Chemical Bonding:

1
Chapter 5

• Chemical Bonding
• Covalent Bond Model

2
Sec 5.1 Covalent Bond Model

• Covalent bonding is different from ionic bonding
  in several ways
• Covalent bonds are usually between two nonmetals,
  even the same element
• Covalent bonds involve sharing of electrons
  rather than transfer of electrons
• Covalent compounds are discrete molecules as
  units (ie not crystals)
• Covalent compounds can be solid, liquid, or gas
  at room temperature

3
Sec 5.1 Covalent Bond Model

• Covalent bond a chemical bond resulting from
  elements sharing electrons
• The orbitals overlap so that both elements in the
  bond satisfy the octet rule
• Example H2, Cl2

4
Sec 5.2 Lewis Structures

• Drawing Lewis structures for covalent bonds
• Dots stand for unshared electrons
• When two electrons are shared between elements,
  we indicate a the bond with a line
• Differentiate between bonding pairs and
  nonbonding pairs
• Example H2, Cl2, CH4

5
Sec 5.2 Lewis Structures
Figure 5.1 page 100
6
Sec 5.2 Lewis Structures

• Exceptions to the octet rule
• Boron has 3 valence electrons, it can be stable
  with 6 electrons (3 bonds)
• Sulfur can be stable with 8, 10, or 12 valence
  electrons due to its size
• Hydrogen needs only 2 electrons
• BF3

7
Sec 5.3 Single, Double, Triple

• More than 2 electrons can be shared between two
  elements
• 2 electrons is called a single bond
• 4 electrons is called a double bond
• 6 electrons is called a triple bond
• There is no quadruple bond
• Examples O2, CO2, N2, HCN

8
Sec 5.4 Determining Bonds Formed

• In general the number of covalent bonds an
  element can form from the valence
• Carbon with 4 electrons can form 4 total bonds
• Nitrogen with 5 forms 3 total bonds
• Oxygen with 6 forms 2 total bonds
• Halogens (F, Cl, Br, I) and Hydrogen form 1 bond.
  These elements will never be involved in double
  or triple bonds

9
Sec 5.5 Coordinate Covalent Bonds

• In general skip this concept

Figure 5.3 Page 105
10
Sec 5.6 Drawing Lewis Structures

• Tactics for completing Lewis Structures
• Find the total valence electrons for the
  molecular (add valences for each atom)
• Determine arrangement of atoms or work from given
  backbone
• Connect atoms with single bonds and subtract
  those e- from the total valence
• Leave lone pairs untouched, and fill in other
  valance e- to fit octet rule (the hard part)

11
Sec 5.6 Drawing Lewis Structures

• Practice makes it much easier
• Rules to remember
• Oxygen will never have more then 2 bonds (1
  double or 2 single)
• Hydrogen and Halogens will never be in the middle
  of a chain, they always cap an end
• Dont break up pairs on elements such as Oxygen,
  Phosphorus, Sulfur, Halogens

12
Sec 5.6 Drawing Lewis Structures
13
Sec 5.7 Bonding with Ions

• Slightly different from the book
• We examine the bonding within polyatomic ions
• If negative, remember to add an extra electron
  (for example NO2-)
• If positive, remember to remove an electron (for
  example NH4)
• Then the polyatomic associates with the opposite
  ion (book example of K2SO4)

14
Sec 5.8 Molecular Geometry

• VSEPR Valence Shell Electron Pair Repulsion
• Method of predicting molecular shape based on the
  number of bonding and non-bonding electron pairs
• Bond angles arise due to electron repulsion

15
Sec 5.8 Molecular Geometry

• Three Primary Classes for Shape
• Tetrahedral 4 regions of electron density
• Trigonal Planar 3 regions of e- density
• Linear 2 regions of e- density
• Double and triple bonds are one density
• Subclasses are based on the number of lone pairs
• Example CF4 vs. PF3

16
(No Transcript)
17
Sec 5.8 Molecular Geometry
Chemistry at a Glance Page 112
18
Sec 5.9 Electronegativity

• How can we tell if the bond is covalent or ionic
  ?
• Electronegativity a measure of an atoms
  attraction for electrons
• Metals have lower EN, want to give up electrons
• Nonmetals have higher EN, wanting to gain
  electrons

19
Sec 5.9 Electronegativity
20
Sec 5.9 Electronegativity
21
Sec 5.10 Bond Polarity

• In general, if the elements have a difference in
  electronegativity of 1.9 or greater, the bond is
  ionic.
• If the difference in electronegativity is less
  than 1.9, the bond is covalent
• Check metals and nonmetals to confirm

22
Sec 5.10 Bond Polarity

• Even with covalent bonds, there can be unequal
  sharing of electrons
• If the difference in the electronegativity is
  between 0.5 and 1.9 the bond is polar
• Polar covalent bond means that the bond is not
  even, there is a partial positive pole and a
  partial negative pole
• These poles are indicated with a and sign and
  the lowercase greek delta (d)

23
Sec 5.11 Molecular Polarity

• In the same way that a bond can have uneven
  sharing making it polar, the overall molecule can
  also be the same
• This concept of polar molecules applies to
  covalent molecules (ionic is already known)
• There are two factors to consider
• Are the bonds in the molecule polar
• What is the geometry and does it have an effect

24
Sec 5.11 Molecular Polarity

• In some cases, multiple polar bonds cancel out
  the opposite direction, rendering the molecule
  overall nonpolar
• Example CO2, CCl4 (Compared with CH3Cl)
• In other cases, a molecule is polar due to the
  lone pairs
• Example H2O, NH3
• In general, figure out the lewis structure and
  then determine polarity

25
Sec 5.11 Molecular Polarity

• Figure 5.13
• Page 118
• The difference of
• CH4 and CH3Cl

26
Sec 5.12 Naming Molecular Compounds

• Remember Binary Ionic Compounds?
• Binary Covalent Molecular compounds are slightly
  different in naming
• Remember binary means only 2 different elements
• When naming, use a prefix to announce how many
  atoms of each type are present in the compound

27
Sec 5.12 Naming Molecular Compounds

• Prefixes for numbers
• Table 5.1 Page 119
• Note that these prefixes are common

28
Sec 5.12 Naming Molecular Compounds

• Generally, give the prefix and name of the first
  element, then the prefix and stem of the second
  element with the suffix ide
• N2O3 would be dinitrogen trioxide
• CCl4 would be carbon tetrachloride
• Some compounds such as H2O, CH4, and NH3 go by
  common names but can be named by the same method
  as above

29
Sec 5.12 Naming Molecular Compounds
Table 5.2 Page 119
30
Problems

• Assigned problems pages 121 - 124
• 5.16, 5.17, 5.21, 5.22
• 5.24, 5.27, 5.29, 5.30
• 5.36, 5.39, 5.43, 5.51, 5.52, 5.53
• Practice Test page 124
