Continuing Cooperation on IMT Standardization

1
Continuing Cooperation on IMT Standardization
Global Standards Collaboration (GSC) 14
2
IMT Standardization Highlights

• TIA continues to actively support the ITU IMT
  Standardization Activities
• Develop Inter-working standards which allow
  IMT-2000 technologies to seamlessly interact with
  other technologies.
• Provide input on Femtocell technology based on
  ITU-R inquiry.
• Provide updates on BWA characteristics for
  compatibility studies with fixed-satellite
  service systems in the 3,400-4,200 MHz band.
• Provide input/updates on ITU-R M.1801, M.1457-9,
  soon to be M.1457-10.
• Although TIA will not present an IMT-Advanced
  technology, TIA will remain actively engaged in
  this process. TIA has formed an IMT-EVAL Group
  to evaluate other IMT-Advanced technologies,
  Peter Nurse, Chair.
• Subcommittee TR-45.3 continues to work jointly
  with WTSC RAN to provide joint submissions for
  TDMA-SC.

3
Highlight of Current Activities (1)

• Recently Completed TR-45.5 Work Items
• E-UTRAN HRPD Inter-working Specification
• WiMAX HRPD Inter-working Specification
• EVRC Revision D
• EVRC Revision C Software Distribution
• Highly Detectable Pilots (HDP) for HRPD
• Position Determination
• TSB58 Development Support for
• CMAS, Generic Key Exchange, eHRPD and EVRC.

• Recently Completed TR-45.5 Work Items
• Ultra Mobile Broadband (UMB Family of
  Standards)
• UMB FDD
• UMB Minimum Performance
• UMB TDD
• VoIP Codecs and Protocols
• Signaling Conformance for HRPD
• Generic Key Exchange Protocol with an emphasis
  on eHRPD

4
Highlight of Current Activities (2)

• Recently Completed TR-45.5 Work Items
• Commercial Mobile Alert Specification over
  cdma2000 (1x)
• Modified documents related CDG findings on
  E-UIMID parameter
• RUIM
• CSIM
• OTASP
• OTASP for MEID related devices

• Overview of Select Current Activity
• HRPD Revision B, second Addendum
• Signaling Test Specification for MEID Revision B
• Signaling Specification for cdma2000 1x, HRPD
  and LTE Interworking
• Minimum Performance Requirements for Femtocells
• HRPD Revision C (HRPD Enhancements)
• Band Class (400 MHz, Ancillary Terrestrial
  Component (ATC L-Band))

5
Highlight of Current Activities (3)

• Overview of Select Current Activity
• cdma2000 Revision E (1x Enhancements)
• Femtocells
• Location
• Priority Services
• CMAS over HRPD
• BCMCS Codecs and Transport Protocols
• Position Determination Enhancements
• Multimode System Selection
• Enhanced System Selection for femto cells
• HRPD Performance and Conformance requirements

• Overview of Select Current Activity
• CSIM and RUIM have related work items to Open
  Market Handset (OMH) supported by the CDG
• MPS modifications for Dual Transmitter MS
• OTASP
• MMSS
• Femtocells
• eHRPD
• UMB
• E-UTRAN HRPD Interworking Addendum

6
Strategic Direction

• Strategically, TR45.5 will continue to
• Collaborate with other Standards Organizations
• Develop Interworking Specifications in support of
  other technologies (LTE, WiMAX)
• Collaborate with other standards groups, e.g.,
  3GPP and WiMAX Forum on interworking
• Collaborate with 3GPP to develop Signaling
  Conformance Specifications for Interworking
• Partner with 3GPP2 and its Organizational
  Partners and Marketing Representation Partners
• Maintain a cooperative relationship with the
  Femto Forum and Broadband Forum, in partnership
  with 3GPP2.
• Work with ITU
• Provide ITU with updates of cdma2000 as IMT-2000
  and Broadband Wireless Access (BWA), M.1801 and
  M.1457
• Provide ITU with input on Femtocell developments

7
Strategic Direction

• TR45.5 will continue to
• Develop new technologies and services.
• Concentrate on environmentally friendly systems
  and services.
• Consider, the Green Initiative
• Continue to improve battery life,
• Support of DTX in the Codec, would reduce the
  amount of energy consumption,
• 1x Revision E has the ability to put many
  terminals on the same carrier, thereby reducing
  power consumption. A base station can reduce
  power consumption by supporting a larger number
  of terminals on the same carrier.

8
Challenges

• Increase capacity while maintaining service
  quality and system coverage to satisfy market
  demands
• Enhance data throughput and reduce latency to
  accommodate existing and emerging data services
• Continue to improve battery life of the terminal
• Quick Paging Channel
• Fast Call Set-up
• New Radio Configuration
• Continue to meet time-to-market requirements by
  the industry
• Continue to meet industry requirements for
  emerging markets related to Smart Card
  development

9
TR-45.5 Next Steps/Actions

• Continue to develop new technologies and services
  for the cdma2000 industry.
• Recognize and acknowledge emerging markets and
  continue to develop key requirements and feature
  enhancements for such markets.
• In partnership with 3GPP2, TR-45.5 is developing
  a workshop to be held in Mumbai, India (November
  2009).
• Innovate and improve existing systems in TR45.5
• Work closely with regulatory bodies to provide
  solutions for
• location services,
• emergency notification,
• new frequency plans,
• other governmental services

10
TR-45.3 Next Steps/Actions

• Continues to be a joint partner in the TDMA-SC
  IMT-2000 Radio Interface in M.1457 with ATIS
  WTSC.  TR-45.3 and ATIS WTSC have completed the
  technical input for M.1457-9..
• TR-45.3 will be balloting Enhanced addenda to
  Revision G of TIA/EIA-136 to support the
  transpositions for M.1457-9 while ATIS WTSC will
  be transposing 3GPP Specifications for its part
  in support of M.1457-9 that are due August 3rd.
• Continue to support any M.1457 updates for
  TDMA-SC in the future and has submitted the first
  contribution (meeting X) toward M.1457-10 update
  along with ATIS WTSC and supported the annual
  update cycle for M.1457.

11
Supplementary Slides
12
Subcommittee TR-45.5

• TIA Subcommittees continues to develop
  international standards and have developed joint
  relations with other standards organizations
• Subcommittee TR-45.5 develops performance,
  compatibility and interoperability standards for
  Spread Spectrum Digital wireless access systems
  supporting international, public, non-public, or
  residential mobile and personal communications.
• These standards apply to service definition,
  mobile and portable station equipment, base
  station equipment, ancillary apparatus, as
  covered by applicable Parts of the FCC Rules.
• Developed joint standards with ATIS WTSC
• TR-45.5, in partnership with 3GPP2, has a
  cooperative relationship with the Femto Forum and
  Broadband Forum.

13
Emergency Services

• Commercial Mobile Alert System
• Joint activity between TR-45.5 and ATIS to
  develop CMAS-related specifications common to
  both groups
• Published Core 1x cdma2000 CMAS air interface
  standard
• Develop CMAS over HRPD standard

14
E911 and Priority Services

• Support of granting priority access to cdma2000
  services to a government- related special class
  of users.
• Support identification of emergency calls
  originated by the mobile station. This indication
  is passed to the network.
• Support Multimedia Priority Services for 1x and
  HRPD

15
Location

• Protocols and procedures to enable mobile station
  assisted advanced forward link trilateration
  (AFLT) for HRPD access networks and UMB access
  networks including Highly Detectable Pilot
• Protocols and procedures to enable mobile station
  based AFLT for 1x, HRPD, and UMB networks
• Protocols and procedures to enable additional
  Global Navigation Satellite Systems, e.g., Galileo

16
Band Class Enhancements

• Addition of band class support for the
  air-to-ground (airborne terminal and ground base
  stations) system operations
• Support 400 MHz band plan and ATC Bands
• UMB system support in the band class
  specifications
