2D Matrix Data

1
2D Matrix Data
2D Matrix Data
2
Two-dimensional data has two location indicators
for each data point
If the location indicators are evenly spaced, the
data can easily be stored as a 2D Matrix file.
3
Two-dimensional data has two location indicators
for each data point
X Y speed 0.5 0.5 0.0350 0.5 1.0 0.0714 0.5
1.5 0.3853 1.0 0.5 0.4911 1.0 1.0 0.2422 1.0
1.5 0.9207 1.5 0.5 0.5744 1.5 1.0 0.3305 1.
5 1.5 0.8485
4
Two-dimensional data has two location indicators
for each data point
X
0.5 1.0 1.5 0.5 0.0350 0.0714 0.3853
1.0 0.4911 0.2422 0.9207 1.5 0.5744 0.3305 0.84
85
Y
5
Organization of 2D Matrix files
There is no standard layout for 2D matrix files
Some standard file formats which use binary
storage of data HDF netCDF FITS TIFF
6
Images as 2D Matrix files
The most common form of 2D matrix file is the
digital image.

• Remember that the pixel values or intensities in
  an image may represent
• intensity
• density
• temperature
• pressure
• some other measurement taken on a
• regular grid.

7
Common Enhancement Techniques for Images
- look up table transformations - histogram
modifications - geometric transformations -
filtering
8
Identity Transformation
TRANSFORMATION FUNCTION
transformed pixel value
original pixel value
9
Photographic Negatives
TRANSFORMATION FUNCTION
transformed pixel value
original pixel value
10
Photographic Negatives
11
Thresholding
TRANSFORMATION FUNCTION
transformed pixel value
original pixel value
12
Thresholding
13
Contrast Stretching
TRANSFORMATION FUNCTION
transformed pixel value
LO
HI
original pixel value
14
Contrast Stretching
15
Grey level Distribution plotted as a Histogram
16
Grey level Distribution plotted as a Histogram
17
Grey level Distribution plotted as a Histogram
18
