Dimitris Dimitropoulos MSD Search Database

1
Dimitris DimitropoulosMSD Search Database
Database Replication
2
What is the MSDSD database

• A relational database primarily developed in
  Oracle that stores the cleaned up PDB together
  with reference and derived information
• Simple to understand for the novice average
  biologist and fast in performance for the
  database non-expert
• Originates from the internal MSD deposition
  database that ensures accuracy and data integrity
• In MSDSD naming and other summary information is
  repeated from every level of the hierarchy to the
  next one in order to be closer to the familiar
  PDB data

3
Main MSDSD features

• The symmetry has been expanded and the
  information of the quaternary biological
  assemblies is directly available
• External Information like binding sites and
  secondary structure has been derived on the
  assembly level
• The original PDB asymmetric unit is also
  available
• Includes and provides clear database relations
  with the ligands data mart and other reference
  information
• Includes information and cross-references to
  external databases (NCBI taxonomy, UniProt, SCOP
  etc)

4
MSDSD Conventions

• Model nomenclature focuses in simplicity rather
  than term accuracy
• Different sets of identifiers for different
  purposes
• Abstract database identifiers (ie CHAIN_ID)
• Original PDB identifiers (ie PDB_CHAIN_CODE)
• Cleaned up official identifiers (ie CHAIN_CODE)
• Several other model conventions to avoid user
  confusion and improve model clarity

5
Managing Data

• The information available in the MSD database is
  organised in application areas (data marts)
• Users may replicate only the data marts that
  they are interested in
• Some data marts are quite valuable and still
  small enough to be used on desktop systems as in
  the demonstration
• The data marts are also loosely interrelated and
  can be synchronised independently

6
DATA MARTS

• Structure Data
• Descriptions
• Secondary Structure
• Taxonomy
• Ligands
• Experimental details
• Citations
• Mapping to SWISS-PROT, SCOP, CATH, PFAM
• Active Sites
• Structural-Sequence alignment

7
Building The Search Database
Deposition
Deposition Copy
Pre-Search-Database
Replication
Transformation
Post Transformation
Search-Database
distribution
Replication
8
Database Documentation
9
Database Documentation
http//www.ebi.ac.uk/msd-srv/docs/dbdoc/
10
(No Transcript)
11
Database Replication

• EBI has by definition the role to concentrate and
  distribute biological information
• Enables distribution and sharing of the enhanced
  clean PDB in the powerful environment of a
  relational database
• Research avoids the overhead of data management,
  by adapting a consistent and ready to use
  database
• Updates are applied in a Semi-Automated Fashion

12
Why Replicate?

• To take advantage of local hardware and CPU time
  some operations are simply not possible on-line
• To avoid continuous dependency on network and
  EBI resources
• To extend or merge information with other
  databases or data sources
• To utilise the information in new innovative
  ways
• To ensure confidentiality of research

13
Replication Overview
SOURCE DATABASE
MSD SEARCH DATABASE
Database Copy Oracle Export SQL Loader Files
Incremental Replication
14
Components of the Replication

• Database copy on Sun Solaris
• Schema export-import plus sql-loader files for
  creating the database initially for Oracle on
  other platforms
• Possibility to Import to Non Oracle databases
  (MySQL)
• Periodic synchronisation with the MSD master
  database using periodic incremental scripts for
  all Oracle platforms
• Use of two schemas, main search database and
  incremental

15
Incremental Data Export Import

• Implemented in server side JavaScript
• Data is exported as Oracle Export files
  organised in marts
• Data files on the FTP server
• Aim for weekly updates
• Mechanism flexible enough to adapt on different
  data mart
• Combinations
• Prerequisites Rhino, Java, Oracle-JDBC driver,
  oracle-export-import
• The user has just to download and run the
  periodic incremental import script of a data mart
  for his database
• Database version, Data version, Data mart
  maintenance is controlled via the administration
  tables through synchronisation

16
Incremental Replication Mechanism
DATA MARTS
DATA MARTS
Increment log
Admin Tables
Admin Tables
JDBC
JDBC
crontab
crontab
PERIODIC EXPORT SCRIPT
PERIODIC IMPORT SCRIPT
Oracle Dump Files
Web-FTP Service
Target Database
MSD Search Database
