Signature Files

1
Signature Files

• CSE3201/CSE4500
• Information Retrieval Systems

2
Signature File for Text Retrieval

• A signature is created as an abstraction of a
  document.
• All the signatures that represent the documents
  in the collection are kept in a file called
  signature file.

3
Word Signature(WS)

• A word signature
• is a fixed-length bit-string represents a word.
• is described by
• The length (N)
• A number of bits set to 1(k)

N24
1 1 1 0 0 0 1 0 0 1 0 0 0 0 0 0 0 1 0 0 1 0 0 0
k7
4
Word Signature Generation

• Use a hash function to find the location of the
  bit(s) that will be set on.
• Using triplets of characters to generate word
  signature.
• divide the word into overlapping triplets.
• For each triplet of characters
• convert the characters to a numeric value (can be
  ASCII representation of the character).
• Use the the number as the input to the hash
  function.
• The hash function will produce a number which
  represent the bit position of the triplet in the
  word signature.

5
Word Signature Generation

• Example
• A signature 111000111001 is generated for the
  word signature.
• The position is read from left to right

6
Document Signature (DS)

• Document Signature can be created using two
  methods
• concatenation of word signatures
• superimposed coding.

7
Document Signature Concatenation of WS

• The length of document signatures (DS) can vary.
• A fixed number of bits may precede the document
  signature (DS) to indicate the length of DS.
• It is possible to fix the length of the Document
  Signature (DS).
• The length can be set to equal the longest
  document in the collection.
• Extra 0 bits are padded to the shorter
  documents.

8
Document Signature Superimposed Coding

• Each document is divided into blocks containing a
  constant number of distinct words.
• To create a block signature, perform OR operation
  on all the words in the block.

9
Document Signature Superimposed Coding

• To create the document signature, all the block
  signatures are superimposed.

10
Query Signature

• Query will be converted to a block signature as
  in the document.
• Query
• free 001 000 110 010
• text 000 010 101 001
• Block 001 010 111 011

11
Query on Signature File
Match? Perform AND operation between the query
and block signature, if ( result query) 0,
they are matched
Query 001 010 111 011
No
Yes
No
No
Yes
No
Yes
12
Signature File Structure

• Sequential
• During searching, each signature will be compared
  to query signature.
• Time consuming
• Bit-Sliced Signature
• The signature file undergo a matrix transposed

13
Matrix Transposed
14
Bit-Sliced
d1
d2
d3
d4
N bits
d1
d2
N records
d3
d4
sequential
Bit sliced
15
Bit Sliced Signature File

• Retrieval
• If ith bit in the query signature is set to 1,
  retrieve the ith signature block/record.
• If there is n number of bits are set to 1, only n
  number of records needs to be retrieved.

16
Bit Slice Signature File
Query 001 010 111 011
Retrieved records
Match, because all bits in this column is set to
1 (the 2nd block).
17
Bit Sliced Signature File

• Advantages
• Smaller number of records are retrieved - faster
  retrieval.
• Disadvantages
• An update operation become a very costly exercise.

18
False Drop

• False drop occurs when a documents signature
  matches a querys signature but the querys word
  does not match any word in the document.
• It is possible because 2 distinct blocks may have
  the same signatures due to
• the hashing algorithm
• superimposed coding
• The rate of false drop depends on
• The size of the signature (N bits)
• The size of bits set to 1(k bits)
• The number of words per-block

19
Inverted or Signature?

• Inverted files
• Slower retrieval
• More accurate
• Easier to maintain
• In fact, inverted files are still the most
  popular storage structure for information
  retrieval.
