Title: Crossbow: Smarter Sensors in Silicon


1
Crossbow Smarter Sensors in Silicon
  • Johann Ammerlahn

2
Crossbow Platform Review
  • Overview and Goals
  • History
  • Design Approach
  • Current System
  • Hardware
  • Software
  • Future Directions

3
Overview and Goals
  • Big Idea Ubiquitous sensing
  • How?
  • Necessarily cheap
  • This is the military. Cheap is relative.
  • Necessarily small
  • (more survivable, low profile, etc.)
  • Necessarily many
  • (economies of scale, higher measurement
    granularity, lower power comms, etc.)
  • Necessarily robust
  • Common case no maintenance

4
Crossbow Mote History

Network Embedded Systems Technology Program
5
Hardware Development Cycle
6
Current Design Analysis Mica Series
  • Integrate sensors, computation and communication
    in single unit
  • Basic board has radio, processor, memory
  • Sandwich sensor boards in layers
  • Just like the rockgreat cleavage
  • Open-source hardware/software concept
  • Software is TinyOS (TOS) and TinyDB (TDB)
  • Hardware design and Intel networking technology
    is licensed to Crossbow
  • Modular design allows fast development

7
Available Mote Designs MICA
  • Crossbow 2nd generation wireless sensor, 4th from
    Berkeley Labs
  • Atmel ATMEGA103/128L
  • 4 Mhz 8-bit CPU
  • 128KB Instruction Memory
  • 4KB SRAM and EEPROM
  • 4 Mbit flash (AT45DB041B)
  • SPI interface
  • 1-4 uj/bit r/w
  • RFM TR1000 Radio (916/433 MHz)
  • 50 kb/s ASK
  • Focused hardware acceleration
  • 1 to 300 ft. range, RSSI
  • 51-pin connector
  • Analog ADC comparators, I2C, SPI, interrupts,
    PWM, ext. SRAM, UART
  • 100-400 depending upon configuration

8
Available Mote Designs MICA
  • Three low-power modes
  • Idle Processor is turned off
  • Power Down Everything but the
  • watch-dog is turned off
  • Power Save Only asynchronous
  • timer powered on
  • 100 mW power consumption
  • Processors, radio, typical sensor load
  • 30 uW power consumption
  • All components asleep

9
Available Mote Designs MICA2
  • Crossbow 3rd generation wireless sensor
  • Design changes to MICA
  • Processor now offers standalone boot-loader
  • New radio (Chipcon 1000)
  • 500 to 1000 ft. range, 38.4 Kbaud
  • Better noise immunity, linear RSSI
  • FM modulated (vs Mica AM)
  • Digitally programmable output power
  • Built-in Manchester encoding
  • Software programmable freq.
  • hopping within bands
  • Tiny OS v. 1.0 - improved network stack,
    debugging
  • Wireless remote programming
  • 512 Kb serial flash

10
Available Mote Designs MICA2DOT
  • Crossbow 3rd generation wireless sensor
  • Similar feature set to MICA2
  • Degraded I/O capabilities 18 pins vs. 51
  • 6 analog inputs, digital bus,
  • serial or UART
  • Integrated temperature and battery
  • voltage sensors, status LED
  • Battery is 3V coin cell instead of AA x 2
  • 25 mm diameter, 6 mm height
  • Compatible with MICA2

11
Next Generation Mote Spec
  • Single-chip mote
  • 2 mm x 2.5 mm
  • RISC core
  • 3k Memory
  • 8-bit on-chip ADC
  • FSK 19.2 kbps RF transmitter
  • Paged memory
  • SPI, RS232 compatible UART
  • 4-bit input/4-bit output port
  • Hardware support for comms encryption
  • Hardware OEM costs Under 1 in quantity (w/o
    antenna and sensors)

12
Next Generation Mote Spec (Cont.)
13
Sensor External Modules
  • Each sensor has individual power control
  • MTS300
  • Light, temperature, acoustic, sounder
  • MTS310
  • 2-axis accelerometer, 2-axis magnometer, MTS300
    feature set
  • MTS101
  • Thermistor, light sensor/photocell, 24-point
    general prototyping area
  • MDA500
  • Connects MICA2DOT I/O signals to thru holes
  • WSC100
  • Four-channel analog (12-bit digital, 100hz)
    Bluetooth radios
  • Single module dedicated to either input or output
  • 100 ft range

14
Operating System TinyOS
  • Tiny Microthreading Operating System
  • Tiny - 4k OS program memory limit
  • Microthreading - processor directly handles
    almost all data (radio, sensors, etc.)
  • OS - allows platform for future development
  • - convenient abstractions for hardware
  • Designed to do the job fast and then turn off
    everything allowed
  • Open source

15
Design Considerations
  • Make best use of most constrained asset battery
    power
  • Network self-configuration
  • Manage complexity, respond to unplanned events
  • Sensor self-configuration (?)
  • Glue and go
  • Real-time
  • Limited buffering available
  • Network robustness and maintenance
  • Multiple points of failure, self-healing ability
  • Heterogeneous end environments
  • Application specific rather than general purpose
    (?)
  • Fast creation of efficient, specific applications
    w/o too much HW-specific nastiness

16
Example Software Layer Structure
17
Example Memory Allocation
18
Example Utilization Radio Receive
19
TinyOS Programming
  • Structural VHDL puts the pieces together
  • Schematics are (usually) easier to put
  • together and understand than code
  • Industry standard design model
  • Scripts take VHDL description and
  • compile the resultant code base
  • Components are aggregated and
  • easily reused
  • Low-level component software written
  • In C and/or assembly
  • But, this is largely hidden from view for
  • standard modules

20
TinyOS Example Code
/ Messaging Component Declaration
/ //ACCEPTS char TOS_COMMAND(AM_SEND_MSG)(char
addr,char type, char data) void
TOS_COMMAND(AM_POWER)(char mode) char
TOS_COMMAND(AM_INIT)() //SIGNALS char
AM_MSG_REC(char type, char data) char
AM_MSG_SEND_DONE(char success) //HANDLES char
AM_TX_PACKET_DONE(char success) char
AM_RX_PACKET_DONE(char packet) //USES char
TOS_COMMAND(AM_SUB_TX_PACKET)(char data) void
TOS_COMMAND(AM_SUB_POWER)(char mode) char
TOS_COMMAND(AM_SUB_INIT)()
21
TinyDB Overview
  • Imposes SQL-like querying ability on nodes
  • Treats distributed network like a database (!)
  • Allows specification of which data should be
    sent, update rate, etc.
  • Filters and aggregates before displaying on PC
    screen (Java interface)
  • Saves bandwidth and power by allowing nodes to
    only transmit requested data
  • Graphical query-builder
  • Download self-configuring runtime to motes, no C
    coding

22
Crossbow Motes Conclusion
  • Crossbow motes are very cool
  • Probably cheap enough for us to buy a couple for
    playing with?
  • Otherwise, maybe just TinyOS emulation?
  • Sensor Hardware
  • Cheap, publicly-available, modular, integrated,
    power-efficient, extensible, tiny
  • Sensor Software
  • Free, open-source, modular, abstract,
    power-efficient, extensible, small
