MSC'Fatigue 2000 Wheels Module

1
MSC.Fatigue 2000Wheels Module

• DEVELOPED IN COLLABORATION WITH BFG AEROSPACE AND
  nCODE

2

MSC.Fatigue- WheelsPROCEDURE
3
QSG - Demo Model
4
Multiple Results - Travel
N36 Static Load Cases
5
Stress-time history createdfor each load
condition...
Multiple solutions performed to obtain stresses
for each node at various positions relative to
the load.
Stress at Node n
1
2
...
36
35
...
6
PROCEDURE

• Extract stress histories and calculate fatigue
  lifes from stress data from multiple FEA
  solutions
• User selects the FEA solution sets used to define
  each load condition

• Determine plane of critical fatigue damage
• Calculate stresses and fatigue damage in angular
  increments about each node
• Sum damage for each angular increment

• Display Results

7
FE-Based Wheel FatigueAnalysis Using MSC.Fatigue
MODIFICATIONSTO MSC.FATIGUE
8
Wheel Fatigue General Setup
9
Wheel Fatigue Loading Info...
10
Wheel Fatigue Job Control Results
After selecting full analysis on the job
control form, the software produces a stress-time
history for each node containing N points
(extracted from the N load cases). It then
conducts a rainflow cycle count and calculates
fatigue damage (a typical SN analysis).
11
Interactive
12
FE-Based Wheel FatigueAnalysis Using MSC.Fatigue
RESULTS
13
Fatigue Life Contours (log scale)
14
Summary

• MSC.FATIGUE provides benefits of an FE-based
  fatigue analysis design process.
• Reduced development time
• Reduced development cost
• Improved product quality
• MSC.FATIGUE Wheels module developed is fully
  functional in core Fatigue.
