaphyses of long bones
  with most common sites like femur, pelvis and
  tibia seen a white tan mass with necrosis and
  hemorrhage.
• Micro sheets of undifferentiated small round
  blue cells resembling lymphocytes.
• Characteristic Homer- Wright pseudorosettes
• Frequently the tumoral cells erode cortex and
  periosteum and invade surrounding tissues.
• Tx. chemotherapy, surgery and/ or radiation
• Prognosis 5 year survival rate of 75

44
NEUROMUSCULAR DISORD.

• The motor unitconsists of a lower motor
  neuron(anterior horn cell or neuron in cranial
  nerve nuclei), its axon and the muscle fibers
  innervated by it. The number of muscle fibers
  innervated varies from a few fibers(oculo-motor
  muscles) to several hundreds(extremity muscles).
  Muscles fibers of one motor unit are scattered in
  a wide area in a random fashion(checkerdboard).
• Diseases can be classified as involving
  A. Motor neuron B.
  Peripheral nerves C.Neuro
  muscular junction D. Muscles

45
NEUROMUSCULAR DIS.(cont)

• A. DISEASES OF MOTOR NEURON.
  -Etiology of most of the motor neuron
  dis.(AML, progressive muscular atrophy) is not
  known, but may be caused by several agents
  adriamycin, vincristine, aluminium?perikaryon(neur
  onal cell body)
  primarily affected w/loss of microtubules and
  nuclear displacement increased cytoplasmic
  neurofilaments or tangled masses of neurofila-
  ments. Viral infections(Polyomyelitis, Herpes
  encephalitis, Varicella-zoster) may also affect
  the motor neuron or sensory ganglia.

46
NEUROMUSCULAR DISORD.

• B. DISEASES OF PERIPHERAL NERVES
  I. Axonal degeneration(axonal
  neuropathy) a. Wallerian
  degeneration(crush/cut along a myelinated fiber)

  b. Axonal degeneration
  caused by other diseases
  (less axoplasm leakage more inflammation
  chronic evolution)

  1.Proximal axonal degeneration intoxic. w/
  IDPN(BB-Iminodipropioni
  trite)?shrinkage of distal axons due to focal
  proximal blockage.
  2.Distal
  axonal degeneration earliest changes
  occur in the most distal portion of axons

47
NEUROMUSCULAR DISORD.

• DISEASES OF PERIPHERAL...(cont.)
  Many diseases w/earlier changes in
  the most distal portion of axons?slow spread to
  proximal structures?perikaryon cannot support the
  terminal axon, vgr.

  --Hereditary neuropathies.

  -HSMN I (Charcot-Marie-Tooth)disease, the MOST
  common of these, inherited as autosomal-
  dominant is usually
  present in childhood/early
  adulthood(PMP 22 gene/17p11.2-p12 locus),
  characterized by progressive atrophy of leg mus-
  cles,foot
  drop/deformed feet w/less sensory defect



48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
NEUROMUSCULAR DISORD.

• DISEASES OF PERIPHERAL...(cont.)
  --Hereditary neuropathies...
  -HSMN II(CMT2A) also AD,
  with similar manifestations than CMT I but
  without nerve enlargement and presentation at a
  la- ter age. Linked to chromosome 1p35-p36.
  -HSMN III(Dejerine-Sottas
  disease) is an AR condition that begins slowly in
  early childhood w/delayed acquisition of motor
  skills and involvement of muscles of limbs and
  trunk?enlar
  gement of nerves easy to detect. Genetic heteroge
  nicity(PMP 22, MPZ, PRX and
  EGR2).

54
(No Transcript)
55
(No Transcript)
56
NEUROMUSCULAR DISORD.

• DISEASES OF PERIPHERAL...(cont.)
  --Acquired metabolic/toxic neuropathies.
  -Diabetic peripheral
  neuropathy w/symme
  tric neuropathy involving distal sensory/mo
  tor nerves dysfunction of
  autonomic nervous system(20-40 of cases).It can
  also present as a single peripheral or cranial
  neuroneuropathy(oculomotor nerve).
  -Metabolic/nutritional
  chronic liver disease,resp. insuff., renal
  failure, thiamine def.,Vit.B12,B6,E.
  Chronic alcoholism, etc.

57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60
STRIATED MUSCLE DISORDERS (Dystrophies, Myositis
and Tumors)

• INFLAMMATORY DISORDERS.
• POLYMYOSITIS
• It may affect adults, females with bilateral
  progressive, proximal muscle weakness
• Micro endomysial lymphocytic inflammation
  (mostly cytotoxic T8)
• Skeletal muscle fiber degeneration and
  regeneration.

61
DERMATOMYOSITIS.

• It may affect children or adults, females,with
  bilateral and proximal muscle weakness
• Also skin rash of the upper eyelids ,
  periorbital edema
• Micro perimysial and vascular lymphocytic
  inflammation
• with perifascicular fiber atrophy
• Skeletal muscle fiber degeneration and
  regeneration.
• Increased risk of lung, stomach, ovarian and
  breast cancers.

62
Dermatomyositis
63
MUSCULAR DYSTROPHIES

• DUCHENNE MUSCULAR DYSTROPHY
• MOST COMMON and severe form of muscular
  dystrophy.
• X linked inheritance
• Dystrophin gene in Xp 21
• (Mutation results in a virtual absence of
  dystrophin protein)
• Normal at birth with onset of symptoms by age 5 ,
  with progressive muscular weakness of proximal
  ,shoulder and pelvic girdles.
• CALF PSEUDOHYPERTROPHY
• Heart failure and arrhytmias may occur
• Progressive respiratory failure and pulmonary
  infections
• Increased serum creatine kinase
• Muscle fibers of various sizes , necrosis,
  degeneration and regeneration fibers
• Fibrosis
• Fatty infiltration.

64
(No Transcript)
65
Duchenne muscular dystrophy

• Dx muscle biopsy with immunostains shows
  decreased dystrophin protein
• DNA analysis by PCR.

66
Duchenne muscular dystrophy
67
(No Transcript)
68
BECKER MUSCULAR DISTROPHY

• It is a less common condition
• The observed mutation produces an altered
  dystrophin protein
• Later onset with variable progression
• Cardiac involvement is rarely seen
• Patients have a relatively normal life span

69
(No Transcript)
70
MUSCULARY DISTROPHY(cont.)

• -Inclusion body myositis.
• -Myasthenic Syndromes
• -Inflammatory Neuropathies.

71
(No Transcript)
72
(No Transcript)
73
(No Transcript)
74
(No Transcript)
75
SOFT TISSUE TUMORS.

• Adipose tissue. Lipomas Liposarcomas
• Fibrosarcoma
• Rhabdomyoma , rhabdomyosarcoma
• Smooth muscle
• Vascular tumors
• Peripheral nerve tumors.

76
(No Transcript)
77
(No Transcript)
78
(No Transcript)
79
(No Transcript)
80
(No Transcript)
81
(No Transcript)
82
(No Transcript)
83
(No Transcript)
84
(No Transcript)
85
(No Transcript)
86
(No Transcript)
87
(No Transcript)
88
(No Transcript)
89
(No Transcript)
90
SOFT TISSUE TUMORS

• RHABDOMYOSARCOMA (cont.)
• Dx
  -Excisional
  biopsy
  -Immunochemistry
  vimentin
  desmin

  actin
  myoglobin

91
SOFT TISSUE TUMORS

• SMOOTH MUSCLE TUMORS.
  1. Leiomyoma
  2. Leiomyosarcoma
• VASCULAR TUMORS
  1. Hemangiomas
  2. Angiosarcomas
• SYNOVIALSARCOMA

92
(No Transcript)
